Parts for 440 Trs GM 454 V-8 7.4L (454 Cu In) V8 GM MerCruiser Engines - Gas Thermostat Housing (460)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 99386A2 | GASKET SET (1 required per assembly) |
  |
|
27-99386A 2 - Gasket Set, NLA [ More info ] Unavailable |
| #1 | 99270A1 | THERMOSTAT HSG (1 required per assembly) |
  |
|
99270A 1 - Thermostat Housing, NLA [ More info ] Unavailable |
| #2 | 97314 | FITTING (STRAIGHT) (1 required per assembly) |
  |
|
22-97314 - Fitting [ More info ]
|
| #3 | 416223 | PLUG PIPE (.750-14) THERMOSTAT HOUSING (1 required per assembly) — Replaces: 33198A1, 41622 |
  |
|
22-41622 3 - Pipe Plug [ More info ]
|
| #3 | 8M0204657 | PLUG THERMOSTAT HOUSING (1 required per assembly) — Replaces: 36373 |
  |
|
228M0204657 - PLUG [ More info ]
|
| #4 | 530451 | GASKET THERMOSTAT HOUSING TO MANIFOLD (LOWER) (1 required per assembly) — Replaces: 53045 |
  |
|
27-53045 1 - Gasket - Priced Individually [ More info ]
|
  |
|
18-2917-9 - Gasket 27-530451 2-Pack [ More info ]
|
  |
|
27-53045Q01 - Gasket [ More info ]
|
| #5 | 8072521 | THERMOSTAT (143 DEGREE) (1 required per assembly) — Replaces: 59137, 8052731 |
  |
807252 1 - Thermostat-140 [ More info ] Unavailable |
|
  |
807252T 1 - Thermostat, 140 Degrees [ More info ] Unavailable |
|
  |
|
807252Q 4 - Thermostat Kit, 140 Degrees [ More info ]
|
  |
|
8M0089715 - Thermostat, 140 Degrees [ More info ]
|
  |
|
18-3551 - Thermostat, 142 Degrees, 807252T1, 59137 [ More info ]
|
  |
|
75-03057 - Thermostat 142 Degree, 8M0089715 [ More info ]
|
| #6 | 47510 | GASKET THERMOSTAT HOUSING (MIDDLE) (1 required per assembly) |
  |
|
27-47510 - Thermostat Gasket [ More info ]
|
  |
|
18-2553-9 - Gasket 27-47510 2-Pack [ More info ]
|
| #7 | 47508T | SLEEVE THERMOSTAT HOUSING (1 required per assembly) — Replaces: 47508 |
  |
|
23-47508T - Thermostat Sleeve [ More info ]
|
| #8 | 488181 | GASKET THERMOSTAT HOUSING (UPPER) (1 required per assembly) — Replaces: 48818 |
  |
|
27-48818 1 - Gasket - Priced Individually [ More info ]
|
| #9 | 8M0061068 | THERM COVER HSG THERMOSTAT HOUSING (1 required per assembly) — Replaces: 47442A1 |
  |
|
8M0061068 - THERM Cover Housing [ More info ]
|
  |
|
MC-29-47442 - Thermostat Housing [ More info ]
|
| #10 | 612268 | HOSE SEA PUMP TO FLYWHEEL HOUSING (25") (1 required per assembly) |
  |
|
32-61226 8 - Hose, NLA [ More info ]
|
| #11 | 815504220 | CLAMP WORM GEAR HOSE ATTACHING (2 required per assembly) — Replaces: 32780 |
  |
|
54-815504220 - Clamp [ More info ]
|
| #12 | 897181 | HOSE THERM. HSG/WATER PUMP (W/O POWER STEERING) (1 required per assembly) — Replaces: 89718 |
  |
|
32-89718 1 - Molded Hose [ More info ]
|
| #13 | 770061 | HOSE THERM. HSG./WATER PUMP (W/POWER STEERING) (1 required per assembly) |
  |
|
0770061 - L/P 68.30 [ More info ] Unavailable |
| #14 | 815504228 | CLAMP WORM GEAR HOSE TO THERMOSTAT HOUSING (TOP) (1 required per assembly) — Replaces: 32781 |
  |
|
54-815504228 - Clamp [ More info ]
|
  |
|
54-8M0232395 - CLAMP HOSE [ More info ] Unavailable |
| #15 | 815504232 | CLAMP WORM GEAR (2.50 DIAMETER) HOSE TO WATER PUMP (BOTTOM) (1 required per assembly) — Replaces: 87268 |
  |
|
54-815504232 - Clamp [ More info ]
|
| #16 | 9809070 | HOSE EXHAUST (2 required per assembly) — Replaces: 980904 |
  |
|
32-98090 70 - Hose, NLA [ More info ] Unavailable |
| #17 | 8M0204717 | CLAMP EXHAUST HOSE (4 required per assembly) — Replaces: 43510, 815504412 |
  |
|
54-8M0204717 - CLAMP [ More info ] Unavailable |
| #18 | 36305T | ELBOW EXHAUST HOSE (2 required per assembly) — Replaces: 36305 |
  |
|
22-36305T - Elbow [ More info ]
|
  |
|
18-8216 - Brass Fitting, 22-36305 [ More info ]
|
| #19 | 93447A2 | LIMITER ASSY (1 required per assembly) |
  |
|
93447A 2 - LIMITER ASSY,NLA [ More info ] Unavailable |
| #20 | 93661 | BRACKET REV LIMITER (1 required per assembly) |
  |
|
93661 - Bracket, NLA [ More info ] Unavailable |
| #21 | 42279 | MOUNT (2 required per assembly) |
  |
|
42279 - MOUNT,NLA [ More info ] Unavailable |
| #22 | 905201 | SPACER (2 required per assembly) — Replaces: 90520 |
  |
|
23-90520 1 - Spacer [ More info ]
|
| #23 | 8M0204649 | WASHER @10 (4 required per assembly) — Replaces: 29245 |
  |
|
12-8M0204649 - WASHER Note: Priced Individually [ More info ]
|
| #24 | 8267089 | NUT @5 (4 required per assembly) — Replaces: 20361 |
  |
|
11-826708 9 - Nut - Priced Individually [ More info ]
|
  |
|
18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ]
|
| #25 | 52693 | SCREW LIMITER AND COVER (2 required per assembly) |
  |
|
10-52693 - Screw, NLA [ More info ] Unavailable |
| #26 | 20553 | WASHER @5 (2 required per assembly) |
  |
|
12-20553 - Washer - Priced Individually [ More info ]
|
| #27 | 94277 | SPACER (2 required per assembly) |
  |
|
23-94277 - SPACER,NLA [ More info ] Unavailable |
