Parts for Mercury 90 (Powerhead) Fuel Pump Assembly

Revise Search: Mercury Jet Drive & SportJet > 90 (Powerhead) > 1995 0E095088 - 0E138324 - Belgium > Fuel Pump Assembly

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Fuel Pump Assembly

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	809469A1	GASKET SET POWERHEAD (1 required per assembly)
		27-809469A 1 - Powerhead Gasket Set [ More info ] $242.75 Available to Order: Shipping delay up to 10 days.
#-	818153A69	POWERHEAD-DRESSED (1 required per assembly) — Replaces: 818153A25
		800-818153A69 - Powerhead-DRESSE,NLA [ More info ] Unavailable
#1	817870A1	COVER KIT FUEL PUMP (With Plug) (1 required per assembly)
		817870A 1 - Fuel Pump Cover Kit, NLA [ More info ] Unavailable
#2	F658803	GASKET SPACER PLATE (1 required per assembly)
		27-F658803 - Fuel Pump Spacer Gasket [ More info ] $3.79 6 In Stock.
#3	79989	NUT (#10-24) STAINLESS STEEL (2 required per assembly)
		11-79989 - Nut (10 - 24) [ More info ] $2.79 10+ In Stock.
#4	F658836	SPACER FUEL PUMP (1 required per assembly)
		F658836 - Fuel Pump Spacer [ More info ] $33.83 10+ In Stock.
#5	820490	GASKET FUEL PUMP (1 required per assembly)
		27-820490 - Fuel Pump Gasket [ More info ] $4.59 10+ In Stock.
#6	F438747	DIAPHRAGM FUEL PUMP (1 required per assembly)
		F438747 - Fuel Pump Diaphragm Only - No Gasket, Priced Individually [ More info ] $9.89 10+ In Stock.
#7	F686096	RETAINER BOOSTER SPRING (1 required per assembly)
		F686096 - Booster Spring Retainer [ More info ] $15.69 Available to Order: Shipping delay up to 10 days.
#8	819843T1	BODY ASSY-F/P FUEL PUMP (1 required per assembly) — Replaces: 819843A1
		819843T 1 - Fuel Pump Body Assembly [ More info ] Unavailable
#9	28430	SCREW (#6-32 X .25) (2 required per assembly)
		10-28430 - Screw [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#10	8M0082362	CHECK VALVE FUEL PUMP (3 required per assembly) — Replaces: F177330
		218M0082362 - Check Valve [ More info ] $9.89 2 In Stock.
#11	F84792	GASKET CENTER VALVE (1 required per assembly)
		27-F84792 - Fuel Pump Valve Gasket [ More info ] $3.39 10+ In Stock.
#12	F686300	SPRING PUMP BOOST (1 required per assembly)
		24-F686300 - Spring [ More info ] Unavailable
#13	89302	WASHER (.203 X .406 X .040) (2 required per assembly)
		12-89302 - Washer (.203 X .406 X .040) [ More info ] $1.80 10+ In Stock.
#14	19930075	SCREW (#10-24 X .75) (With Dri Loc) (2 required per assembly)
		10-19930075 - Screw, NLA [ More info ] Unavailable
#15	26992	LOCKWASHER (.250) STAINLESS STEEL (4 required per assembly)
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#16	F1504	SCREW (.250-20 X 1.250) (4 required per assembly)
		10-F1504 - Screw -ss [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#17	F695801	FITTING (1 required per assembly)
		22-F695801 - Fitting [ More info ] Unavailable
#18	823606	GASKET FUEL PUMP BOWL (1 required per assembly)
		27-823606 - Fuel Bowl Gasket [ More info ] $14.89 5 In Stock.
#19	F438653	SCREEN FUEL PUMP (1 required per assembly)
		35-F438653 - Screen [ More info ] $10.69 7 In Stock.
#20	852368	SCREW (#10-24 X .750) (1 required per assembly) — Replaces: 56682
		10-852368 - Screw [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#21	98254	SCREW (3 required per assembly)
		10-98254 - Screw [ More info ] $0.60 Available to Order: Shipping delay up to 10 days.
#22	F695500	BOWL SEDIMENT (1 required per assembly)
		F695500 - Fuel Pump Bowl, NLA [ More info ] $47.92 10+ In Stock.
#23	F743314	ELBOW RECIRCULATING (1 required per assembly)
		22-F743314 - Elbow [ More info ] Unavailable
#24	820500A3	GASKET KIT FUEL PUMP (1 required per assembly) — Replaces: 820500
		27-820500A 3 - Gasket Kit [ More info ] $17.67 3 In Stock.
		18-0869-9 - Gasket 27-F40223 2-Pack [ More info ] $19.99 $19.30 Available to Order: Shipping delay up to 10 days.
#25	78968	LOCKWASHER @5 (Ground Screw) (2 required per assembly)
		13-78968 - LockWasher - Priced Individually [ More info ] $1.80 10+ In Stock.
#26	28636	SCREW @5 (Ground Wire) (1 required per assembly)
		10-28636 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#_	820581A1	PUMP KIT-FUEL (Complete) (1 required per assembly)
		820581A 1 - Fuel Pump Kit,NLA [ More info ] Unavailable
