Parts for MerCruiser 270 (2 Barrel.) GM 350 V-8 1969-1972 Carburetor Assembly, Complete

Revise Search: All Models > 270 (2 Barrel.) GM 350 V-8 1969-1972 > 2851074 - 3077735 > Carburetor Assembly, Complete

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	1397-3315	SPRING AND CAM KIT, AIR VALVE (1 required per assembly)
		1397-3315 - Carburetor Spring & Cam Kit, NLA [ More info ] Unavailable
#	1397-3465	OFF ENGINE KIT (1 required per assembly)
		1397-3465 - POWER Carburetor Kit [ More info ] Unavailable
		1397-5635 - Overhaul Kit [ More info ] Unavailable
		1397-9723 - Carburetor Repair Kit [ More info ] Unavailable
		823426A 1 - Repair Kit for Rochester 4 Barrel QuadraJet Carb [ More info ] $43.99 1 In Stock.
		18-7095 - Carburetor Kit 1397-9723 [ More info ] $36.59 $33.53 10 In Stock.
		18-7077 - Carburetor Repair Kit for Rochester 4bbl QuadraJet, 1397-8952 [ More info ] $38.19 $37.05 4 In Stock.
		18-7072 - Carburetor Kit 823426A1 [ More info ] $37.01 4 In Stock.
#	1347-4180A 1	CARBURETOR ASSEMBLY, COMPLETE (1 required per assembly)
		1347-4180A 1 - Carburetor [ More info ] Unavailable
		1347-4536A 1 - Carburetor [ More info ] Unavailable
#	1397-4329	OVERHAUL KIT (1 required per assembly)
		1397-4329 - Overhaul Kit [ More info ] Unavailable
#	1397-3309	GASKET SET (1 required per assembly)
		1397-3309 - Carburetor Gasket Set [ More info ] Unavailable
#1	1397-4330	AIR HORN ASSEMBLY (1 required per assembly)
		1397-4330 - Air Horn Assembly [ More info ] Unavailable
#2	1397-3314	LEVER, AIR VALVE LOCKOUT (1 required per assembly)
		1397-3314 - Air Valve Lockout Lever [ More info ] Unavailable
		1397-5640 - NLA NLA [ More info ] Unavailable
#3		ROLL PIN, LOCKOUT LEVER (1 required per assembly)
#4	1397-3313	HOLDER KIT, SECONDARY METERING ROD (1 required per assembly)
		1397-3313 - Metering Rod Holder Kit [ More info ] Unavailable
#5	1397-4331	METERING ROD, SECONDARY (2 required per assembly)
		1397-4331 - NLA NLA [ More info ] Unavailable
#6	10-48137	SCREW, AIR HORN TO FLOAT BOWL (3/8") (2 required per assembly)
		10-48137 - ,NLA [ More info ] Unavailable
#7	10-34370	SCREW, AIR HORN TO FLOAT BOWL (1") (5 required per assembly)
		10-34370 - SCREW,NLA [ More info ] Unavailable
#8	10-48395	SCREW, AIR HORN TO FLOAT BOWL (3") (2 required per assembly)
		10-48395 - ,NLA [ More info ] Unavailable
#9	1397-3311	LEVER, ACTUATING - PUMPING (1 required per assembly)
		1397-3311 - LEVER [ More info ] Unavailable
		1397-4586 - LEVER [ More info ] Unavailable
		1397-5638 - Pump Actuating Lever [ More info ] Unavailable
#19	1397-4326	CHOKE SHAFT AND LEVER ASSEMBLY (1 required per assembly)
		1397-4326 - Choke Shaft And Lever Assembly [ More info ] Unavailable
#19	52730	CHOKE LEVER (1 required per assembly)
		52730 - LEVER,NLA [ More info ] Unavailable
#20	10-27881	SCREW, CHOKE LEVER ATTACHING (1 required per assembly)
		10-27881 - SCREW,NLA [ More info ] Unavailable
#21	13-26994	LOCKWASHER, CHOKE LEVER SCREW (1 required per assembly)
		13-26994 - LockWasher, NLA [ More info ] $0.80 $0.68 10+ In Stock.
#22	11-21270	NUT, CHOKE LEVER SCREW (1 required per assembly)
		11-21270 - NUT,NLA [ More info ] Unavailable
#23	1397-4327	VALVE, CHOKE - CHOKE SHAFT (1 required per assembly)
		1397-4327 - Choke Valve [ More info ] Unavailable
#24	10-48139	SCREW, CHOKE VALVE TO CHOKE SHAFT (2 required per assembly)
		10-48139 - ,NLA [ More info ] Unavailable
#25	1397-3327	FLOAT ASSEMBLY (1 required per assembly)
		1397-3327 - Float, NLA [ More info ] Unavailable
		18-7201 - Float 1397-3327 [ More info ] $23.73 2 In Stock.
