Parts for MerCruiser 5.7L MPI MIE EC Standard Cooling System -inline
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 32-8M2004196 | HOSE, Power Steering Cooler to Y-Fitting (1 required per assembly) |
  |
|
32-8M2004196 - Hose - Power Steering Cooler [ More info ]
|
| #2 | 863841T | TUBE, Water (1 required per assembly) |
  |
|
863841T - Tube - Extender [ More info ]
|
| #3 | 32-42850 69 | HOSE, (44.00 Inches Bulk), Exhaust Manifold to Orifice Fitting (1 required per assembly) (Port 9 Inches, Starboard 3.5 Inches) |
  |
32-42850 69 - Hose -44 Inch [ More info ] Unavailable |
|
  |
|
32-8M0062634 - Transom to Thermostat Housing Hose -44I [ More info ]
|
| #4 | 32-863456A 1 | HOSE ASSEMBLY, Thermostat Housing to Circulating Pump (1 required per assembly) |
  |
|
32-863456A 1 - Hose [ More info ]
|
| #5 | 32-864393 | HOSE, Thermostat Housing to Port Manifold (1 required per assembly) |
  |
|
32-864393 - Hose - Thermosat Housing To Port Manifold [ More info ]
|
| #6 | 32-863459 | HOSE, Thermostat Housing to Starboard Manifold (1 required per assembly) |
  |
|
32-863459 - Hose - Thermostat Housing To Starboard Manifold [ More info ]
|
| #7 | 32-8M2003797 | HOSE, Distribution Housing to Thermostat Housing (1 required per assembly) |
  |
|
32-8M2003797 - Hose - Distribution Housing To Thermostat Housing [ More info ]
|
| #8 | 22-862603 | FITTING, Male Quick Connector, Threaded - Engine Block (2 required per assembly) |
  |
22-862603 - Adaptor -quick Cnt [ More info ] Unavailable |
|
  |
|
228M0180470 - Adaptor-QUICK CNT [ More info ]
|
| #9 | 22-864989A01 | FITTING ASSEMBLY, Lower Distribution (1 required per assembly) |
  |
22-864989A01 - Drain Fitting Assembly [ More info ] Unavailable |
|
  |
|
22-8M0219211 - FITTING-DRAIN ASY [ More info ] Unavailable |
| #10 | 32-862317 5 | HOSE, Cylinder Block Drain to Distribution Fitting (2 required per assembly) Port 23 Inches, Starboard 17 Inches |
  |
32-8623175 - Hose [ More info ] Unavailable |
|
  |
|
32-8M0062590 - Hose=3/8 Push Lck [ More info ]
|
| #11 | 32-863490 | HOSE, Water Drain Accumulator to Distribution Fitting (1 required per assembly) |
  |
|
32-863490 - Hose - Distribution Fitting To Accumulator Housing [ More info ]
|
| #12 | 32-865394 | HOSE (1 required per assembly) |
  |
|
32-865394 - Hose [ More info ]
|
| #13 | 32-865337 | HOSE, Sea Pump to Water Orifice (1 required per assembly) 3 Point Drain |
  |
32-865337 - Hose - Sea Water Pump To Water Orifice [ More info ] Unavailable |
|
  |
|
32-8M2021656 - Hose [ More info ]
|
| #13 | 32-865234 | HOSE, Sea Pump to Water Orifice (1 required per assembly) Air Actuated Drain |
  |
|
32-865234 - Hose - Sea Water Pump To Water Orifice [ More info ]
|
| #14 | NA | NOT AVAILABLE, Orifice Meter Assembly (1 required per assembly) See 'Cool Fuel System -Bravo' page for service part number |
  |
|
NA - NOT AVAILABLE [ More info ] Unavailable |
| #15 | 32-865235 | HOSE, Water Orifice to Power Steering Cooler (1 required per assembly) |
  |
32-865235 - Hose [ More info ] Unavailable |
|
  |
|
