Mercury Marine Mechanical Panel Mount Remote Controls & Components Remote Control-4000 Gen II (Lock Bar) Panel Mount

Revise Search: Accessories 1994 & Up > Remote Controls & Components > Panel Mount > Mechanical > 1994 & Up > Remote Control-4000 Gen II (Lock Bar) Panel Mount

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Remote Control-4000 Gen II (Lock Bar) Panel Mount

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	883710A01	REMOTE CONTROL (Outboard/Sterndrive) (1 required per assembly)
		883710A01 - Remote Control [ More info ] $459.47 In Stock
#-	883710A02	REMOTE CONTROL (Outboard) (1 required per assembly)
		883710A02 - Remote Control [ More info ] $528.03 In Stock
#-	883710A03	REMOTE CONTROL (Mercruiser) (1 required per assembly)
		883710A03 - Remote Control [ More info ] $553.89 In Stock
#-	883710A04	REMOTE CONTROL (MIE/Inboard) (1 required per assembly)
		883710A04 - Remote Control [ More info ] Unavailable
#-	8M0099936	REMOTE CONTROL (1 required per assembly)
		8M0099936 - Remote Control [ More info ] Unavailable
#1	898971T01	HANDLE ASSEMBLY OUTBOARD TRIM (1 required per assembly) — Replaces: 891902T01
		898971T01 - Outboard Trim Handle Assembly [ More info ] $113.05 Available to Order: Shipping delay up to 10 days.
#1	891647T01	HANDLE/BEZEL ASSEMBLY REPAIR KIT. Contains handle assembly, bezel and hardware for Outboard Trim model. (AR required per assembly)
		891647T01 - Handle/Bzl Repair Kit [ More info ] $118.38 Available to Order: Shipping delay up to 10 days.
#1	898971T02	HANDLE ASSEMBLY MCM TRIM (Mercruiser) (1 required per assembly) — Replaces: 891902T02
		898971T02 - Handle Assembly -mc Trm C [ More info ] $113.05 Available to Order: Shipping delay up to 10 days.
#1	898971T03	HANDLE ASSEMBLY NON TRIM (1 required per assembly) — Replaces: 891902T03
		898971T03 - Handle Assembly -NO TRM [ More info ] $111.71 Available to Order: Shipping delay up to 10 days.
#2	859032T02	SWITCH /HARNESS ASSEMBLY (Outboard) (1 required per assembly)
		87-859032T02 - Switch and Harness - Outboard [ More info ] Unavailable
#3	858679T1	SWITCH/HARNESS ASSEMBLY (Mercruiser) (1 required per assembly)
		87-858679T 1 - Switch and Harness [ More info ] $95.49 In Stock
#4	16924	SPRING HANDLE (1 required per assembly)
		24-16924 - Spring [ More info ] $1.58 Available to Order: Shipping delay up to 10 days.
#5	87775510	SCREW (M4 X 10) (1 required per assembly)
		10-877755 10 - Screw - Priced Individually [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
#6	897481	SCREW (#6-32 X .375) (2 required per assembly)
		10-897481 - SCREW (#6-32 x .3 [ More info ] Unavailable
#7	891645A01	BUTTON ASSEMBLY THROTTLE ONLY (1 required per assembly)
		891645A01 - Button Assembly [ More info ] $9.79 3 In Stock.
#8	891656	EMBLEM MERCURY (1 required per assembly)
		37-891656 - Emblem- Mercury [ More info ] $8.69 Available to Order: Shipping delay up to 10 days.
#9	8222131	BOLT LOCKING SPECIAL (1 required per assembly)
		10-822213 1 - Bolt [ More info ] Unavailable
#10	19923062	SCREW (.250-20 X .625) (3 required per assembly)
		10-19923062 - Screw [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#11	8M0032846	RETAINER BRASS (1 required per assembly) — Replaces: 120441
