Mercury Marine Joystick Piloting (Design II) Outboard Joystick Piloting Systems Link Rod / Link Cable / Extension Arm & Torsion Springs
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 8M0099091 | HARDWARE KIT EXTENSION ARM (1 required per assembly) |
  |
8M0099091 - HARDWARE KIT [ More info ] Unavailable |
|
  |
|
8M0213285 - HARDWARE KIT [ More info ] Unavailable |
| #1 | 8M0073161 | KIT-LINK ROD ASY Quad Application (4 required per assembly) |
  |
|
988M0073161 - Link Rod Assembly [ More info ]
|
| #2 | 37828 | WASHER (.390 X .625 X .062) STAINLESS STEEL (2 required per assembly) |
  |
|
12-37828 - Washer, (.390 X .625 X .062) Stainless Steel [ More info ]
|
| #3 | 8M0204726 | NUT-BRASS @3 (2 required per assembly) — Replaces: 8M0042636 |
  |
|
118M0204726 - NUT-BRASS Note: Priced Individually [ More info ]
|
| #4 | 73732 | SCREW (.375-24 X 1.120) (1 required per assembly) |
  |
|
10-73732 - Screw [ More info ]
|
| #5 | 8M0087880 | EXTENSION ARM-JPO [2B144122] & Below (AR required per assembly) |
  |
|
988M0087880 - Extension ARM-JPO [ More info ]
|
| #5 | 8M0098927 | EXTENSION ARM KIT (350/400R All) (250-300 Serial # 2B144123 and above) (AR required per assembly) |
  |
|
8M0098927 - Extension Arm Kit [ More info ]
|
| #6 | 896634 | WASHER RETAINER LOCKING (2 required per assembly) |
  |
|
14-896634 - Washer [ More info ]
|
| #6 | NSS | NOT SOLD SEPARATE TAB WASHER (10 MM) (2 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #7 | 8M0086349 | WASHER (0.328 ID 0.562 OD THICK) (2 required per assembly) |
  |
|
128M0086349 - Washer [ More info ]
|
| #7 | NSS | NOT SOLD SEPARATE WASHER, (10 MM) (2 required per assembly) |
| #8 | 896555025 | SCREW (M8 X 25 MM) (2 required per assembly) |
  |
|
10-896555025 - Screw [ More info ]
|
| #8 | NSS | NOT SOLD SEPARATE SCREW (M10 1.5 HEX HD CAP, SS) (2 required per assembly) |
| #9 | 892373001 | SCREW (M8 X 46.75 MM) (1 required per assembly) |
  |
|
10-892373001 - Screw [ More info ]
|
| #9 | NSS | NOT SOLD SEPARATE NUT (JAM M10 HEX) (1 required per assembly) |
| #10 | 400213 | NUT (M8) STAINLESS STEEL (1 required per assembly) |
  |
|
11-40021 3 - Nut - Priced Individually [ More info ]
|
| #10 | NSS | NOT SOLD SEPARATE SCREW M10 X 1.5 HEX HD) (1 required per assembly) |
| #11 | 8M6002058 | SPRING TORSION USED ON FIXED LENGTH LINK CABLES-OUTSIDE ENGINES Dual and Triple Application Only (2 required per assembly) |
  |
|
248M6002058 - Torsion Spring SS [ More info ]
|
| #12 | 8M6002059 | SPRING TORSION USED ON FIXED LENGTH LINK CABLES-CENTER ENGINE Dual and Triple Application Only (1/2 required per assembly) |
  |
|
248M6002059 - Spring-TRSN Inner [ More info ]
|
| #13 | 8M6002439 | SPRING TORSION USED ON ADJUSTABLE LENGTH LINK CABLES-OUTSIDE ENGINE Dual and Triple Application Only (2 required per assembly) |
  |
|
248M6002439 - Torsion Spring SS [ More info ]
|
| #14 | 8M6002440 | SPRING TORSION USED ON ADJUSTABLE LENGTH LINK CABLE -CENTER ENGINE Dual and Triple Application Only (2 required per assembly) |
  |
|
248M6002440 - Torsion Spring SS [ More info ]
|
| #15 | 8M0109000 | CABLE-25IN CENTER Quad Application Only (AR required per assembly) |
  |
|
8M0109000 - Cable-25IN CENTER [ More info ]
|
| #15 | 8M0108999 | CABLE-26IN CENTER Quad Application Only (AR required per assembly) |
  |
|
8M0108999 - Cable-26IN CENTER [ More info ]
|
| #15 | 8M0079292 | LINK CABLE-25 ADJ (AR required per assembly) |
  |
|
8M0079292 - Link Cable -25 ADJ [ More info ]
|
| #15 | 8M0079945 | LINK CABLE-26 ADJ (AR required per assembly) |
  |
|
8M0079945 - Link Cable -26 ADJ [ More info ]
|
| #15 | 8M0077126 | CABLE-26IN CENTER (AR required per assembly) |
  |
|
8M0077126 - Link Cable -26 IN [ More info ]
|
| #15 | 8M0077129 | CABLE-27IN CENTER (AR required per assembly) |
  |
|
8M0077129 - Link Cable -27 IN [ More info ]
|
| #15 | 8M0077130 | CABLE-28IN CENTER (AR required per assembly) |
  |
|
8M0077130 - Link Cable -28 IN [ More info ]
|
| #15 | 8M0077133 | CABLE-29IN CENTER (AR required per assembly) |
  |
|
8M0077133 - Link Cable -29 IN [ More info ]
|
| #15 | 8M0077134 | CABLE-30IN CENTER (AR required per assembly) |
  |
|
8M0077134 - Link Cable -30 IN [ More info ]
|
| #15 | 8M0077135 | CABLE-31IN CENTER (AR required per assembly) |
  |
|
8M0077135 - Link Cable -31 IN [ More info ]
|
| #15 | 8M0077136 | CABLE-32IN CENTER (AR required per assembly) |
  |
|
8M0077136 - Link Cable -32 IN [ More info ]
|
| #15 | 8M0077137 | CABLE-33IN CENTER (AR required per assembly) |
  |
|
8M0077137 - Link Cable -33 IN [ More info ]
|
| #15 | 8M0077138 | CABLE-34IN CENTER (AR required per assembly) |
  |
|
8M0077138 - Link Cable -34 IN [ More info ]
|
| #15 | 8M0077139 | CABLE-35IN CENTER (AR required per assembly) |
  |
|
8M0077139 - Link Cable -35 IN [ More info ]
|
| #15 | 8M0077140 | CABLE-37IN CENTER (AR required per assembly) |
  |
|
8M0077140 - Link Cable -36 IN [ More info ]
|
| #15 | 8M0079408 | CABLE-37IN CENTER (AR required per assembly) |
  |
|
8M0079408 - Link Cable -38 IN [ More info ] Unavailable |
| #16 | 8M0086774 | BRACKET-TRAILERNG (AR required per assembly) |
  |
|
8M0086774 - Bracket-TRAILERNG [ More info ]
|
| #17 | 8M0080643 | PIN QUICK RELEASE (2 required per assembly) |
  |
|
178M0080643 - PIN-QUICK RELEASE [ More info ]
|
