Mercury Marine Gen-I Digital Console Mount Remote Controls & Components Remote Control-DTS Slim Binnacle (Design II)

Revise Search: Accessories 1994 & Up > Remote Controls & Components > Console Mount > Digital > Gen-I > 2002-2021 > Remote Control-DTS Slim Binnacle (Design II)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Remote Control-DTS Slim Binnacle (Design II)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0079291	ERC-SLM CNSL TRIM (1 required per assembly)
		8M0079291 - Remote Control Si [ More info ] $1,374.53 Available to Order: Shipping delay up to 10 days.
#-	8M0079290	ERC-SLM CNSL NTRM (1 required per assembly)
		8M0079290 - Remote Control Si [ More info ] Unavailable
#1	8M0080010	HANDLE ASSEMBLY ERC SLIM WITH TRIM (BLACK/CHROME) INCLUDES TRIM SWITCH ASSEMBLY (1 required per assembly)
		8M0080010 - Handle-SLIM W/TRM [ More info ] $384.47 Available to Order: Shipping delay up to 10 days.
#2	8M0101755	TRIM SWITCH ASSEMBLY SLIM ERC (1 required per assembly)
		878M0101755 - Trim Switch - Slim [ More info ] $92.41 Available to Order: Shipping delay up to 10 days.
#3	58376	SCREW (.164-18 X .375) (1 required per assembly)
		10-58376 - Screw [ More info ] $1.23 $1.18 9 In Stock.
#4	8M0080013	HANDLE COVER PORT WITH TRIM- CHROME (1 required per assembly)
		8M0080013 - Trim Handle, Port [ More info ] Unavailable
#5	40011148	SCREW (M8 X 20) (1 required per assembly)
		10-40011148 - Screw - Priced Individually [ More info ] Unavailable
		10-8M0214929 - SCREW @2 [ More info ] Unavailable
#6	8M0080011	HANDLE ASSEMBLY ERC SLIM W/O TRIM (BLACK/CHROME) (1 required per assembly)
		8M0080011 - Handle Assembly SLIM [ More info ] Unavailable
#7	58376	SCREW (.164-18 X .375) (1 required per assembly)
#8	40011148	SCREW (M8 X 20) (1 required per assembly)
#9	8M0080012	HANDLE COVER PORT W/O TRIM- CHROME (1 required per assembly)
		8M0080012 - Trim Handle, Port [ More info ] $32.96 Available to Order: Shipping delay up to 10 days.
#10	NSS	NOT SOLD SEPARATE HANDLE-NON TRIM SLIM ERC (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#11	8M0080016	ERC CAN PAD ASSEMBLY SLIM (1 required per assembly)
		878M0080016 - ERC CAN PAD Assembly [ More info ] $204.67 Available to Order: Shipping delay up to 10 days.
#12	8M0080170	SIDE TRIM COVER SLIM ERC PORT (1 required per assembly)
		8M0080170 - Side Cover PORT [ More info ] $19.58 Available to Order: Shipping delay up to 10 days.
#13	8M0080091	MID COVER SLIM ERC (1 required per assembly)
		8M0080091 - Cover-ERC MID SLM [ More info ] $29.79 Available to Order: Shipping delay up to 10 days.
#14	8M0080171	SIDE TRIM COVER SLIM ERC STBD (1 required per assembly)
		8M0080171 - Side Cover Stbd [ More info ] $19.58 Available to Order: Shipping delay up to 10 days.
#15	8M6001063	DECAL M-ICON (1 required per assembly)
		378M6001063 - Decal-M ICON [ More info ] $7.52 Available to Order: Shipping delay up to 10 days.
#16	8M0069457	PLUG ERC ADJUSTMENT (2 required per assembly)
		198M0069457 - Plug , Priced Individually [ More info ] $1.92 Available to Order: Shipping delay up to 10 days.
#17	4001987	SCREW (M4 X 16) (2 required per assembly)
		10-40019 87 - Screw [ More info ] $1.80 5 In Stock.
#18	8M0080085	SIDE COVER SLIM ERC (BLACK) (1 required per assembly)
		8M0080085 - Side Cover PORT [ More info ] $13.77 Available to Order: Shipping delay up to 10 days.
#19	877724A02	MODULE ASSEMBLY SHIFT AND THROTTLE (1 required per assembly)
		877724A02 - Module Assembly - Control [ More info ] $275.71 Available to Order: Shipping delay up to 10 days.
#20	4008860	SCREW (M6 X 60) (2 required per assembly)
		10-40088 60 - Screw [ More info ] $0.90 Available to Order: Shipping delay up to 10 days.
#21	NSS	NOT SOLD SEPARATE ERC MOUNT BRACKET (1 required per assembly)
#22	8M0080086	BASE HOUSING ASSEMBLY SLIM ERC (1 required per assembly)
		8M0080086 - Base-ERC SLIM [ More info ] $23.68 Available to Order: Shipping delay up to 10 days.