		8M0032846 - Brass Retainer [ More info ] $4.61 Available to Order: Shipping delay up to 10 days.
#12	133982	SWITCH ASSEMBLY STOP (Outboard) (1 required per assembly)
		87-13398 2 - Switch [ More info ] $67.17 Available to Order: Shipping delay up to 10 days.
#13	133983	SWITCH ASSEMBLY STOP STOP (Mercruiser) (1 required per assembly)
		87-13398 3 - Switch [ More info ] $67.17 Available to Order: Shipping delay up to 10 days.
#14	891647T	BEZEL (1 required per assembly)
		891647T - Bezel - Panel Mnt [ More info ] $30.85 Available to Order: Shipping delay up to 10 days.
#15	891905001	DECAL F-N-R Starboard-Mount (1 required per assembly)
		37-891905001 - Decal - F/N/R Stbd [ More info ] $1.40 Available to Order: Shipping delay up to 10 days.
#15	891905002	DECAL R-N-F Port-Mount (AR required per assembly)
		37-891905002 - Decal -f/N/R Port [ More info ] $28.72 Available to Order: Shipping delay up to 10 days.
#16	859031	SCREW (.250-20 X 1.50) (3 required per assembly)
		10-859031 - Screw [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#17	859664	WASHER (3 required per assembly)
		12-859664 - Washer - Priced Individually [ More info ] $1.80 $1.44 10 In Stock.
#18	8267088	NUT (.250-20) (3 required per assembly)
		11-826708 8 - Nut [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#19	891648T	COVER DARK GRAY (1 required per assembly)
		891648T - Cover [ More info ] $3.26 Available to Order: Shipping delay up to 10 days.
#19	891648001	COVER WOODGRAIN (Opt required per assembly)
		891648001 - Cover [ More info ] $38.81 10+ In Stock.
#19	891648002	COVER BURLWOOD GOLD WOODGRAIN (Opt required per assembly)
		891648002 - Cover [ More info ] $36.00 $30.49 10+ In Stock.
#20	859016	BUSHING (1 required per assembly)
		23-859016 - Bushing [ More info ] $8.69 3 In Stock.
#21	15920Q54	LANYARD ASSEMBLY (1 required per assembly)
		15920Q54 - Stop Switch Lanyard- Priced Individually [ More info ] Unavailable
#22	824783A11	HARNESS ASSEMBLY TRIM SWITCH (Outboard) (1 required per assembly)
		84-824783A11 - Harness Adaptor Assembly [ More info ] $19.96 Available to Order: Shipping delay up to 10 days.
#23	8M0087765	DECAL LANYARD, WHITE (1 required per assembly)
		568M0087765 - Decal-Lanyard WHT [ More info ] $3.11 1 In Stock.
#24	817659A1	HARNESS ASSY (Mercruiser) (Not included in Remote Control Kit - Order Separate) (1 required per assembly)
		84-817659A 1 - Harness Assembly [ More info ] $32.24 1 In Stock.
#25	881125A1	HARNESS ASSY (Mercruiser) (Not included in Remote Control Kit - Order Separate) (1 required per assembly)
		84-881125A 1 - Harness Assembly [ More info ] $40.83 In Stock
#NS	883719A_	CABLE ASSEMBLY THROTTLE/SHIFT (STANDARD) (See Accessories Guide for correct length cable) (AR required per assembly)
		883719A_ - CABLE ASSEMBLY [ More info ] Unavailable
#NS	883720A_	CABLE ASSEMBLY THROTTLE/SHIFT (PLATINUM) (See Accessories Guide for correct length cable) (AR required per assembly)
		883720A_ - CABLE ASSEMBLY [ More info ] Unavailable
#NS	892547A01	INDICATOR TOOL SHIFT LOAD (Use with MPC 4000 (Gen II) Panel Mount) (1 required per assembly)
		91-892547A01 - Indicator- Shift [ More info ] Unavailable
