Parts for Mercury 90 (Jet Drive) Turn Key Start Kit (Page 1 of 3)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 116453 | REED BLOCK (3 required per assembly) — Replaces: 116451, 116452 |
  |
11645 3 - REED BLOCK ASSY [ More info ] Unavailable |
|
  |
11645T 3 - REED BLOCK ASSY [ More info ] Unavailable |
|
  |
855952T - Reed Block Assembly [ More info ] Unavailable |
|
  |
|
855952T 3 - Reed Block Assembly [ More info ]
|
| #2 | F85168-2 | GASKET TOP (1 required per assembly) |
  |
|
27-F85168-2 - Reed Plate Adapter Gasket [ More info ]
|
| #3 | 819733 | GASKET CENTER/BOTTOM (2 required per assembly) |
  |
|
27-819733 - Reed Plate Adapter Gasket [ More info ]
|
| #4 | 8197351 | ADAPTER REED PLATE (1 required per assembly) |
  |
|
819735 1 - Adapter, NLA [ More info ]
|
| #5 | F85159-1 | GASKET INTAKE MANIFOLD (1 required per assembly) |
  |
|
27-F85159-1 - 27-F85159-1 - GASKET [ More info ] Unavailable Replaced by 27-F85159-1 |
| #6 | 825195A3 | MANIFOLD ASSEMBLY INTAKE (1 required per assembly) |
  |
|
825195A 3 - Manifold Assembly [ More info ] Unavailable |
| #7 | 8267611 | ELBOW (1 required per assembly) — Replaces: 826761 |
  |
|
22-826761 1 - Elbow [ More info ]
|
| #8 | 14868 | FITTING (2 required per assembly) |
  |
|
22-14868 - Fitting [ More info ]
|
| #9 | F433209-1 | STUD (.250-20 X 1.250) (1 required per assembly) |
  |
|
16-F433209-1 - Stud [ More info ]
|
| #10 | 8263881 | STUD (6 required per assembly) — Replaces: 826388, F40209 |
  |
|
16-826388 1 - Stud, NLA [ More info ]
|
| #11 | 828925 | GASKET CARBURETOR (3 required per assembly) |
  |
|
27-828925 - Carburetor Gasket [ More info ]
|
| #12 | 8M0204668 | NUT (.312-18) (6 required per assembly) — Replaces: 68292 |
  |
|
11-8M0204668 - NUT @5 [ More info ] Unavailable |
| #13 | 819110100 | SCREW (.250-20 X 1.00) (8 required per assembly) |
  |
|
10-819110100 - Screw [ More info ]
|
| #14 | 819110150 | SCREW (.250-20 X 1.500) (6 required per assembly) |
  |
|
10-819110150 - Screw, NLA [ More info ] Unavailable |
| #15 | 819110125 | SCREW (.250-20 X 1.250) (4 required per assembly) |
  |
|
10-819110125 - Screw [ More info ] Unavailable |
| #16 | F289446-1 | CLAMP FUEL HOSE (1 required per assembly) |
  |
54-F289446-1 - CLAMP,NLA [ More info ] Unavailable |
|
| #17 | 8M0024808 | J-CLIP WIRE HARNESS (1 required per assembly) — Replaces: 65292 |
  |
|
54-8M0024808 - J-CLIP [ More info ] Unavailable |
| #18 | F698772 | CLAMP WORM GEAR (6 required per assembly) |
  |
|
54-F698772 - Clamp [ More info ]
|
| #19 | 82722881 | HOSE (38.00 INCHES BULK) (Cut to 3.500 Inch Length) (2 required per assembly) |
  |
|
32-827228 81 - Hose-38 INCH [ More info ] Unavailable |
| #20 | 82722881 | HOSE (38.00 INCHES BULK) (1 required per assembly) |
| #21 | 8M0108355 | HOSE (57 INCHES BULK) (Cut to 4.500 Inch Length) (1 required per assembly) — Replaces: 830756109, 8M0047428 |
  |
|
32-8M0108355 - Hose, 57 Inch [ More info ]
|
| #22 | 815504104 | CLAMP WORM GEAR (6 required per assembly) |
  |
|
54-815504104 - Clamp [ More info ]
|
| #23 | 830760 | HOSE MOLDED (TOP) (1 required per assembly) |
  |
|
32-830760 - Molded Hose [ More info ]
|
| #24 | 814329T6 | AUTO ENRICHNER (1 required per assembly) — Replaces: 8143296 |
  |
|
814329T 6 - Auto Enrichener [ More info ]
|
| #25 | 830766 | HOSE MOLDED (BOTTOM) (1 required per assembly) |
  |
|
32-830766 - Molded Hose, NLA [ More info ] Unavailable |
| #26 | 82724316 | HOSE (4.750 INCHES BULK) (1 required per assembly) |
  |
|
32-827243 16 - Hose -4.750 Inch [ More info ] Unavailable |
| #27 | 65567 | WASHER (.265 X .750 X .048) STAINLESS STEEL (4 required per assembly) |
  |
|
12-65567 - Washer, (.265 X .750 X .048) Stainless Steel [ More info ]
|
| #28 | 826750 | BRACKET AUTO ENRICHER (1 required per assembly) |
  |
|
826750 - Bracket, NLA [ More info ] Unavailable |
| #29 | 90329 | GROMMET (2 required per assembly) |
  |
|
25-90329 - Grommet, Bracket [ More info ]
|
| #30 | 42116 | BUSHING (2 required per assembly) |
  |
|
23-42116 - Bushing [ More info ]
|
| #31 | 40011130 | SCREW (M6 X 30) STAINLESS STEEL (2 required per assembly) |
  |
|
10-40011130 - Screw [ More info ]
|
| #32 | 816311T | TIE STRAP (8.00 INCHES) (2 required per assembly) — Replaces: 816311 |
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #33 | 831262A1 | HARNESS ASSEMBLY [0E023150] THRU [0E033710] (1 required per assembly) |
  |
|
84-831262A 1 - Harness Assembly, NLA [ More info ] Unavailable |
| #33 | 831262A2 | HARNESS ASSEMBLY [0E033711] THRU [0E095087] (1 required per assembly) |
  |
|
84-831262A 2 - Harness Assembly, NLA [ More info ] Unavailable |
| #_ | 830883A3 | RETRO KIT-TKS (1 required per assembly) — Replaces: 830883A1 |
  |
|
830883A 3 - Retro Kit -tks, NLA [ More info ] Unavailable |
| #_ | 830883A2 | RETRO KIT-TKS (1 required per assembly) |
  |
|
830883A 2 - RETRO KIT-TKS,NLA [ More info ] Unavailable |
