Parts for Mercury 95XR (Jet Drive) Cylinder Block Assembly

Revise Search: Mercury Jet Drive & SportJet > 95XR (Jet Drive) > 1996 0E145580 - 0E151579 - USA > Cylinder Block Assembly

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Cylinder Block Assembly

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	818153A66	PH 95 JET 97 (Painted) (1 required per assembly) — Replaces: 818153A45
		800-818153A66 - PH 95 JET 97,NLA [ More info ] Unavailable
#1	818153A43	CYLINDER KIT (1 required per assembly)
		800-818153A43 - Cylinder Kit, NLA [ More info ] Unavailable
#2	809469A2	GASKET SET POWERHEAD (1 required per assembly)
		27-809469A 2 - Gasket Set [ More info ] $89.99 $76.21 2 In Stock.
#3	8263942	STUD (With Dri Loc) (1 required per assembly) — Replaces: 826394, 8263941
		16-826394 2 - Stud [ More info ] $10.00 $8.47 10+ In Stock.
#4	43044	PIN DOWEL - WITHOUT HOLE (.375 X .625) (2 required per assembly)
		17-43044 - Pin -Dowel-solid [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#5	32132	SCREW (.375-16 X 1.750) (2 required per assembly)
		10-32132 - Screw [ More info ] $2.99 4 In Stock.
#6	53734	SCREW (.375-16 X 3.00) (4 required per assembly)
		10-53734 - Screw [ More info ] $0.50 $0.43 10+ In Stock.
#7	47688	SCREW (.375-16 X 2.750) (1 required per assembly)
		10-47688 - Screw [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#8	820589	SCREW (.250-20 X 1.250) (2 required per assembly)
		10-820589 - Screw [ More info ] $9.99 Available to Order: Shipping delay up to 10 days.
#9	828271	WASHER (8 required per assembly)
		12-828271 - Washer [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#10	8M0204671	NUT (1 required per assembly) — Replaces: 86226
		11-8M0204671 - NUT [ More info ] Unavailable
#11	F719372	PIN WATER JACKET (NATURAL) (2 required per assembly)
		17-F719372 - Pin, Water Jacket Tube [ More info ] $1.70 $1.45 10+ In Stock.
#12	F719418	TUBE WATER JACKET PIN (2 required per assembly)
		32-F719418 - Water Tube Jacket [ More info ] $2.99 Available to Order: Shipping delay up to 10 days.
#13	F691372	PIN WATER JACKET (BLACK) (Top) (1 required per assembly)
		17-F691372 - Pin, Water Jacket Tube [ More info ] $1.63 10+ In Stock.
#14	F719943	TUBE WATER JACKET PIN (Top) (1 required per assembly)
		32-F719943 - Water Tube Jacket [ More info ] $3.10 $2.63 10+ In Stock.
#15	47945	PLUG PIPE (1 required per assembly)
		22-47945 - Pipe Plug [ More info ] Unavailable
#16	F722109-1	PLUG (NYLON) CYLINDER HEAD (1 required per assembly)
		22-F722109-1 - Plug - (Nylon), NLA [ More info ] $7.81 10+ In Stock.
#17	8237002	GASKET SPACER PLATE (1 required per assembly)
		27-823700 2 - Gasket [ More info ] $35.49 Available to Order: Shipping delay up to 10 days.
#18	8205002	GASKET TRANSFER PORT (2 required per assembly)
		27-820500 2 - Gasket [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#19	819110062	SCREW (8 required per assembly)
		10-819110062 - Screw [ More info ] $2.59 $2.08 6 In Stock.
#20	8197373	COVER TRANSFER PORT (2 required per assembly)
		819737 3 - COVER-T FER PORT,NLA [ More info ] Unavailable
#21	820438	GASKET CYLINDER HEAD (1 required per assembly) — Replaces: 8204381
		27-820438 - Cylinder Head Gasket [ More info ] $83.49 Available to Order: Shipping delay up to 10 days.
