Parts for Mercury 95XR (Jet Drive) Crankshaft & Piston

Revise Search: Mercury Jet Drive & SportJet > 95XR (Jet Drive) > 1996 0E145580 - 0E151579 - USA > Crankshaft & Piston

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Crankshaft & Piston

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	809469A2	GASKET SET POWERHEAD (1 required per assembly)
		27-809469A 2 - Gasket Set [ More info ] $89.99 $76.21 2 In Stock.
#-	818153A66	PH 95 JET 97 (1 required per assembly) — Replaces: 818153A45
		800-818153A66 - PH 95 JET 97,NLA [ More info ] Unavailable
#1	819312T3	CAGE ASSY-40/150 CRANKSHAFT UPPER (1 required per assembly) — Replaces: 819312A3
		1100-819312T 3 - Cage Assembly -40/150, NLA [ More info ] $72.22 $61.17 10+ In Stock.
#2	828626	SEAL UPPER CRANKSHAFT (1 required per assembly)
		26-828626 - Seal [ More info ] $25.89 $17.36 10+ In Stock.
#3	92160	SCREW (5 required per assembly)
		10-92160 - Screw [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#4	91800	KEY WOODRUFF CRANKSHAFT/FLYWHEEL (1 required per assembly)
		28-91800 - Key - Priced Individually [ More info ] $3.05 4 In Stock.
#5	828515T1	C SHAFT ASSY-95J (1 required per assembly) — Replaces: 828515A1
		400-828515T 1 - CrankShaft Assembly -95J, NLA [ More info ] Unavailable
#6	803893T	BEARING-BALL UPPER (1 required per assembly) — Replaces: F284659-2
		30-803893T - Ball Bearing [ More info ] $109.30 4 In Stock.
#7	F748691	GEAR OIL INJECTION (1 required per assembly)
		F748691 - Oil Injection Gear [ More info ] Unavailable
#8	818050T3	BEARING ASSY LOWER (1 required per assembly) — Replaces: 818050A3
		31-818050T 3 - Bearing Assembly [ More info ] $256.58 Available to Order: Shipping delay up to 10 days.
#9	828627	SEAL LOWER CRANKSHAFT (See Note # 1) (1 required per assembly)
		26-828627 - Seal [ More info ] $22.92 $19.81 10+ In Stock.
#10	803604T	BEARING-CTR MAIN CENTER MAIN (2 required per assembly) — Replaces: FA85655-1
		31-803604T - Bearing - Center Main [ More info ] $83.49 $79.92 7 In Stock.
#11	F85410	RING SNAP (2 required per assembly)
		53-F85410 - Ring, Snap, NLA [ More info ] Unavailable
#12	819193	BEARING ASSY (2 required per assembly)
		31-819193 - Bearing Assembly [ More info ] Unavailable
#13	823605	PIN LOCATING (Pressed Into Cylinder Assembly) (3 required per assembly)
		17-823605 - Locating Pin [ More info ] $4.54 10+ In Stock.
#14	F316579	SEAL CRANKCASE (2 required per assembly)
		F316579 - Crankcase Seal [ More info ] $18.09 2 In Stock.
#15	9612A6	CONN ROD ASSY (3 required per assembly) — Replaces: 9612A2, 9612A7
		640-9612A 6 - Connecting Rod Assembly [ More info ] $479.99 Available to Order: Shipping delay up to 10 days.
#16	91012	SCREW (.250-28 SPECIAL) CONN ROD (6 required per assembly)
		10-91012 - Screw - Special - Priced Individually [ More info ] $7.89 4 In Stock.
#17	8M0045428	BEARING KIT ROLLER (3 required per assembly) — Replaces: 17514A2
		31-8M0045428 - 31-8M0045428 - BEARING KIT [ More info ] Unavailable Replaced by -8M0234886
		8M0234886 CAGE BEARING [ More info ] $70.49 $70.25 Available to Order: Shipping delay up to 10 days.
#18	47270	BEARING NEEDLE (87 required per assembly)
		29-47270 - Needle Bearing [ More info ] $0.40 10+ In Stock.
		18-4036-9 - Bearing, 29-47270, 200PK [ More info ] $52.63 Available to Order: Shipping delay up to 10 days.
		29-8M0214934 - BRG-NEEDLE @200 [ More info ] Unavailable
#19	8M0012298	THRUST WASHER THRUST (6 required per assembly) — Replaces: 812876
		12-8M0012298 - Thrust Washer [ More info ] $5.29 6 In Stock.
#20	828304A10	PISTON KIT-STD (Standard) (3 required per assembly) — Replaces: 828304A2, 828304A6
		700-828304A10 - Piston Kit - Std [ More info ] Unavailable
		700-828304A13 - Piston Kit-STD [ More info ] Unavailable
#20	828304A11	PISTON KIT-.015 (.015 Oversize) (OPT required per assembly) — Replaces: 828304A3, 828304A7
		700-828304A11 - Piston Kit-.015 [ More info ] Unavailable
		700-828304A14 - Piston Kit-.015,NLA [ More info ] Unavailable
#20	828304A12	PISTON KIT-.030 (.030 Oversize) (OPT required per assembly) — Replaces: 828304A4, 828304A8
		700-828304A12 - Piston Kit-.030 [ More info ] Unavailable
		700-828304A15 - Piston Kit-.030,NLA [ More info ] Unavailable
#21	857196	LOCK RING LOCK (6 required per assembly) — Replaces: 52035
		53-857196 - Lock Ring - Priced Individually [ More info ] $3.39 $2.72 10+ In Stock.
#22	828564A4	RING SET PISTON (2 Rings) (Standard) (See Note # 2) (3 required per assembly) — Replaces: 828565A1, 828564A1
		39-828564A 4 - Rings - 2 - Standard [ More info ] $62.67 Available to Order: Shipping delay up to 10 days.
#22	828564A5	RING SET PISTON (2 Rings) (.015 Oversize) (See Note # 2) (OPT required per assembly) — Replaces: 828565A2, 828564A2
		39-828564A 5 - Rings - 2-.015 [ More info ] $56.08 $37.70 10+ In Stock.
#22	828564A6	RING SET PISTON (2 Rings) (.030 Oversize) (See Note # 2) (OPT required per assembly) — Replaces: 828565A3, 828564A3
		39-828564A 6 - Rings - 2-.030 [ More info ] Unavailable