#26	17-48140	PIN, HINGE - FLOAT (1 required per assembly)
		17-48140 - Pin, Hinge - Float,NLA [ More info ] Unavailable
#27	1397-3323	LEVER, INTERMEDIATE CHOKE (1 required per assembly)
		1397-3323 - Intermediate Choke Lever [ More info ] Unavailable
#28	1397-3332	BAFFLE, FLOAT BOWL (1 required per assembly)
		1397-3332 - Float Bowl Baffle [ More info ] Unavailable
#29	1397-3324	ROD, CHOKE (1 required per assembly)
		1397-3324 - Rod Choke [ More info ] $1.50 $1.28 2 In Stock.
#31	1397-3318	ROD, VACUUM CONTROL (1 required per assembly)
		1397-3318 - Vacuum Control Rod [ More info ] Unavailable
#33	1397-3339	BRACKET ASSEMBLY, VACUUM CONTROL (1 required per assembly)
		1397-3339 -Vacuum Control Bracket Assembly [ More info ] Unavailable
#34	10-48138	SCREW, VACUUM CONTROL BRACKET TO FLOAT BOWL (1 required per assembly)
		10-48138 - ,NLA [ More info ] Unavailable
#35	1397-3317	CONTROL ASSEMBLY, VACUUM (1 required per assembly)
		1397-3317 - Control, NLA [ More info ] Unavailable
#36	1397-3320	HOSE, VACUUM (1 required per assembly)
		1397-3320 - VACUUM Hose, NLA [ More info ] Unavailable
#37	1397-3328	POWER PISTON ASSEMBLY (1 required per assembly)
		1397-3328 - Piston, NLA [ More info ] Unavailable
#38	24-48142	SPRING, METERING ROD - PRIMARY (1 required per assembly)
		24-48142 - Spring [ More info ] Unavailable
#39	1397-3329	RETAINER, POWER PISTON (1 required per assembly)
		1397-3329 -Power Piston Retainer [ More info ] Unavailable
#40	1397-3326	RETAINER, PUMP DISCHARGE BALL (1 required per assembly)
		1397-3326 - Retainer [ More info ] Unavailable
#42	24-48141	SPRING, POWER PISTON (1 required per assembly)
		24-48141 - Spring, Power Piston,NLA [ More info ] $2.50 $2.13 1 In Stock.
#43	1397-3331	INSERT, FLOAT BOWL (1 required per assembly)
		1397-3331 - Carburetor Bowl Insert, NLA [ More info ] Unavailable
#44	1397-4332	FLOAT BOWL ASSEMBLY (1 required per assembly)
		1397-4332 - Float Bowl Assembly [ More info ] Unavailable
#45	10-48144	SCREW, IDLE STOP (1 required per assembly)
		10-48144 - ,NLA [ More info ] Unavailable
#46	24-34373	SPRING, IDLE STOP SCREW (1 required per assembly)
		24-34373 - Spring [ More info ] Unavailable
#47	24-48143	SPRING, FILTER NUT (1 required per assembly)
		24-48143 - Spring, Fuel Filter [ More info ] $9.29 10+ In Stock.
		3302-9032 - Spring, Fuel Strainer [ More info ] $7.89 Available to Order: Shipping delay up to 10 days.
#48	35-53336	FILTER, FUEL INLET (1 required per assembly)
		35-53336 - Fuel Filter - Carburetor [ More info ] $4.43 10+ In Stock.
		35-53336Q - Fuel Filter - Priced Individually [ More info ] $10.39 Available to Order: Shipping delay up to 10 days.
		18-7859 - Filter, 3302-9033 [ More info ] $7.67 2 In Stock.
		35-53336T - Fuel Filter - Priced Individually [ More info ] $11.39 Available to Order: Shipping delay up to 10 days.
#49	1397-3330	NUT, FILTER - FUEL INLET (1 required per assembly)
		1397-3330 - Nut, Filter - Fuel Inlet,NLA [ More info ] $36.45 10+ In Stock.
#52	1397-3333	ROD, PUMP (1 required per assembly)
		1397-3333 - Pump Rod [ More info ] Unavailable
#54	1397-4385	THROTTLE BODY ASSEMBLY (1 required per assembly)
		1397-4385 - Throttle Body Assembly [ More info ] Unavailable
#56	24-33050	SPRING, IDLE NEEDLE (2 required per assembly)
		24-33050 - Spring, Idle Adjusting Needle [ More info ] $1.88 $1.59 4 In Stock.
#57	1397-4333	SCREW, THROTTLE BODY TO FLOAT BOWL (3 required per assembly)
		1397-4333 - Screw [ More info ] Unavailable
#58	1397-3335	LEVER, CAM (1 required per assembly)
		1397-3335 - Cam Lever [ More info ] Unavailable
#59	1397-3336	LEVER, FAST IDLE (1 required per assembly)
		1397-3336 - Fast Idle Lever [ More info ] Unavailable
#60	10-48146	SCREW, LEVER AND CAM TO THROTTLE BODY (1 required per assembly)
		10-48146 - ,NLA [ More info ] Unavailable