#22	819857A3	CYLINDER HEAD KIT CYLINDER (1 required per assembly)
		900-819857A 3 - Head Kit -3 Cylinder [ More info ] $99.99 $84.68 10+ In Stock.
#23	878609	SCREW (#10-16 X .600) (1 required per assembly) — Replaces: 8128321
		10-878609 - Screw [ More info ] $2.59 10 In Stock.
#24	8M0204666	WASHER @5 (1 required per assembly) — Replaces: 56681
		128M0204666 - WASHER Note: Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#25	889733	RETAINER THERMOSWITCH (1 required per assembly) — Replaces: 44552
		889733 - Retainer [ More info ] $5.59 Available to Order: Shipping delay up to 10 days.
#26	819110075	SCREW @5 (12 required per assembly)
		10-819110075 - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#27	F692995	COVER CYLINDER HEAD (1 required per assembly)
		1000-F692995 - Cylinder Head Cover [ More info ] $86.22 3 In Stock.
#28	819110062	SCREW (3 required per assembly)
#29	79654	SCREW (14 required per assembly)
		10-79654 - Screw [ More info ] Unavailable
#30	F664914	SEAL THERMOSTAT (1 required per assembly)
		26-F664914 - Seal [ More info ] $22.36 2 In Stock.
#31	8283111	SPACER THERMOSTAT (1 required per assembly)
		23-828311 1 - Spacer [ More info ] $7.09 4 In Stock.
#32	F664068	THERMOSTAT-130 (1 required per assembly)
		F664068 - Thermostat -130 Degrees [ More info ] $41.99 5 In Stock.
#33	F664268	SPRING THERMOSTAT (1 required per assembly)
		24-F664268 - Spring , Thermostat [ More info ] $5.19 3 In Stock.
#34	828319	GASKET THERMOSTAT COVER (1 required per assembly)
		27-828319 - Thermostat Cover Gasket [ More info ] $4.49 8 In Stock.
		18-0854-9 - Gasket 27-828319 2-Pack [ More info ] $8.99 $8.01 Available to Order: Shipping delay up to 10 days.
#35	819693	COVER THERMOSTAT (1 required per assembly)
		819693 - Thermostat Cover [ More info ] Unavailable
#36	19932075	SCREW (With Dri Loc) (4 required per assembly)
		10-19932075 - Screw [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#37	828824238	SCREW (21 required per assembly)
		10-828824238 - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#38	8M0204649	WASHER @10 (21 required per assembly) — Replaces: 29245
		12-8M0204649 - WASHER Note: Priced Individually [ More info ] $1.20 10+ In Stock.
#39	819982A6	MANIFOLD KIT EXHAUST (Painted) (1 required per assembly)
		819982A 6 - Manifold Kit [ More info ] Unavailable
#40	852966	TUBE STRAINER (1 required per assembly) — Replaces: 824947, 834931
		35-852966 - Tube - Strainer [ More info ] Unavailable
#41	8M0204679	PLUG-PIPE (4 required per assembly) — Replaces: 428611
		22-8M0204679 - Exhaust Manifold Pipe Plug [ More info ] $10.99 Available to Order: Shipping delay up to 10 days.
#42	8190354	GASKET EXHAUST (1 required per assembly)
		27-819035 4 - Gasket [ More info ] $75.49 $72.40 10+ In Stock.
#43	F695649	CLAMP BELLOWS (2 required per assembly)
		54-F695649 - Clamp [ More info ] Unavailable
#44	820082	BELLOWS EXHAUST (1 required per assembly)
		820082 - Bellows [ More info ] $98.99 Available to Order: Shipping delay up to 10 days.
#45	53166	LOCKWASHER @5 (Ground Screw) (1 required per assembly)
		13-53166 - LockWasher - Priced Individually [ More info ] $1.80 10+ In Stock.
#46	39349	SCREW @5 (Ground) (1 required per assembly)
		10-39349 - Screw - Priced Individually [ More info ] $1.80 $1.44 10+ In Stock.
