Parts for 165 (2 BBL.) Mercury 224 I / L4 3.7L (224 Cu In) L4 Mercury MerCruiser Engines - Gas Starter Motor & Wiring Harness

Revise Search: Sterndrive > MerCruiser Engines - Gas > 3.7L (224 Cu In) L4 Mercury > 165 (2 BBL.) Mercury 224 I / L4 > 1987 0B434941 - 0B774251 > Starter Motor & Wiring Harness

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Starter Motor & Wiring Harness

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	11149A5	ADAPTOR KIT (See Note) (1 required per assembly)
		84-11149A 5 - Adaptor Kit, NLA [ More info ] $4.00 $3.39 7 In Stock.
#1	8M6007288	STARTER (1 required per assembly) — Replaces: 97499A2, 97499R3
		50-8M6007288 - STARTER [ More info ] Unavailable
#2	48130	SCREW (.375-16 X 4.500) STARTER MOTOR (2 required per assembly)
		10-48130 - Screw, NLA [ More info ] $4.05 10+ In Stock.
#3	25909	WASHER (.406 X .812 X .065) STARTER MOTOR SCREW (2 required per assembly)
		12-25909 - Washer (.406 X .812 X .065) [ More info ] $1.90 Available to Order: Shipping delay up to 10 days.
#4	82671112	NUT (.375-16) STARTER MOTOR SCREW (2 required per assembly) — Replaces: 99405
		11-826711 12 - Nut, (.375-16) [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#5	29031	NUT (1/4-20) STARTER MOTOR TERMINAL (1/4-20) (2 required per assembly)
		11-29031 - Nut, (1/4-20) [ More info ] Unavailable
#7	26419	NUT (#8-32) BRASS STARTER MOTOR TERMINAL (2 required per assembly)
		11-26419 - Nut (#8-32) (brass) [ More info ] $1.70 10+ In Stock.
#7	15874	NUT (M10) BATTERY TERMINAL (1 required per assembly)
		11-15874 - Nut (10 Mm) [ More info ] $2.79 10+ In Stock.
#7	400211	NUT (M5) STAINLESS STEEL SOLENOID SWITCH TERMINAL (2 required per assembly)
		11-40021 1 - Nut [ More info ] $3.59 10+ In Stock.
#8	97259A1	BRACKET STARTER MOTOR TO CYLINDER BLOCK (1 required per assembly)
		97259A 1 - Bracket, NLA [ More info ] Unavailable
#9	98261	SCREW (.375-16 X .750) BRACKET TO CYLINDER BLOCK (2 required per assembly)
		10-98261 - Screw [ More info ] $1.20 5 In Stock.
#10	35048	LOCKWASHER (.375) BRACKET SCREW (2 required per assembly)
		13-35048 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#11	65057T1	SOLENOID ASSY (1 required per assembly) — Replaces: 65057A1
		65057T 1 - Solenoid Assembly [ More info ] $81.99 $80.92 1 In Stock.
		18-5802 - Solenoid 65057A1 [ More info ] $40.99 $40.82 2 In Stock.
		SW981 - Solenoid [ More info ] $44.26 $40.51 In Stock
#12	28635	SCREW (.250-20 X .620) STAINLESS STEEL SOLENOID TO CYLINDER BLOCK (2 required per assembly)
		10-28635 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#13	26992	LOCKWASHER (.250) STAINLESS STEEL SOLENOID SCREW (2 required per assembly)
		13-26992 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#14	269011	BUMPER RUBBER SOLENOID (1 required per assembly) — Replaces: 26901
		26901 1 - Bumper [ More info ] $3.99 4 In Stock.
#15	26996	LOCKWASHER (#10) STAINLESS STEEL SOLENOID TERMINAL (2 required per assembly)
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 3 In Stock.
#16	68219	NUT (#10-32) STAINLESS STEEL SOLENOID TERMINAL (2 required per assembly)
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#17	8M0204647	LOCKWASHER @5 SOLENOID TERMINAL (2 required per assembly) — Replaces: 26993
		138M0204647 - LOCKWASHER, Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#18	22053	NUT (.312-24) SOLENOID TERMINAL (2 required per assembly)
		11-22053 - Nut (5/16x24) [ More info ] $0.20 10+ In Stock.
#19	98269A9	ENGINE HARNESS (1 required per assembly)
		84-98269A 9 - Engine Harness [ More info ] $461.99 Available to Order: Shipping delay up to 10 days.
#20	26079A2	PLATE KIT Plastic (1 required per assembly) — Replaces: 26079
		26079A 2 - Plate Kit [ More info ] $30.64 2 In Stock.
#21	34696	SCREW (#8-32 X .750) USE WITH METAL PLATE (4 required per assembly)
		10-34696 - Screw [ More info ] Unavailable
#21	15001	SCREW (#8-16 X .875) Use with Plastic Plate Kit (4 required per assembly)
		10-15001 - Screw [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#22	815425T	SENDER ASSEMBLY OIL PRESSURE (1 required per assembly) — Replaces: 90806, 815425
		815425T - Sender [ More info ] Unavailable
		8M0068784 - Sender Assembly [ More info ] $133.49 $131.62 In Stock
		18-5899 - Sender, 982650, 815425T [ More info ] $42.99 $41.78 10+ In Stock.
		75-24301 - Mercruiser and OMC Oil Pressure Sender [ More info ] $42.49 $34.16 3 In Stock.
#23	26996	LOCKWASHER (#10) STAINLESS STEEL SENDING UNIT TERMINAL (1 required per assembly)
#24	68219	NUT (#10-32) STAINLESS STEEL SENDING UNIT TERMINAL (1 required per assembly)
#25	99502A13	VOLTAGE REGULATOR (1 required per assembly) — Replaces: 99502A9
		99502A13 - Voltage Regulator [ More info ] Unavailable
		18-99421 - Mercuiser Voltage Regulator 194-9502 [ More info ] $657.08 $644.29 In Stock
#26	98255	SCREW (.250-20 X 2.25) VOLTAGE REGULATOR (2-1/4&QUOT;) (2 required per assembly)
		10-98255 - Screw, NLA [ More info ] $1.50 $1.28 1 In Stock.
#27	26992	LOCKWASHER (.250) STAINLESS STEEL VOLTAGE REGULATOR SCREW (2 required per assembly)
#28	34354	SCREW (.375-16 X 1.50) VOLTAGE REGULATOR (1 required per assembly)
		10-34354 - Screw - Priced Individually [ More info ] $2.39 10+ In Stock.
#29	58643	LOCKWASHER (.375) VOLTAGE REGULATOR SCREW (1 required per assembly)
		13-58643 - LockWasher [ More info ] $1.80 $1.30 10+ In Stock.
#30	68219	NUT (#10-32) STAINLESS STEEL VOLTAGE REGULATOR TERMINALS (5 required per assembly)
#31	94227A2	RESISTOR WIRE KIT (TO REPLACE RESISTOR WIRE) (1 required per assembly)
		84-94227A 2 - Resistance Wire Kit [ More info ] $41.49 Available to Order: Shipping delay up to 10 days.
