Parts for Mercury 95XR (Jet Drive) Carburetor (Serial # 0E203000 - 0E315904)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 809735A1 | REPAIR KIT CARBURETOR (3 required per assembly) |
  |
|
809735A 1 - Carburetor Repair Kit [ More info ]
|
| #- | 809736A1 | GASKET SET CARBURETOR (3 required per assembly) |
  |
|
27-809736A 1 - Carburetor Gasket Set [ More info ]
|
| #- | 809469A2 | GASKET SET POWERHEAD (1 required per assembly) |
  |
|
27-809469A 2 - Gasket Set [ More info ]
|
| #- | 818153A66 | PH 95 JET 97 (1 required per assembly) — Replaces: 818153A45 |
  |
|
800-818153A66 - PH 95 JET 97,NLA [ More info ] Unavailable |
| #1 | FO10588 | PLUG BODY CHANNEL (3 required per assembly) |
  |
|
19-FO10588 - Plug -cup - Priced Individually [ More info ]
|
| #2 | FO16128 | PLUG BY PASS CHAMBER (1 required per assembly) |
  |
|
19-FO16128 - Plug -cup [ More info ]
|
| #3 | F10319 | TUBE BY PASS (1 required per assembly) |
  |
|
F10319 - Tube, NLA [ More info ] Unavailable |
| #4 | 852077 | ELBOW/FILTER ASSEMBLY (Bottom) (1 required per assembly) |
  |
|
852077 - Elbow/Filter Assembly [ More info ]
|
| #5 | 64706001 | FITTING TEE (Top And Middle) (2 required per assembly) — Replaces: 852078, 64706 |
  |
|
22-64706001 - Fitting [ More info ]
|
| #6 | 820493 | JET (.044) (.044)-IDLE AIR BLEED (1 required per assembly) |
  |
|
820493 - Jet -.044, NLA [ More info ]
|
| #7 | F10265 | NEEDLE INLET (Note: Do Not Remove Inlet Seat) (1 required per assembly) |
  |
|
F10265 - Inlet Needle [ More info ]
|
| #8 | FO13944 | PIN FLOAT (1 required per assembly) |
  |
|
17-FO13944 - Carburetor Float Pin [ More info ]
|
| #9 | FO15623 | GASKET FUEL BOWL (1 required per assembly) |
  |
|
27-FO15623 - Fuel Bowl Gasket [ More info ]
|
| #10 | FO2510 | GASKET FUEL BOWL RETAINING SCREW (2 required per assembly) |
  |
|
27-FO2510 - Fuel Bowl Gasket [ More info ]
|
| #11 | F10333 | BOWL FUEL (Top And Bottom) (1 required per assembly) |
  |
|
F10333 - Fuel Bowl [ More info ]
|
| #12 | 809740 | BOWL FUEL (Middle) (1 required per assembly) |
  |
|
809740 - Fuel Bowl, NLA [ More info ]
|
| #13 | 5128 | SCREW FUEL BOWL RETAINING (1 required per assembly) |
  |
|
1399-5128 - Screw, NLA [ More info ] Unavailable |
| #14 | 891730A01 | FLOAT KIT FUEL BOWL (1 required per assembly) — Replaces: F10346, FO13554 |
  |
|
891730A01 - Float [ More info ]
|
| #15 | F10302 | NOZZLE MAIN (1 required per assembly) |
  |
|
F10302 - Nozzle, NLA [ More info ] Unavailable |
| #16 | 6207 | JET (.072) MAIN FUEL (2500 - 5000 Feet) (Bottom) (OPT required per assembly) |
  |
|
1395-6207 - Jet -.072 [ More info ]
|
| #16 | 6030 | JET (.070) MAIN FUEL (5000 - 7500 Feet) (Bottom) (OPT required per assembly) |
  |
|
1395-6030 - Jet -.070 [ More info ]
|
| #16 | 6029 | JET (.068) MAIN FUEL (7500 - 10000 Feet) (Bottom) (OPT required per assembly) |
  |
|
