Electrical Harnesses & Connectors

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0165557	J-BOX 5-WAY W/CAP (1 required per assembly) — Replaces: 878492K18
		988M0165557 - J-BOX 5-WAY W/CAP [ More info ] $77.36 Available to Order: Shipping delay up to 10 days.
#2	8M0165557	J-BOX 5-WAY W/CAP (1 required per assembly) — Replaces: 878492T18
#3	859318T2	CAP WEATHER - 10 PIN (4 required per assembly)
		859318T 2 - Weather Cap [ More info ] Unavailable
#4	8M0165557	J-BOX 5-WAY W/CAP (1 required per assembly) — Replaces: 878492K16
#5	8M0165557	J-BOX 5-WAY W/CAP (1 required per assembly) — Replaces: 878492T16
#6	859318T2	CAP WEATHER - 10 PIN (3 required per assembly)
#7	893330K01	KIT-ADAPTOR DUAL (1 required per assembly)
		84-893330K01 - Dual Adaptor Kit [ More info ] $200.89 Available to Order: Shipping delay up to 10 days.
#8	830796A03	CONNECTOR ASSEMBLY WEATHER CAP - 2 PIN MALE (2 required per assembly)
		830796A03 - Connector [ More info ] $5.92 2 In Stock.
#9	877613A02	CONNECTOR ASSEMBLY WEATHER CAP 6 PIN (1 required per assembly)
		877613A02 - Connector [ More info ] $8.19 Available to Order: Shipping delay up to 10 days.
#10	830796A03	CONNECTOR Diesel-Dual/Triple/Quad (2 required per assembly)
#11	8M2004357	ADAPTER-PORT OUTR 4.2 I6 Diesel Application Only (1 required per assembly)
		84-8M2004357 - Harness [ More info ] $33.29 $32.10 Available to Order: Shipping delay up to 10 days.
#11	8M0109337	ADAPTER-STBD OUTR 4.2 I6 Diesel Application Only (1 required per assembly)
		848M0109337 - Adapter - Starboard OUTR [ More info ] $33.10 Available to Order: Shipping delay up to 10 days.
#12	879312T20	HARNESS-ADAPTOR Diesel Application (AR required per assembly)
		84-879312T20 - Harness - Adaptor [ More info ] $33.69 Available to Order: Shipping delay up to 10 days.
#13	8M6000699	HARNESS-E-STOP Diesel Application (1 required per assembly)
		848M6000699 - Harness-E-Stop [ More info ] $176.05 Available to Order: Shipping delay up to 10 days.
#14	896352A01	TOOL-DEPINNING (1 required per assembly)
		91-896352A01 - Tool -depinning [ More info ] $9.09 Available to Order: Shipping delay up to 10 days.
#15	889826	CAVITY PLUG (8 required per assembly)
		889826 - Plug - Priced Individually [ More info ] $1.20 Available to Order: Shipping delay up to 10 days.