#23	69570	SCREW (#10-16 X .750) (4 required per assembly)
		10-69570 - Screw [ More info ] $1.80 7 In Stock.
#24	8M0070490	GASKET SLIM ERC HOUSING (1 required per assembly)
		278M0070490 - Gasket -Base Housing [ More info ] Unavailable
#25	19674A07	SWITCH/LANYARD KIT (1 required per assembly)
		87-19674A07 - Switch/Lanyard Kit Ob [ More info ] $85.93 Available to Order: Shipping delay up to 10 days.
#26	18303	SCREW (.190-16 X 1.750) STAINLESS STEEL (2 required per assembly)
		10-18303 - Screw [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#27	133982	SWITCH ASSEMBLY STOP (1 required per assembly)
		87-13398 2 - Switch [ More info ] $67.17 Available to Order: Shipping delay up to 10 days.
#28	NSS	NOT SOLD SEPARATE SWITCH PLATE (1 required per assembly)
#29	879925	WASHER (52 MM) (1 required per assembly)
		12-879925 - Washer -52MM - Priced Individually [ More info ] $3.14 $2.99 3 In Stock.
#30	18321	CLAMP MOUNTING (1 required per assembly)
		18321 - Clamp [ More info ] $7.19 Available to Order: Shipping delay up to 10 days.
#31	24676	WASHER (.200 X .440 X .032) (2 required per assembly)
		12-24676 - Washer, (.200 X .440 X .032) [ More info ] $1.50 10+ In Stock.
#32	68219	NUT (#10-32) STAINLESS STEEL (4 required per assembly)
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#33	8M0032846	RETAINER BRASS (1 required per assembly)
		8M0032846 - Brass Retainer [ More info ] $4.61 Available to Order: Shipping delay up to 10 days.
#34	623594	INSULATOR (2.00 INCH) (1 required per assembly)
		85-62359 4 - Insulator [ More info ] $0.40 $0.32 10 In Stock.
#35	32866	SCREW (#10-32 X 2.00) STAINLESS STEEL (2 required per assembly)
		10-32866 - Screw - Priced Individually [ More info ] $1.70 $0.34 10+ In Stock.
#36	15920Q54	LANYARD ASSEMBLY (1 required per assembly)
		15920Q54 - Stop Switch Lanyard- Priced Individually [ More info ] Unavailable
#37	27164	NUT AND LOCKWASHER (#10-32) (1 required per assembly)
		11-27164 - Nut And Lockwasher (#10-32) [ More info ] $1.00 1 In Stock.
#38	24231	SCREW (#10-32 X .250) (1 required per assembly)
		10-24231 - Screw - Priced Individually [ More info ] $1.10 $0.88 5 In Stock.
#39	11149A3	CABLE ASSEMBLY (1 required per assembly)
		84-11149A 3 - Cable Assembly [ More info ] $4.69 1 In Stock.
#40	816311T	TIE STRAP (8.00 INCHES) (7 required per assembly)
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#41	79146	RETAINER (1 required per assembly)
		79146 - Retainer [ More info ] $5.59 2 In Stock.
#42	8M0087765	DECAL LANYARD, WHITE (1 required per assembly)
		568M0087765 - Decal-Lanyard WHT [ More info ] $3.11 1 In Stock.
#43	4008840	SCREW (M6 X 40) (4 required per assembly)
		10-40088 40 - Screw [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#44	4002316	WASHER (6.60 X 17.0 X 1.5SS) (4 required per assembly)
		12-40023 16 - Washer - Priced Individually [ More info ] $1.17 2 In Stock.
		128M0214930 - WASHER Note: Must be ordered in multiples of 5 [ More info ] $1.00 1 In Stock.
#45	401386	NUT (M6) STAINLESS STEEL (4 required per assembly)
		11-40138 6 - Nut - Priced Individually [ More info ] $5.09 9 In Stock.
#46	88849025	WRENCH ALLEN (2.5 MM) (1 required per assembly)
		91-888490 25 - Wrench-allen [ More info ] Unavailable
#47	88849050	WRENCH ALLEN (5.0 MM) (1 required per assembly)
		91-888490 50 - Wrench-allen 5.0 [ More info ] Unavailable
#48	8M0123449	ADAPTER HARNESS Application for Diesel Tier II Sterndrive DTS, 4.2 I6 & 2.8 I4 (AR required per assembly)
		848M0123449 - Adapter Harness [ More info ] $42.02 Available to Order: Shipping delay up to 10 days.
#NS	877771	NYLINER FLANGED (1 required per assembly)
		23-877771 - NyLiner [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#NS	877736	SENSOR THROTTLE/SHIFT (1 required per assembly)
		82-877736 - Sensor -Throttle/Shft [ More info ] Unavailable
