Parts for 900 Sc Dry Sump 8.8L (540 Cu In) V8 MerCruiser Engines - Gas Starter Motor & Alternator
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 808011A05 | STARTER MOTOR ASY - NOTE: See Starter Motor Components Section For Parts Breakdown (1 required per assembly) — Replaces: 808011A1, 808011A4 |
  |
|
50-808011A05 - Starter Motor Assembly [ More info ]
|
  |
|
18-5911 - Starter, 60-5119 [ More info ]
|
  |
|
18-5908 - Starter, 50-808011A1, New [ More info ]
|
  |
|
18-5603-1 - Mercury/Pleasurecraft Starter [ More info ]
|
  |
|
30459 - Starter, 50-808011A4, 3862985 [ More info ]
|
  |
|
|
| #2 | 8M0204653 | NUT @10 (2 required per assembly) — Replaces: 82671015, 34933 |
  |
|
11-8M0204653 - Prop Lock Nut 7/16-20 , Priced Individually [ More info ]
|
  |
|
11-00118 - Nut, Sold Individually [ More info ]
|
| #3 | 45176 | WASHER @5 (2 required per assembly) |
  |
|
12-45176 - Washer, (.453 X .812 X .105) [ More info ]
|
| #4 | 8M0041668 | STUD (2 required per assembly) — Replaces: 57982 |
  |
|
16-8M0041668 - Stud [ More info ]
|
| #5 | 20086 | WASHER @5 (1 required per assembly) |
  |
|
12-20086 - Washer, (.390 X .620 X .060) [ More info ]
|
| #6 | 4013610 | NUT @3 (1 required per assembly) |
  |
|
11-40136 10 - Nut, (M10) Stainless Steel [ More info ]
|
| #7 | 79695T | BOOT-INSULATOR (1 required per assembly) — Replaces: 79695 |
  |
|
85-79695T - Insulator Boot [ More info ]
|
| #8 | 30164 | WASHER @3 (1 required per assembly) |
  |
|
12-30164 - Washer, (.192 X .375 X .0312) [ More info ]
|
| #9 | 400263 | NUT @2 (2 required per assembly) |
  |
|
11-40026 3 - NUT,NLA [ More info ] Unavailable |
| #10 | 842433 | HARNESS ASSEMBLY ALTERNATOR (1 required per assembly) |
  |
|
84-842433 - Harness Assembly [ More info ] Unavailable |
| #11 | 842410 | SPACER (1 required per assembly) |
  |
|
23-842410 - Spacer [ More info ] Unavailable |
| #12 | 843108 | WASHER (1 required per assembly) |
  |
|
12-843108 - Washer, (.330 X .560 X .060) Stainless Steel [ More info ]
|
| #13 | 401368 | NUT @3 (1 required per assembly) — Replaces: 400265 |
  |
|
11-40136 8 - Nut - Priced Individually [ More info ]
|
| #14 | 843365001 | STUD (2 required per assembly) |
  |
|
16-843365001 - Stud [ More info ] Unavailable |
| #15 | 843585 | STUD (1 required per assembly) |
  |
|
16-843585 - Stud [ More info ] Unavailable |
| #16 | 8414342 | BRACKET ALTERNATOR (1 required per assembly) |
  |
|
841434 2 - Bracket [ More info ] Unavailable |
| #17 | 856774 | WASHER @5 (1 required per assembly) |
  |
12-856774 - Washer, (.406 X .750 X .105) Stainless Steel [ More info ] Unavailable |
|
  |
|
128M0214963 - WASHER Note: Priced Individually [ More info ]
|
| #18 | 82671013 | NUT @5 (1 required per assembly) |
  |
|
11-826710 13 - Nut, (.375-24) Stainless Steel [ More info ]
|
  |
|
18-3720-9 - Lock Nut, 11-34932, 5PK [ More info ]
|
| #19 | 45176 | WASHER @5 (2 required per assembly) |
| #20 | 8M0204653 | NUT @10 (1 required per assembly) — Replaces: 34933 |
| #21 | 843365 | STUD (2 required per assembly) |
  |
|
16-843365 - Stud [ More info ] Unavailable |
| #22 | 45176 | WASHER @5 (3 required per assembly) |
| #23 | 8M0204653 | NUT @10 (3 required per assembly) — Replaces: 34933 |
| #24 | 8M0052708 | V BELT ALTERNATOR (1 required per assembly) — Replaces: 842434 |
  |
|
57-8M0052708 - V-Belt [ More info ]
|
| #25 | 862030T01 | ALTERNATOR - NOTE: Service Complete (1 required per assembly) — Replaces: 862030T |
  |
|
862030T01 - Alternator [ More info ]
|
  |
|
20810 - Inboard Alternator [ More info ]
|
| #26 | 939362 | PULLEY (1 required per assembly) |
  |
|
93936 2 - Pulley [ More info ] Unavailable |
| #27 | 37998 | WASHER @2 (1 required per assembly) |
  |
|
12-37998 - Washer - Priced Individually [ More info ]
|
| #28 | 8267098 | NUT @2 (1 required per assembly) |
  |
|
11-826709 8 - Nut - Priced Individually [ More info ]
|
| #29 | 79989 | NUT (2 required per assembly) |
  |
|
11-79989 - Nut (10 - 24) [ More info ]
|
| #30 | 26996 | LOCKWASHER @15 (2 required per assembly) |
  |
|
13-26996 - LockWasher - Priced Individually [ More info ]
|
| #31 | 21806 | NUT (1 required per assembly) |
  |
|
11-21806 - Nut, (#10x24) [ More info ]
|
| #32 | 847883 | WASHER (1 required per assembly) |
  |
|
12-847883 - Washer, (.192 X .375 X .033) [ More info ]
|
| #33 | 824459110 | SCREW (1 required per assembly) |
  |
|
10-824459110 - Screw [ More info ]
|
| #34 | 63032 | WASHER (2 required per assembly) |
  |
|
12-63032 - Washer, (.320 X 1.00 X .120) Stainless Steel [ More info ]
|
| #35 | 842439 | BRACE OIL PAN TO ALTERNATOR (1 required per assembly) |
  |
|
842439 - Brace [ More info ] Unavailable |
| #36 | 4000354 | SCREW @5 (1 required per assembly) |
  |
|
10-40003 54 - Screw - Priced Individually [ More info ]
|
| #37 | 8M0204726 | NUT-BRASS @3 (1 required per assembly) — Replaces: 826709113, 8M0042636 |
  |
|
118M0204726 - NUT-BRASS Note: Priced Individually [ More info ]
|
| #38 | 856774 | WASHER @5 (1 required per assembly) |
| #39 | 818824 | STUD (.375-16/.375-24 X 1.590) TO OIL PAN (1 required per assembly) |
  |
|
16-818824 - Stud [ More info ]
|
