Parts for Mercury 240 EFI M2 Jet Drive (Powerhead) Cylinder Head Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 885214A1 | GASKET/SEAL SET POWERHEAD - NOTE: See Gasket/Seal Set - Powerhead Section For Parts Breakdown (1 required per assembly) |
  |
|
27-885214A 1 - Powerhead Gasket Set [ More info ]
|
| #- | 858961T30 | PH SJ 240 EFI [0E414100] & Up (1 required per assembly) — Replaces: 858961A26 |
  |
|
884-858961T30 - Powerhead Sj 240 Efi [ More info ] Unavailable |
| #1 | 858281A11 | CYLINDER HEAD KIT ALSO INCLUDES REF NO 22 (2 required per assembly) |
  |
|
858281A11 - Cylinder Head Kit [ More info ]
|
| #2 | 8M0149612 | SEAL CYLINDER HEA CYLINDER HEAD (2 required per assembly) — Replaces: 8584521 |
  |
|
258M0149612 - Seal CYLINDER HEA [ More info ]
|
| #3 | 8597721 | SEAL CYLINDER BORE (6 required per assembly) |
  |
|
|
| #4 | 35126 | O-RING (.859 X .139) (2 required per assembly) |
  |
|
25-35126 - O-ring, (.859 X .139) [ More info ]
|
| #5 | 8591001 | PLUG ASSEMBLY (M10 X 1.5) BRASS (2 required per assembly) |
  |
|
22-859100 1 - Plug Assembly [ More info ]
|
| #6 | 627021 | O-RING (.301 X .070) (2 required per assembly) — Replaces: 62702 |
  |
|
25-62702 1 - O-Ring [ More info ]
|
| #7 | 8M0125882 | SCREW (24 required per assembly) — Replaces: 878217 |
  |
|
108M0125882 - Screw [ More info ]
|
| #8 | 63779 | PIN-DOWEL @3 (4 required per assembly) |
  |
|
17-63779 - Pin, Dowel (.250 X .625) [ More info ]
|
| #9 | 90390A1 | COVER KIT-THERMO (2 required per assembly) |
  |
|
90390A 1 - Thermostat Cover Kit [ More info ]
|
| #10 | 40011149 | SCREW (4 required per assembly) |
  |
|
10-40011149 - Screw [ More info ]
|
| #11 | 687271 | FITTING (1 required per assembly) |
  |
|
22-68727 1 - Fitting [ More info ]
|
| #12 | F698772 | CLAMP (2 required per assembly) |
  |
|
54-F698772 - Clamp [ More info ]
|
| #13 | 77653101 | HOSE (48.00 INCHES BULK) CUT 12.750 INCHES (1 required per assembly) |
  |
|
32-77653101 - Hose -48 Inch [ More info ]
|
| #14 | 68728 | FITTING (1 required per assembly) |
  |
|
22-68728 - Fitting [ More info ] Unavailable |
| #15 | F698772 | CLAMP (1 required per assembly) |
| #16 | BOATPART | SEE BOAT MANUFACTURER HOSE - TO THRU HULL FITTING (1 required per assembly) |
  |
|
BOATPART - SEE BOAT MANUFACT [ More info ] Unavailable |
| #17 | 87810178 | SCREW (2 required per assembly) |
  |
|
10-878101 78 - Screw [ More info ]
|
| #18 | 4002319 | WASHER @3 (2 required per assembly) |
  |
|
12-40023 19 - Washer (M10) [ More info ]
|
| #19 | 8M6003194 | SENSOR-KNOCK (2 required per assembly) — Replaces: 878187 |
  |
|
8M6003194 - Knock Sensor [ More info ]
|
| #20 | 882841 | ADAPTER KNOCK SENSOR (2 required per assembly) |
  |
|
882841 - Adaptor [ More info ]
|
| #21 | 889575 | SENSOR ASSY-TEMP - Design I [0E406400] THRU [0E418555] (2 required per assembly) — Replaces: 858535 |
  |
889575 - Temperature Sensor Assembly [ More info ] Unavailable |
|
  |
|
8M0214984 - Exhaust Temperature Sensor [ More info ]
|
| #21 | 8M0148668 | SENSOR ASSEMBLY TEMPERATURE - Design II [0E418556] & Up (2 required per assembly) — Replaces: 885342001, 885342002 |
  |
|
8M0148668 - Temperature Sensor [ More info ]
|
| #22 | 627021 | O-RING (.301 X .070) - Design I [0E406400] THRU [0E418555] (2 required per assembly) |
| #22 | 896699 | O-RING (1.78 MM X .08 MM) - Design II [0E418556] & Up (2 required per assembly) — Replaces: 888814 |
  |
|
25-896699 - O-ring, (1.78 Mm X .08 Mm) [ More info ]
|
