Mercury Marine Extension Kits Exhaust / Cooling Systems & Extension Kits Driveshaft Extension Kit (98634A13)

Revise Search: Accessories 1994 & Up > Exhaust / Cooling Systems & Extension Kits > Extension Kits > 1994 & Up > Driveshaft Extension Kit (98634A13)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Driveshaft Extension Kit (98634A13)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	98634A13	MAIN KIT (1 required per assembly)
		98634A13 - MAIN KIT [ More info ] Unavailable
#-	12304	PLUG (1 required per assembly)
		19-12304 - Plug [ More info ] $16.69 Available to Order: Shipping delay up to 10 days.
#1	93911A4	HOUSING ASSEMBLY SHAFT EXTENSION SUPPORT (1 required per assembly)
		93911A 4 - Housing Assembly [ More info ] $985.99 Available to Order: Shipping delay up to 10 days.
#2	8M0169589	FITTING GREASE (Use with greased bearing) (1 required per assembly) — Replaces: 74036
		228M0169589 - Fitting Note: Priced Individually [ More info ] $4.79 1 In Stock.
#2	8M0204738	SET SCREW (Use with non-greased bearing) (1 required per assembly) — Replaces: 8M2015913
		10-8M0204738 - SET SCREW [ More info ] Unavailable
#3	47651	SCREW (.437-14 X 1.50) (6 required per assembly)
		10-47651 - Screw [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#4	861776A2	PLATE KIT (1 required per assembly) — Replaces: 97350T1
		861776A 2 - Exhaust Plate Kit [ More info ] $119.49 $117.81 1 In Stock.
#5	93923A1	MOUNT ASSEMBLY (2 required per assembly)
		93923A 1 - Mount Assembly [ More info ] $157.99 Available to Order: Shipping delay up to 10 days.
#6	47651	SCREW (.437-14 X 1.50) (4 required per assembly)
#7	32993	LOCKWASHER (.437) (4 required per assembly)
		13-32993 - LockWasher - Priced Individually [ More info ] $1.70 9 In Stock.
#8	814309A1	HOUSING ASSEMBLY (1 required per assembly)
		814309A 1 - Flywheel Housing Assembly [ More info ] $533.99 Available to Order: Shipping delay up to 10 days.
		MC-24-44187 - Bellhousing [ More info ] $473.00 $362.70 Available to Order: Shipping delay up to 10 days.
#9	818718A3	COVER KIT (1 required per assembly)
		818718A 3 - Cover Assembly [ More info ] $70.99 Available to Order: Shipping delay up to 10 days.
		MC-24-14043 - Flywheel Housing Dust Cover [ More info ] $52.00 $39.87 Available to Order: Shipping delay up to 10 days.
#10	86015	GASKET (1 required per assembly)
		27-86015 - Flywheel Housing Cover Gasket [ More info ] $11.49 Available to Order: Shipping delay up to 10 days.
#11	98253	SCREW (.250-20 X .500) (7 required per assembly)
		10-98253 - Screw [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#12	26992	LOCKWASHER (.250) STAINLESS STEEL (7 required per assembly)
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#13	37612	SCREW (.375-16 X 1.250) (2 required per assembly)
		10-37612 - Screw - Priced Individually [ More info ] $2.49 3 In Stock.
#13	47688	SCREW (.375-16 X 2.750) (2 required per assembly)
		10-47688 - Screw [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#14	35048	LOCKWASHER (.375) (8 required per assembly)
		13-35048 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#15	78458A1	TUBE (2 required per assembly)
		78458A 1 - Exhaust Tube Assembly [ More info ] $85.99 In Stock
		18-2760 - Exhaust Tube 78458A1 [ More info ] $60.99 $58.97 10+ In Stock.
		61-00519 - Exhaust Bellows, 78458A 1 [ More info ] $61.99 $51.84 1 In Stock.
#16	41063A1	BRACKET ASSEMBLY (1 required per assembly)
		41063A 1 - Bracket Assembly [ More info ] $37.99 Available to Order: Shipping delay up to 10 days.
#17	861316	STUD (.375-16 X 2.750) SPECIAL (1 required per assembly) — Replaces: 64066
		16-861316 - Stud [ More info ] $15.09 Available to Order: Shipping delay up to 10 days.
#18	32219	NUT (.375-16) (1 required per assembly)
		11-32219 - Nut (3/8-16) [ More info ] $2.79 10+ In Stock.
#19	939201	PLATE (1 required per assembly)
		93920 1 - Plate - Cover [ More info ] $53.99 Available to Order: Shipping delay up to 10 days.
#20	92913	SCREW (.437-14 X .750) (2 required per assembly)
		10-92913 - Screw [ More info ] $15.49 $12.40 3 In Stock.
#21	32993	LOCKWASHER (.437) (8 required per assembly)
#22	814263A1	BASE ASSEMBLY (2 required per assembly)
		814263A 1 - Mount Base Assembly [ More info ] $129.99 In Stock
#23	816331	NUT (.750-16) (2 required per assembly)
		11-816331 - Nut, (.750-16) [ More info ] $7.59 10+ In Stock.