1395-6029 - Jet -.068 [ More info ]
|
| #16 | 4215 | JET MAIN FUEL (.066) MAIN FUEL (5000 - 10000 Feet) (Top And Middle) (OPT required per assembly) |
  |
|
1399-4215 - Jet -.066 [ More info ]
|
| #16 | 3794 | JET (.074) MAIN FUEL (0 - 2500 Feet) (Bottom) (1 required per assembly) |
  |
|
1399-3794 - Jet -.074 [ More info ]
|
| #17 | F10268 | SCREW IDLE MIXTURE (1 required per assembly) |
  |
|
F10268 - Screw - Idle Mixture Screw [ More info ]
|
| #18 | 27160 | SPRING IDLE MIXTURE SCREW (1 required per assembly) |
  |
|
24-27160 - Spring, Idle Adjusting Screw [ More info ]
|
| #19 | F10305 | SHAFT THROTTLE (1 required per assembly) |
  |
|
F10305 - Throttle Shaft [ More info ] Unavailable |
| #20 | F10334 | SPRING THROTTLE RETURN (1 required per assembly) |
  |
|
24-F10334 - Spring, Throttle Shaft [ More info ]
|
| #21 | 803176 | SCREW-W/PATCH THROTTLE SHUTTER (2 required per assembly) — Replaces: F10328 |
  |
|
10-803176 - Screw [ More info ]
|
| #22 | 820635 | SHUTTER THROTTLE (1 required per assembly) |
  |
|
820635 - Shutter, NLA [ More info ] Unavailable |
| #23 | 830110 | SHAFT THROTTLE ROLLER (Bottom) (1 required per assembly) — Replaces: F333316 |
  |
|
830110 - Roller Shaft, NLA [ More info ]
|
| #24 | 819225 | ROLLER THROTTLE (Bottom) (1 required per assembly) |
  |
|
819225 - Roller, NLA [ More info ]
|
| #25 | 8267094 | NUT @5 (Bottom) (1 required per assembly) — Replaces: F1997 |
  |
|
11-826709 4 - Nut - Priced Individually [ More info ]
|
| #26 | 828925 | GASKET FLANGE (3 required per assembly) |
  |
|
27-828925 - Carburetor Gasket [ More info ]
|
| #27 | 56762 | TIE STRAP @5 (4 required per assembly) |
  |
|
56762 - Tie Strap - Priced Individually [ More info ]
|
| #28 | 7381567 | TUBING-42 INCH (Cut to 3.500 Inch Length) (2 required per assembly) |
  |
|
32-73815 67 - Tubing - 42 Inch [ More info ]
|
| #29 | 21058 | E RING RETAINING (3 required per assembly) |
  |
|
53-21058 - E-Ring, NLA [ More info ] Unavailable |
| #30 | FA85193 | END ASSEMBLY CARB THROTTLE TIE (2 required per assembly) |
  |
|
FA85193 - Bar Assembly - Throttle, NLA [ More info ]
|
| #31 | F1693 | NUT-SS (Tie Bar Retaining) (2 required per assembly) |
  |
|
11-F1693 - Nut (#8-32) [ More info ]
|
| #32 | F1064 | SCREW-SS (2 required per assembly) |
  |
|
10-F1064 - Screw -ss [ More info ]
|
| #33 | FA85511 | BAR ASSY-THROTTLE (1 required per assembly) |
  |
|
FA85511 - Throttle Bar, NLA [ More info ]
|
| #_ | 8266522 | CARBURETOR TOP (WB-122B) (1 required per assembly) |
  |
|
1300-826652 2 - Carburetor-TOP,NLA [ More info ] Unavailable |
| #_ | 8266532 | CARBURETOR MIDDLE (WB-123B) (1 required per assembly) |
  |
|
1300-826653 2 - Carburetor-MIDDL,NLA [ More info ] Unavailable |
| #_ | 8266542 | CARBURETOR BOTTOM (WB-124B) (1 required per assembly) |
  |
|
1300-826654 2 - Carburetor-BOTTO,NLA [ More info ] Unavailable |
