Parts for Mercury 120XR2 (Jet Drive) Pinion & Impeller Shaft

Revise Search: Mercury Jet Drive & SportJet > 120XR2 (Jet Drive) > 2000 0E369300 - 0E379999 - USA > Pinion & Impeller Shaft

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Pinion & Impeller Shaft

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	803834A1	SEAL/GASKET SET DRIVE HOUSING (1 required per assembly)
		26-803834A 1 - SEAL/Gasket Set [ More info ] Unavailable
#-	859609A8	HSG-COMP 120XR SJ DRIVE (Complete) (Painted) (No Impeller) (1 required per assembly) — Replaces: 854668A6
		859609A 8 - HSG-COMP 120XR S,NLA [ More info ] Unavailable
#1	30271	RING RUBBER RUBBER (1 required per assembly)
		25-30271 - Ring - Priced Individually [ More info ] Unavailable
		18-7426-9 - O-Ring (PK2) 25-30271 [ More info ] $4.39 Available to Order: Shipping delay up to 10 days.
		25-8M0214918 - WATER PUMP HSG RUBBER RING O/B [ More info ] $1.99 9 In Stock.
#2	4010725	SCREW (4 required per assembly)
		10-40107 25 - Screw [ More info ] $5.79 Available to Order: Shipping delay up to 10 days.
#3	830748A1	HOUSING ASSEMBLY PINION SHAFT (Painted) (1 required per assembly)
		1100-830748A 1 - Housing Assembly [ More info ] $339.99 Available to Order: Shipping delay up to 10 days.
#4	826210	SEAL PINION SHAFT HOUSING (2 required per assembly)
		26-826210 - Seal [ More info ] $24.49 4 In Stock.
#5	820292	BEARING BALL BALL (1 required per assembly)
		30-820292 - Ball Bearing [ More info ] $68.99 Available to Order: Shipping delay up to 10 days.
#6	38356A1	BEARING SET (Cup And Cone) (1 required per assembly)
		31-38356A 1 - Tapered Roller Bearing [ More info ] $95.49 $91.68 9 In Stock.
#7	54030	O-RING (2.987 X .103) (1 required per assembly)
		25-54030 - O-ring, (2.987 X .103) [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#8	878129002	SHIM-.002 RED (AR required per assembly) — Replaces: 831951002
		15-878129002 - Shim -.002 [ More info ] $16.19 Available to Order: Shipping delay up to 10 days.
#8	878129004	SHIM-.004 BEIGE (AR required per assembly) — Replaces: 831951004
		15-878129004 - Shim -.004 [ More info ] $15.59 Available to Order: Shipping delay up to 10 days.
#8	878129005	SHIM-.005 BLUE (AR required per assembly) — Replaces: 831951005
		15-878129005 - Shim -.005 [ More info ] $15.49 1 In Stock.
#8	878129007	SHIM-.0075 FROST (AR required per assembly) — Replaces: 831951007
		15-878129007 - Shim -.0075 [ More info ] $15.89 Available to Order: Shipping delay up to 10 days.
#8	878129010	SHIM-.010 BROWN (AR required per assembly) — Replaces: 831951010
		15-878129010 - Shim -.010 [ More info ] $16.39 Available to Order: Shipping delay up to 10 days.
#9	857013T	GEAR/SHAFT ASSEMBLY PINION (1 required per assembly)
		43-857013T - Gear And Shaft Assembly [ More info ] Unavailable
#10	888499T	SHAFT IMPELLER (1 required per assembly) — Replaces: 835366T
		44-888499T - Impeller Shaft [ More info ] $477.99 Available to Order: Shipping delay up to 10 days.
#11	830901	GEAR IMPELLER SHAFT (1 required per assembly)
		43-830901 - Impeller Gear [ More info ] $224.99 Available to Order: Shipping delay up to 10 days.
#12	832812	WASHER (1 required per assembly)
		12-832812 - Washer [ More info ] $11.09 Available to Order: Shipping delay up to 10 days.
#13	818591	NUT (1 required per assembly)
		11-818591 - Nut (M14) [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#14	878130002	SHIM-.002 RED (AR required per assembly) — Replaces: 831950002
		15-878130002 - Shim -.002 [ More info ] $14.89 Available to Order: Shipping delay up to 10 days.
#14	878130004	SHIM-.004 BEIGE (AR required per assembly) — Replaces: 831950004
		15-878130004 - Shim -.004 [ More info ] Unavailable
#14	878130005	SHIM-.005 BLUE (AR required per assembly) — Replaces: 831950005
		15-878130005 - Shim -.005 [ More info ] $14.89 $11.92 2 In Stock.
#14	878130007	SHIM-.0075 FROST (AR required per assembly) — Replaces: 831950007
		15-878130007 - Shim -.0075 [ More info ] $5.29 $4.24 2 In Stock.
#14	878130010	SHIM-.010 BROWN (AR required per assembly) — Replaces: 831950010
		15-878130010 - Shim -.010 [ More info ] Unavailable
#15	830878A1	COVER ASSEMBLY IMPELLER SHAFT (Painted) (1 required per assembly)
		830878A 1 - Cover Assembly [ More info ] $436.49 Available to Order: Shipping delay up to 10 days.
#16	38356A1	BEARING SET (Cup And Cone) (1 required per assembly)
#17	841807	O-RING (3.500 X .103) (1 required per assembly)
		25-841807 - O-ring, (3.500 X .103) [ More info ] $5.79 5 In Stock.
#18	4010725	SCREW (4 required per assembly)
