Parts for Mercury Marine Docking System Wire Harness & Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 88-881809T | SWITCH/BREAKER ASSEMBLY (1 required per assembly) (150 AMP) |
  |
|
88-881809T - Switch/Breaker Assembly -150 [ More info ]
|
| #2 | 84-40569A 2 | CABLE ASSEMBLY (1 required per assembly) (Marked 84-40569A1) (Battery Bank To Switch/Breaker) |
  |
|
84-40569A 2 - Cable Assembly [ More info ] Unavailable |
| #3 | NSS | CABLE ASSEMBLY (1 required per assembly) (Marked 84-40594A1) (Controller Housing Ground) (Service With Complete Electrical Box 40614A2) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #4 | 84-40570A 3 | CABLE KIT (2 required per assembly) (Marked 84-40570A1) (Battery To Battery) |
  |
|
84-40570A 3 - Cable Kit [ More info ]
|
| #5 | 84-40572A 2 | CABLE ASSEMBLY (1 required per assembly) (Marked 84-40572A1) (Battery Bank Ground) |
  |
|
84-40572A 2 - Cable Assembly [ More info ] Unavailable |
| #6 | 84-40639A 3 | HARNESS ASSEMBLY (3 required per assembly) (Marked 84-40639A1) (Bulkhead Jumper - Sea Ray Models Only) |
  |
|
84-40639A 3 - Harness Assembly [ More info ] Unavailable |
| #NS | 32-828547353 | CONDUIT (1 required per assembly) (.350 x 3.00 Feet Bulk) (Cut As Required) |
  |
|
32-828547353 - Conduit 0.350 x 36 inches [ More info ]
|
| #7 | 84-40591A 4 | HARNESS ASSEMBLY (1 required per assembly) (Marked 84-40591A3) (Bow Motor Jumper) |
  |
|
84-40591A 4 - Harness Assembly [ More info ] Unavailable |
| #NS | 32-828547753 | CONDUIT (1 required per assembly) (.750 x 3.00 Feet Bulk) (Cut As Required) |
  |
|
32-828547753 - Conduit (.750 Inside Di [ More info ]
|
| #8 | 84-40574A 2 | CABLE ASSEMBLY (1 required per assembly) (Marked 84-40574A1) (Equalizer To Ground) |
  |
|
84-40574A 2 - Cable Assembly [ More info ] Unavailable |
| #9 | 84-40617A 2 | CABLE ASSEMBLY (1 required per assembly) (Marked 84-40617A1) (Battery Switch To Breaker) |
  |
|
84-40617A 2 - Cable Assembly [ More info ] Unavailable |
| #10 | 88-881808T | SWITCH/BREAKER ASSEMBLY (1 required per assembly) (50 AMP) |
  |
|
88-881808T - Switch -Breaker-50 [ More info ] Unavailable |
| #11 | 883105T | EQUALIZER KIT (1 required per assembly) |
  |
|
883105T - EQUALIZER KIT [ More info ] Unavailable |
| #NS | 54-816311T | CABLE TIE (8.00 Inch) (6 required per assembly) |
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #12 | 84-40566A 2 | CABLE ASSEMBLY (1 required per assembly) (Marked 84-40566A1) (Breaker To Equalizer) |
  |
|
84-40566A 2 - Cable Assembly [ More info ] Unavailable |
| #13 | 84-40581A 2 | HARNESS ASSEMBLY (1 required per assembly) (Marked 84-40581A1) (Joystick To Electrical Box) |
  |
|
84-40581A 2 - Harness Assembly [ More info ]
|
| #14 | 88-40556 20 | FUSE (20 AMP - 58 Volt) (1 required per assembly) |
  |
|
88-40556 20 - Fuse - 20AMP-58V [ More info ]
|
| #NS | 828054 | COVER-Fuse (1 required per assembly) |
  |
|
828054 - Fuse Cover [ More info ]
|
| #NS | 32-828547253 | CONDUIT (1 required per assembly) (.250 x 3.00 Feet Bulk) (Cut As Required) |
  |
|
32-828547253 - Conduit (.250 Inside Di [ More info ]
|
| #NS | 32-828547T 1 | CONDUIT (1 required per assembly) (.500 x 3.00 Feet Bulk) (Cut As Required) |
  |
|
32-828547T 1 - Conduit (.500 Inside Di [ More info ]
|
| #15 | 84-40592A 2 | HARNESS ASSEMBLY (1 required per assembly) (Marked 84-40592A1) (Aft Motor Jumper) |
  |
|
84-40592A 2 - Harness Assembly [ More info ] Unavailable |
| #16 | 84-40568A 2 | HARNESS ASSEMBLY (1 required per assembly) (Marked 84-40568A1) (Equalizer Out To Switch/Breaker) |
  |
|
84-40568A 2 - Harness Assembly [ More info ] Unavailable |
