Parts for 10 Magnum 2-Stroke Carbureted Mercury Outboard Motor Clamp Bracket
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 8894A8 | BRKT-CLAMP-P-BLK (Port) (Black) (1 required per assembly) |
  |
|
3404-8894A 8 - Clamp Bracket Assembly [ More info ]
|
| #2 | 8892A6 | BRKT-CLAMP-S-BLK (Starboard) (Black) (1 required per assembly) |
  |
|
3403-8892A 6 - Clamp Bracket [ More info ]
|
| #3 | 92767A3 | THUMB SCREW ASSEMBLY (16 MM) (2 required per assembly) |
  |
|
10-92767A 3 - Thumb Screw Assembly, 16MM [ More info ]
|
| #4 | NSS | NOT SOLD SEPARATE (HANDLE) (2 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #5 | NSS | NOT SOLD SEPARATE (RIVET) (2 required per assembly) |
| #6 | 818884 | WASHER (2 required per assembly) — Replaces: 73719 |
  |
|
12-818884 - Washer [ More info ]
|
| #7 | 768042 | SHOULDER SCREW HEX (2 required per assembly) |
  |
|
0768042 - T-SHRT-M-G.BASS [ More info ] Unavailable |
| #8 | 8M0084719 | SPACER (1 required per assembly) — Replaces: 818539 |
  |
|
238M0084719 - Spacer [ More info ]
|
| #9 | 4000333 | SCREW @5 (2 required per assembly) |
  |
|
10-40003 33 - Screw - Priced Individually [ More info ]
|
| #10 | 12869 | DECAL (1 required per assembly) |
  |
|
37-12869 - Decal [ More info ]
|
| #11 | 814427 | SHUTTLE-TILT LOCK (1 required per assembly) |
  |
|
814427 - Tilt Lock Shuttle [ More info ]
|
| #12 | 42078 | TILT TUBE (Handle Models) (1 required per assembly) |
  |
|
42078 - Tilt Tube [ More info ]
|
| #13 | 8M0041936 | TILT TUBE (RC Models) (1 required per assembly) — Replaces: 883067, 8M0035074 |
  |
|
8M0041936 - Tilt Tube [ More info ]
|
| #14 | 8M0085928 | CLIP (1 required per assembly) — Replaces: 30954 |
  |
|
548M0085928 - Clip [ More info ]
|
| #15 | 93164 | NUT (2 required per assembly) |
  |
|
11-93164 - Nut, (.875) [ More info ]
|
| #16 | 71421 | WASHER @2 (2 required per assembly) |
  |
|
12-71421 - Washer, Nylon [ More info ]
|
| #17 | 42390A1 | LEVER ASSY (2 required per assembly) |
  |
|
42390A 1 - Lever Assembly [ More info ]
|
| #18 | NSS | NOT SOLD SEPARATE (SCREW) (M5 X 35) (2 required per assembly) |
| #19 | NSS | NOT SOLD SEPARATE (SPRING) (2 required per assembly) |
| #20 | NSS | NOT SOLD SEPARATE (KNOB) (2 required per assembly) |
| #21 | 90901 | STRAP PORT SIDE (1 required per assembly) |
  |
|
90901 - Tilt Stop Strap [ More info ] Unavailable |
| #22 | 42498 | SCREW (2 required per assembly) |
  |
|
10-42498 - Screw [ More info ]
|
| #23 | 31030 | WASHER-WAVE @5 (1 required per assembly) |
  |
|
13-31030 - Wave Washer - Priced Individually [ More info ]
|
| #24 | 43216 | SCREW (2 required per assembly) |
  |
|
10-43216 - Screw [ More info ]
|
| #25 | 67983 | WASHER (2 required per assembly) |
  |
|
12-67983 - Washer, Clamp Bracket Bolt [ More info ]
|
| #26 | 8267118 | NUT (2 required per assembly) |
  |
|
11-826711 8 - Nut [ More info ]
|
| #27 | 113841 | SPACER (RC Models) (1 required per assembly) |
  |
|
23-11384 1 - Spacer [ More info ]
|
| #28 | 93164 | NUT (RC Models) (2 required per assembly) |
| #29 | 19624A1 | SEAL KIT (RC Models) (1 required per assembly) |
  |
|
19624A 1 - Seal Kit [ More info ]
|
| #30 | 29619 | O-RING (.583 X .103) (RC Models) (1 required per assembly) |
  |
|
25-29619 - O-ring, (.583 X .103) [ More info ]
|
| #31 | 78861 | SPACER (RC Models) (1 required per assembly) |
  |
|
23-78861 - Spacer [ More info ]
|
| #32 | 8M0204726 | NUT-BRASS @3 (RC Models) (2 required per assembly) — Replaces: 826709113, 8M0042636 |
  |
|
118M0204726 - NUT-BRASS Note: Priced Individually [ More info ]
|
| #33 | 37828 | WASHER (.390 X .625 X .062) STAINLESS STEEL (.625 O.D.) (RC Models) (3 required per assembly) |
  |
|
12-37828 - Washer, (.390 X .625 X .062) Stainless Steel [ More info ]
|
| #34 | 30521 | WASHER @5 (RC Models) (1 required per assembly) |
  |
|
12-30521 - Washer, (.97 X .56 X .19) (neoprene) [ More info ]
|
| #35 | 8M0109680 | WASHER (RC Models) (1 required per assembly) — Replaces: 71970 |
  |
|
128M0109680 - Washer [ More info ]
|
| #36 | 8240717 | SCREW W/WASHER (RC Models) (2 required per assembly) |
  |
|
10-824071 7 - Screw [ More info ]
|
| #37 | 11607 | BRACKET (RC Models) (1 required per assembly) |
  |
|
|
| #38 | 401388 | NUT @5 (RC Models) (2 required per assembly) |
  |
|
11-40138 8 - Nut - Priced Individually [ More info ]
|
| #39 | 29698 | BALL JOINT (RC Models) (1 required per assembly) |
  |
|
29698 - Ball Joint [ More info ]
|
| #40 | 11606A1 | ATTACHING KT-STBD (RC Models) (1 required per assembly) |
  |
|
11606A 1 - Attaching Kit - Starboard [ More info ]
|
| #41 | 66751 | SPACER (RC Models) (1 required per assembly) |
  |
|
23-66751 - Spacer - .25 X .39 X .63 [ More info ]
|
  |
|
23-8M0151156 - SPACER [ More info ] Unavailable |
| #42 | 424291 | RETAINER (RC Models) (2 required per assembly) |
  |
|
42429 1 - Retainer [ More info ]
|
| #43 | 11372 | CLIP (RC Models) (1 required per assembly) |
  |
|
|
| #44 | 15822001 | PLUG (RC Models) (1 required per assembly) — Replaces: 15822 |
  |
|
|
| #45 | NSS | NOT SOLD SEPARATE (DECAL-LOWER TILT LIMIT) (1 required per assembly) |
| #46 | NSS | NOT SOLD SEPARATE (DECAL-TILT LOCK) (1 required per assembly) |
