Parts for MerCruiser 5.0L MPI Alpha / Bravo Standard Cooling System - Bravo, 7 Point Drain

Revise Search: All Models > 5.0L MPI Alpha / Bravo > 1A300000 - 1A611927 > Standard Cooling System - Bravo, 7 Point Drain

« Previous

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	32-865674	HOSE, Power Steering Cooler to Drain Fitting (1 required per assembly)
		32-865674 - Hose - Power Steering Cooler To Drain Fitting [ More info ] $73.49 Available to Order: Shipping delay up to 10 days.
#2	32-865235	HOSE, Water Orifice to Power Steering Cooler (1 required per assembly)
		32-865235 - Hose [ More info ] Unavailable
		32-8M2021655 - Hose [ More info ] $81.49 Available to Order: Shipping delay up to 10 days.
#3	32-865409	HOSE, Drain Fitting to Thermostat Housing (1 required per assembly)
		32-865409 - Hose - Drain Fitting To Thermostat Housing [ More info ] $54.99 Available to Order: Shipping delay up to 10 days.
#4	22-866725	FITTING, Straight (.750-14), Barb (1 required per assembly)
		22-866725 - Brass Fitting, 3/4 NPT [ More info ] $18.29 In Stock
		18-4461 - Brass Connector [ More info ] $13.99 $13.86 1 In Stock.
#5	32-864703A 1	HOSE, Circulating Pump to Drain Elbow (1 required per assembly)
		32-864703A 1 - Hose Assembly [ More info ] $84.49 Available to Order: Shipping delay up to 10 days.
#6	32-864979	HOSE, Starboard Exhaust Elbow to Thermostat Housing (1 required per assembly)
		32-864979 - Hose [ More info ] $49.49 Available to Order: Shipping delay up to 10 days.
#7	32-863459	HOSE, Thermostat Housing to Starboard Manifold (1 required per assembly)
		32-863459 - Hose - Thermostat Housing To Starboard Manifold [ More info ] $57.17 1 In Stock.
#8	32-863458	HOSE, Thermostat Housing to Port Manifold (1 required per assembly)
		32-863458 - Hose - Thermostat Housing To Port Manifold [ More info ] $63.49 Available to Order: Shipping delay up to 10 days.
#9	32-865337	HOSE, Sea Water Pump to Water Orifice (1 required per assembly)
		32-865337 - Hose - Sea Water Pump To Water Orifice [ More info ] Unavailable
		32-8M2021656 - Hose [ More info ] $31.99 Available to Order: Shipping delay up to 10 days.
#10	NA	NOT AVAILABLE, Orifice Meter Assembly (1 required per assembly) (See Cool Fuel System -Bravo page for service part number
		NA - NOT AVAILABLE [ More info ] Unavailable
#11	32-865672079	HOSE, (96.00 Inches Bulk), Transom Assembly to Power Steering Coller (1 required per assembly) Alpha
		32-865672079 - Hose-96 Inch [ More info ] Unavailable
		32-8M0062666 - Water Hose Bulk -96" [ More info ] $220.99 $218.15 Available to Order: Shipping delay up to 10 days.
#12	861505	FITTING, Drain Tee (1 required per assembly)
		861505 - Drain Insert [ More info ] $15.69 Available to Order: Shipping delay up to 10 days.
#13	863841T	TUBE, Water, Brass (1 required per assembly) Compact Hydralic Steering
		863841T - Tube - Extender [ More info ] $166.49 Available to Order: Shipping delay up to 10 days.
#14	32-864435	HOSE, Port Exhaust Elbow to Thermostat Housing (1 required per assembly)
		32-864435 - Hose - Port Exhaust Elbow To Thermostat Housing [ More info ] $57.43 1 In Stock.
#15	22-862210A01	ELBOW KIT, Drain (2 required per assembly)
		22-862210A01 - Elbow Kit [ More info ] $29.09 In Stock
		18-4224 - Drain Elbow 22-806926A1 [ More info ] $11.15 10+ In Stock.
#16	22-806608A02	PLUG ASSEMBLY, (.500-13) Blue (9 required per assembly)
		22-806608A02 - Plug Assembly - Priced Individually [ More info ] $3.05 4 In Stock.
		22-8M0119211 - Drain Plug, Priced Individually, .5 inch x 13 [ More info ] $10.19 10+ In Stock.
		18-4226 - Blue Drain Plug, 22-806608A1 [ More info ] $4.10 10+ In Stock.
		22-806608Q01 - Plug - Priced Individually [ More info ] $10.29 1 In Stock.
#17	25-8M2000926	SEAL (9 required per assembly)
		25-8M2000926 - Seal - Priced Individually [ More info ] $1.39 10+ In Stock.
		25-26802 - O-ring, (.424 X .103) [ More info ] $2.89 8 In Stock.
#18	22-860088	BUSHING (4 required per assembly)
		22-860088 - Bushing [ More info ] Unavailable
		22-8M0214973 - Cylinder Block Adaptor Bushing ZZ [ More info ] $12.79 8 In Stock.
#19	22-46982	FITTING, (90 Degree) (1 required per assembly)
		22-46982 - Fitting [ More info ] $28.51 10+ In Stock.
#20	54-815504216	CLAMP, Worm Gear (1.56 Diameter) (4 required per assembly)
		54-815504216 - Clamp [ More info ] Unavailable
#21	54-815504228	CLAMP, Worm Gear (11 required per assembly)
		54-815504228 - Clamp [ More info ] $17.29 Available to Order: Shipping delay up to 10 days.
		54-8M0232395 - CLAMP HOSE [ More info ] Unavailable
#22	54-8M2001490	CLAMP, Worm Gear (4 required per assembly)
		54-8M2001490 - Clamp [ More info ] Unavailable
		54-815504232 - Clamp [ More info ] $8.89 10+ In Stock.
#23	22-866729	FITTING, (.250 x .250 NPTF) (1 required per assembly)
		22-866729 - Fitting - Adapter [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#24	54-815504222	CLAMP, Worm Gear (1.98 DIameter) (3 required per assembly)
		54-815504222 - Clamp - See Note On Detail Page [ More info ] Unavailable
		54-8M0188622 - CLAMP [ More info ] Unavailable
#25	32-865672013	HOSE, (4.00 Inches) (1 required per assembly)
		32-865672013 - Hose - 4 Inch [ More info ] Unavailable
		32-8M0062653 - Water Hose 4 IN [ More info ] $7.39 Available to Order: Shipping delay up to 10 days.
#26	22-865362	QUICK CONNECT (1 required per assembly)
		22-865362 - Spigot-q/C [ More info ] $9.69 Available to Order: Shipping delay up to 10 days.
#27	22-865324	QUICK CONNECT (2 required per assembly)
		22-865324 - Fitting -q/C [ More info ] $11.79 Available to Order: Shipping delay up to 10 days.