32-8M2021655 - Hose [ More info ]
|
| #16 | 32-865672079 | HOSE, (96.00 Inches Bulk), Transom Water Pick Up to Sea Water Pump (1 required per assembly) |
  |
32-865672079 - Hose-96 Inch [ More info ] Unavailable |
|
  |
|
32-8M0062666 - Water Hose Bulk -96" [ More info ]
|
| #17 | 32-8M2004199 | HOSE, Y-Fitting to Drain Fitting (1 required per assembly) |
  |
|
32-8M2004199 - Hose - Y Fitting To Drain Fitting [ More info ]
|
| #18 | 22-862225 | FITTING, Pushlock - Block Drian Hose (4 required per assembly) |
  |
|
22-862225 - Coupling Assembly [ More info ]
|
| #19 | 32-8M2003791 | HOSE, Y-Fitting to Tee Fitting (1 required per assembly) (Short Cooler) MIE Only |
  |
|
32-8M2003791 - Hose - Y Fitting To Tee Fitting [ More info ]
|
| #19 | 32-8M2004095 | HOSE, Y-Fitting to Tee Fitting (1 required per assembly) (Long Cooler) |
  |
|
32-8M2004095 - Hose - Y Fitting To Tee Fitting [ More info ]
|
| #20 | 22-8M2014000 | FITTING, Tee (1 required per assembly) |
  |
|
22-8M2014000 - Tee [ More info ]
|
| #21 | 25-62702 1 | O-RING, (.301 x .070) (2 required per assembly) |
  |
|
25-62702 1 - O-Ring [ More info ]
|
| #22 | 32-8M2005437 | HOSE, Tee Fitting to Port Elbow (1 required per assembly) |
  |
|
32-8M2005437 - Hose - Tee Fitting To Port Elbow [ More info ]
|
| #23 | 32-8M2005436 | HOSE, Tee Fitting to Starboard Elbow (1 required per assembly) |
  |
|
32-8M2005436 - Hose - Tee Fitting To Starboard Elbow [ More info ]
|
| #24 | 54-815504212 | CLAMP, Worm Gear (2 required per assembly) |
  |
|
54-815504212 - Clamp [ More info ] Unavailable |
| #25 | 54-815504216 | CLAMP, Worm Gear (1.56 Diameter) (AR required per assembly) |
  |
|
54-815504216 - Clamp [ More info ] Unavailable |
| #26 | 54-815504228 | CLAMP, Worm Gear (AR required per assembly) |
  |
|
54-815504228 - Clamp [ More info ]
|
  |
|
54-8M0232395 - CLAMP HOSE [ More info ] Unavailable |
| #27 | 54-8M2001490 | CLAMP, Worm Gear (1 required per assembly) |
  |
54-8M2001490 - Clamp [ More info ] Unavailable |
|
  |
|
54-815504232 - Clamp [ More info ]
|
| #29 | 54-815504222 | CLAMP, Worm Gear (1.98 DIameter) (3 required per assembly) |
  |
54-815504222 - Clamp - See Note On Detail Page [ More info ] Unavailable |
|
  |
|
54-8M0188622 - CLAMP [ More info ] Unavailable |
| #30 | 32-865672013 | HOSE, (4.00 Inches) (1 required per assembly) |
  |
32-865672013 - Hose - 4 Inch [ More info ] Unavailable |
|
  |
|
32-8M0062653 - Water Hose 4 IN [ More info ]
|
| #31 | 22-865362 | QUICK CONNECT, Transom Hose (1 required per assembly) |
  |
|
22-865362 - Spigot-q/C [ More info ]
|
| #32 | 22-865324 | QUICK CONNECT, Transom Hose (2 required per assembly) |
  |
|
22-865324 - Fitting -q/C [ More info ]
|
| #33 | 22-8M2003728 | Y-FITTING (1 required per assembly) |
  |
|
22-8M2003728 - Fitting [ More info ]
|
| #34 | 32-866331 | HOSE (1 required per assembly) |
  |
|
32-866331 - Hose [ More info ]
|
| #35 | 22-862993 | FITTING, Y, (2) 1-1/4 In. Hose Barbs / (1) 3/4 In. Hose Barb (1 required per assembly) |
  |
|
22-862993 - Fitting - Water [ More info ]
|