#24	12657	TAB WASHER (2 required per assembly)
		14-12657 - Tab Washer [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#25	859126	NUT (.750-16) (2 required per assembly) — Replaces: 49252
		11-859126 - Nut, (.750-16) [ More info ] $17.49 5 In Stock.
#26	817416A4	HOUSING ASSEMBLY (1 required per assembly) — Replaces: 42304A2
		817416A 4 - Housing Assembly [ More info ] $1,735.99 Available to Order: Shipping delay up to 10 days.
#27	93924	SEAL (1 required per assembly)
		26-93924 - Seal [ More info ] $29.39 Available to Order: Shipping delay up to 10 days.
#28	93944A2	BEARING SET BALL (1 required per assembly) — Replaces: 93944A1
		30-93944A 2 - Jackshaft Gimbal Bearing [ More info ] $138.49 Available to Order: Shipping delay up to 10 days.
#29	93914	RING RETAINING (1 required per assembly)
		53-93914 - Ring - Retaining [ More info ] $95.99 Available to Order: Shipping delay up to 10 days.
#30	8M0169589	FITTING GREASE (1 required per assembly) — Replaces: 74036
#31	93908A1	SHAFT ASSEMBLY (1 required per assembly)
		93908A 1 - Input Shaft [ More info ] Unavailable
#32	93921	EXPANSION PLUG (1 required per assembly)
		19-93921 - Plug [ More info ] $34.49 Available to Order: Shipping delay up to 10 days.
#33	93915	RING RETAINING (1 required per assembly)
		53-93915 - Ring - Retaining [ More info ] $57.95 10+ In Stock.
#34	8M0169589	FITTING GREASE (1 required per assembly) — Replaces: 74036
#35	93918A1	SHIELD LOWER (2 required per assembly)
		93918A 1 - Shield- Lower [ More info ] $260.99 Available to Order: Shipping delay up to 10 days.
#36	93919A1	SHIELD UPPER (2 required per assembly)
		93919A 1 - Shield- Upper [ More info ] $325.49 Available to Order: Shipping delay up to 10 days.
#37	96995	SCREW (.375-16 X .880) (3 required per assembly)
		10-96995 - Screw [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#38	57053	SCREW (.500-20 X 4.500) (2 required per assembly)
		10-57053 - Screw [ More info ] $5.49 Available to Order: Shipping delay up to 10 days.
#39	42307	WASHER (4 required per assembly)
		12-42307 - Washer, Spherical [ More info ] $19.79 Available to Order: Shipping delay up to 10 days.
#40	898832	NUT (.500-20) (2 required per assembly) — Replaces: 28040, 82670817
		11-898832 - Nut, (.500-20) [ More info ] $3.69 Available to Order: Shipping delay up to 10 days.
#41	41575A3	HARNESS ASSEMBLY (1 required per assembly)
		84-41575A 3 - Extension Harness, NLA [ More info ] Unavailable
#42	93906A2	SHAFT (1 required per assembly)
		93906A 2 - Shaft Assembly - Output [ More info ] $912.99 Available to Order: Shipping delay up to 10 days.
#43	25439	O-RING (.862 X .103) (2 required per assembly)
		25-25439 - O-Ring, Shaft Shaft Bushing [ More info ] $1.99 10+ In Stock.
#44	94104	RING RETAINING (1 required per assembly)
		53-94104 - Ring - Retaining [ More info ] $10.79 Available to Order: Shipping delay up to 10 days.
#45	62780T	BEARING BALL (1 required per assembly) — Replaces: 62780A1, 62780
		30-62780T - Ball Bearing [ More info ] Unavailable
		30-879194A03 - Jackshaft Gimbal Bearing [ More info ] $167.49 In Stock
#46	8M0204643	SCREW (3 required per assembly) — Replaces: 14883
		10-8M0204643 - SCREW [ More info ] Unavailable
#47	49126	BUSHING (1 required per assembly)
		23-49126 - Bushing - Pilot - Crankshaft [ More info ] $59.99 Available to Order: Shipping delay up to 10 days.
#48	841897T	RING RETAINING (1 required per assembly) — Replaces: 94103, 94103T
		53-841897T - Ring - Retaining [ More info ] $19.69 Available to Order: Shipping delay up to 10 days.
		538M0141818 - RING-RETAINING [ More info ] $19.69 Available to Order: Shipping delay up to 10 days.
#49	8M0062634	HOSE 44.00 INCH BULK (1 required per assembly) — Replaces: 4285069
		32-8M0062634 - Transom to Thermostat Housing Hose -44I [ More info ] $40.99 In Stock
#50	865672079	HOSE (96.00 INCHES BULK) (1 required per assembly) — Replaces: 1743579, 86334379
		32-865672079 - Hose-96 Inch [ More info ] Unavailable
		32-8M0062666 - Water Hose Bulk -96" [ More info ] $220.99 $218.15 Available to Order: Shipping delay up to 10 days.
#51	986241	HOSE (133.00 INCHES BULK) (1 required per assembly)
		0986241 - Shaft & Gear Assembly (986241) [ More info ] $114.99 $69.92 4 In Stock.
#52	986291	HOSE (136.00 INCHES BULK) (1 required per assembly)
		0986291 - Lead Assembly (986291) [ More info ] $14.29 $12.16 8 In Stock.
