Parts for Mercury 120XR2 (Jet Drive) Fuel Pump Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 809817A1 | GASKET SET POWERHEAD (1 required per assembly) |
  |
|
27-809817A 1 - Powerhead Gasket Set [ More info ]
|
| #- | 818154R52 | PH 120XR2 SJ -RM (1 required per assembly) — Replaces: 818154A52 |
  |
|
800-818154R52 - PH 120XR2 SJ -RM [ More info ] Unavailable |
| #1 | 819759T1 | COVER-FUEL PUMP FUEL PUMP (1 required per assembly) — Replaces: 8197591 |
  |
|
819759T 1 - Fuel Pump Cover, NLA [ More info ]
|
| #2 | F658803 | GASKET SPACER PLATE (1 required per assembly) |
  |
|
27-F658803 - Fuel Pump Spacer Gasket [ More info ]
|
| #3 | F7009 | NUT (#10-24) (2 required per assembly) |
  |
|
11-F7009 - Nut, (#10-24) [ More info ] Unavailable |
| #4 | F658836 | SPACER FUEL PUMP (1 required per assembly) |
  |
|
F658836 - Fuel Pump Spacer [ More info ]
|
| #5 | 820490 | GASKET FUEL PUMP (1 required per assembly) |
  |
|
27-820490 - Fuel Pump Gasket [ More info ]
|
| #6 | F438747 | DIAPHRAGM FUEL PUMP (1 required per assembly) |
  |
|
F438747 - Fuel Pump Diaphragm Only - No Gasket, Priced Individually [ More info ]
|
| #7 | F686096 | RETAINER BOOSTER SPRING (1 required per assembly) |
  |
|
F686096 - Booster Spring Retainer [ More info ] Unavailable |
| #8 | F686300 | SPRING PUMP BOOST (1 required per assembly) |
  |
|
24-F686300 - Spring [ More info ] Unavailable |
| #9 | 819843T1 | BODY ASSY-F/P FUEL PUMP (1 required per assembly) — Replaces: 819843A1 |
  |
|
819843T 1 - Fuel Pump Body Assembly [ More info ] Unavailable |
| #10 | 28430 | SCREW (#6-32 X .25) (2 required per assembly) |
  |
|
10-28430 - Screw [ More info ]
|
| #11 | 8M0082362 | CHECK VALVE FUEL PUMP (3 required per assembly) — Replaces: F177330 |
  |
|
218M0082362 - Check Valve [ More info ]
|
| #12 | F84792 | GASKET CENTER VALVE (1 required per assembly) |
  |
|
27-F84792 - Fuel Pump Valve Gasket [ More info ]
|
| #13 | 88865 | SCREW (#10-24 X .750) STAINLESS STEEL (2 required per assembly) |
  |
|
10-88865 - Screw [ More info ] Unavailable |
| #14 | 26992 | LOCKWASHER (.250) STAINLESS STEEL (4 required per assembly) |
  |
|
13-26992 - LockWasher - Priced Individually [ More info ]
|
| #15 | F1504 | SCREW (.250-20 X 1.250) (4 required per assembly) |
  |
|
10-F1504 - Screw -ss [ More info ]
|
| #16 | F695801 | FITTING (1 required per assembly) |
  |
|
22-F695801 - Fitting [ More info ] Unavailable |
| #17 | 823606 | GASKET FUEL PUMP BOWL (1 required per assembly) |
  |
|
27-823606 - Fuel Bowl Gasket [ More info ]
|
| #18 | F438653 | SCREEN FUEL PUMP (1 required per assembly) |
  |
|
35-F438653 - Screen [ More info ]
|
| #19 | F695500 | BOWL SEDIMENT (1 required per assembly) |
  |
|
F695500 - Fuel Pump Bowl, NLA [ More info ]
|
| #20 | 88865 | SCREW (#10-24 X .750) STAINLESS STEEL (1 required per assembly) |
| #21 | 819110062 | SCREW (4 required per assembly) |
  |
|
10-819110062 - Screw [ More info ]
|
| #22 | 8205002 | GASKET FUEL PUMP (1 required per assembly) |
  |
|
