Harness & Bracket Assembly Quad Engine (Ccm13 Software)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0133230	ORD 8M0139692 (1 required per assembly) — Replaces: 8M0071983, 8M0109079
		84-8M0133230 - ORD 8M0139692 NLA [ More info ] Unavailable
#-	8M0139692	HARN & BRKT ASSY (1 required per assembly) — Replaces: 8M0109079, 8M0133230
		848M0139692 - Harness & Bracket [ More info ] Unavailable
#1	4010660	SCREW (M6 X 60) (3 required per assembly)
		104010660 - Screw [ More info ] $2.69 Available to Order: Shipping delay up to 10 days.
#2	856954	BUSHING (7 required per assembly)
		23-856954 - Bushing [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#3	8349851	GROMMET (6 required per assembly)
		25-834985 1 - Grommet [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#4	4002316	WASHER (6.60 X 17.0 X 1.5SS) (4 required per assembly)
		12-40023 16 - Washer - Priced Individually [ More info ] $1.17 2 In Stock.
		128M0214930 - WASHER Note: Must be ordered in multiples of 5 [ More info ] $1.00 1 In Stock.
#5	8M0047039	SPACER (5 required per assembly)
		238M0047039 - Spacer [ More info ] $7.89 Available to Order: Shipping delay up to 10 days.
#6	82130040	SCREW (M6 X 40) (1 required per assembly)
		10-821300 40 - Screw [ More info ] $7.89 $4.43 10+ In Stock.
#7	8M0139688	CCM18 V2 JPO D1 CCM13 SOFTWARE (2 required per assembly) — Replaces: 8M0109006, 8M0133213
		778M0139688 - CCM18 V2 JPO D1 [ More info ] $833.47 Available to Order: Shipping delay up to 10 days.
#8	8M0056174	BRACKET (1 required per assembly)
		8M0056174 - Bracket [ More info ] Unavailable
#9	8M0076450	HARNESS-HELM (2 required per assembly)
		848M0076450 - Harness- Helm CNTR [ More info ] $467.34 Available to Order: Shipping delay up to 10 days.
#10	882751A04	RELAY ASSEMBLY (1 required per assembly)
		882751A04 - Relay Assembly [ More info ] $23.99 $23.49 In Stock
		18-5850 - Relay, 882751A04 [ More info ] $28.43 6 In Stock.
#11	816311T	TIE STRAP (8.00 INCHES) (6 required per assembly)
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#12	8M0076435	BRACKET (2 required per assembly)
		8M0076435 - Bracket-14 Pin [ More info ] $16.05 Available to Order: Shipping delay up to 10 days.
#13	889664	NUT (1.500-18) BLACK NYLON (2 required per assembly)
		11-889664 - Nut, (1.500-18) Black Nylon [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
#14	893452A01	CABLE ASSEMBLY LINK (2 required per assembly)
		84-893452A01 - Cable Assembly - Link [ More info ] $13.36 Available to Order: Shipping delay up to 10 days.
		84-8M0207792 - INSULATOR-HEATSHK [ More info ] Unavailable
#15	898091T01	RESISTOR ASSY Starboard Inner (1 required per assembly)
		898091T01 - Resistor Assembly [ More info ] $34.01 Available to Order: Shipping delay up to 10 days.
#16	898091T02	RESISTOR ASSY Port Inner (1 required per assembly)
		898091T02 - Resistor Assembly [ More info ] $48.19 Available to Order: Shipping delay up to 10 days.
#17	898091T03	RESISTOR ASSY (1 required per assembly)
		898091T03 - Resistor Assembly [ More info ] $23.28 Available to Order: Shipping delay up to 10 days.
#18	898091T04	RESISTOR ASSY (1 required per assembly)
		898091T04 - Resistor Assembly [ More info ] $25.69 Available to Order: Shipping delay up to 10 days.
#19	896370T01	HARNESS-ADAPTER (1 required per assembly)
		84-896370T01 - Harness - Adapter [ More info ] $25.72 Available to Order: Shipping delay up to 10 days.
#NS	8M0109080	HARNESS AND BRACKET ASSEMBLY DUAL ENGINE OUTBOARD (See Dual Engine Helm Assembly for Parts Breakdown) (AR required per assembly) — Replaces: 8M0085237, 8M0042094
		84-8M0109080 - 84-8M0109080 - HARNESS AND BRACK [ More info ] Unavailable Replaced by -8M0133228
		84-8M0133228 - ORD 8M0139689 NLA [ More info ] Unavailable
#NS	8M0139689	HARN & BRKT ASSY (See Dual Engine Helm Assembly for Parts Breakdown) (AR required per assembly) — Replaces: 8M0109080, 8M0133228
		848M0139689 - Harness & Bracket [ More info ] Unavailable