27-820500 2 - Gasket [ More info ]
|
| #23 | 8M0108355 | HOSE-57 INCH (Cut to 4.500 Inch Length) (1 required per assembly) — Replaces: 830756109, 8M0047428 |
  |
|
32-8M0108355 - Hose, 57 Inch [ More info ]
|
| #24 | 82722881 | HOSE-38 INCH (1 required per assembly) |
  |
|
32-827228 81 - Hose-38 INCH [ More info ] Unavailable |
| #25 | F698772 | CLAMP (2 required per assembly) |
  |
|
54-F698772 - Clamp [ More info ]
|
| #26 | 816311T | TIE STRAP @100 (2 required per assembly) — Replaces: 816311 |
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #27 | F698772 | CLAMP (3 required per assembly) |
| #28 | 83192377 | HOSE-30 INCH (Cut As Required) (1 required per assembly) |
  |
|
32-831923 77 - Hose -30 Inch [ More info ] Unavailable |
| #29 | 8267096 | NUT (2 required per assembly) — Replaces: 34059 |
  |
|
11-826709 6 - Nut [ More info ]
|
| #30 | 852503 | PLATE PUMP MOUNT (1 required per assembly) |
  |
|
852503 - Pump Mount Plate [ More info ] Unavailable |
| #31 | 8318701 | BUSHING (6 required per assembly) |
  |
|
23-831870 1 - Bushing [ More info ]
|
| #32 | 834985 | GROMMET @5 (3 required per assembly) |
  |
25-834985 - Grommet [ More info ] Unavailable |
|
  |
|
25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ]
|
| #33 | 35462 | WASHER @2 (3 required per assembly) |
  |
|
12-35462 - Washer, (.2656 X .625 X .0625) Stainless Steel [ More info ]
|
| #34 | 82130050 | SCREW (3 required per assembly) |
  |
|
10-821300 50 - Screw [ More info ]
|
| #35 | 852523 | ELBOW (1 required per assembly) |
  |
|
22-852523 - Elbow [ More info ]
|
| #36 | 852521T1 | PUMP ASSEMBLY FUEL - ELECTRIC ELECTRIC (1 required per assembly) — Replaces: 852521A1 |
  |
|
852521T 1 - Pump Assembly -elec [ More info ]
|
| #37 | 72761 | WASHER (2 required per assembly) |
  |
|
12-72761 - Washer, (.203 X .562 X .060) Stainless Steel [ More info ]
|
| #38 | 32228 | SCREW @3 (2 required per assembly) |
  |
|
10-32228 - Screw - Priced Individually [ More info ]
|
| #39 | 889615T | FILTER-FUEL (1 required per assembly) — Replaces: 852546T, 889615 |
  |
|
35-889615T - Fuel Filter [ More info ]
|
| #40 | 852527A1 | HARNESS ASSEMBLY FUEL PUMP (1 required per assembly) |
  |
|
84-852527A 1 - Harness Assembly [ More info ]
|
| #41 | 852526 | FUSE MINI - VIOLET - 3 AMPERE (1 required per assembly) |
  |
|
88-852526 - Fuse - 3 Amp-violet [ More info ]
|
| #42 | 828054 | COVER FUSE FUSE HOLDER (1 required per assembly) |
  |
|
828054 - Fuse Cover [ More info ]
|
| #43 | 816311T | TIE STRAP @100 (2 required per assembly) — Replaces: 816311 |
| #44 | 401366 | NUT @5 (3 required per assembly) — Replaces: 400264 |
  |
|
11-40136 6 - Nut - Priced Individually [ More info ]
|
| #_ | 817870T6 | PUMP ASSY-FUEL FUEL (1 required per assembly) — Replaces: 817870A6 |
  |
|
817870T 6 - PUMP ASY-FUEL,SEE NOTE [ More info ] Unavailable |
| #NS | 828547253 | CONDUIT (.250 INSIDE DIAMETER X 3.00 FEET BULK) (Cut As Required) (AR required per assembly) |
  |
|
32-828547253 - Conduit (.250 Inside Di [ More info ]
|
