Parts for Mariner W-55 HP Ignition System

Revise Search: All Models > W-55 HP > 663-578278 & Up (ML) > Ignition System

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	253-8816M	C.D.I. MAGNETO ASSEMBLY (1 required per assembly)
		253-8816M - Flywheel, NLA [ More info ] Unavailable
#2	41303M	FLYWHEEL ASSEMBLY (1 required per assembly)
		41303M - ROTOR,NLA [ More info ] Unavailable
#3	41304M	BASE ASSEMBLY (1 required per assembly)
		41304M - Base, NLA [ More info ] Unavailable
#4	41829M	COIL (CHARGE) (1 required per assembly)
		41829M - COIL [ More info ] Unavailable
		41829T - Coil, NLA [ More info ] $132.00 $111.80 10+ In Stock.
#5	10-96346M	SCREW (2 required per assembly)
		10-96346M - SCREW,NLA [ More info ] Unavailable
#6	41830M	COIL, TRIGGER (1 required per assembly)
		41830M - Coil, NLA [ More info ] $88.99 $75.37 10+ In Stock.
#7	10-91691M	SCREW (1 required per assembly)
		10-91691M - Screw, NLA Z [ More info ] $1.25 $1.06 8 In Stock.
#8	41831M	COIL, LIGHTING (1 required per assembly)
		41831M - Coil, NLA [ More info ] Unavailable
#9	10-97803M	SCREW (2 required per assembly)
		10-97803M - Screw, NLA [ More info ] Unavailable
#10	84305M	BALL JOINT (1 required per assembly)
		84305M - Ball Joint [ More info ] $13.99 Available to Order: Shipping delay up to 10 days.
#11	97074M	TIMING PLATE (1 required per assembly)
		97074M - POINTER,NLA [ More info ] Unavailable
#12	10-84247M	BOLT (1 required per assembly)
		10-84247M - BOLT Note: Priced Individually [ More info ] Unavailable
		10-91725M - BOLT [ More info ] Unavailable
		10-826957M - Bolt, NLA [ More info ] $5.19 10+ In Stock.
#13	12-82214M	WASHER (12 required per assembly)
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#14	82678M	RETAINER (1 required per assembly)
		82678M - Retainer,NLA [ More info ] Unavailable
#15	10-83539M	BOLT (7 required per assembly)
		10-83539M - 10-83539M - BOLT (M6 x 20) [ More info ] Unavailable Replaced by 10-84058M
		10-84058M - Bolt [ More info ] $7.79 1 In Stock.
#16	12-81343M	WASHER (1 required per assembly)
		12-81343M - Washer,base Ass'y, NLA [ More info ] $3.00 $2.54 4 In Stock.
#17	11-81773M	NUT (1 required per assembly)
		11-81773M - Nut, Flywheel [ More info ] $7.99 5 In Stock.
		11893789 - Nut [ More info ] $9.79 Available to Order: Shipping delay up to 10 days.
#18	12-84436M	WASHER (1 required per assembly)
		12-84436M - Washer, Flywheel [ More info ] Unavailable
		12-893762 - Washer - Priced Individually [ More info ] $4.09 1 In Stock.
#19	41302M	BRACKET (1 required per assembly)
		41302M - Bracket, NLA [ More info ] Unavailable
#20	25-93114M	GROMMET (4 required per assembly) SERIAL (M-271949 ML-586106) AND ABOVE
		25-93114M - O RING [ More info ] Unavailable
		25-881304 - Damper [ More info ] $5.99 Available to Order: Shipping delay up to 10 days.
#20	81523M	GROMMET (4 required per assembly) SERIAL (M-271948 ML-586105) AND BELOW
		81523M - Mount, NLA [ More info ] Unavailable
#21	23-82851M	BUSHING (4 required per assembly)
		23-82851M - Bushing [ More info ] Unavailable
		23-804344003 - Collar [ More info ] $2.29 1 In Stock.
#22	10-95629M	BOLT (W/WASHER) (4 required per assembly) SERIAL (M-271272 ML-581824) AND ABOVE
		10-95629M - Bolt, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#22	10-82405M	BOLT (4 required per assembly) SERIAL (M-271271 ML-581823) AND BELOW
		10-82405M - Screw, NLA [ More info ] $10.86 $9.19 10+ In Stock.
#23	13-82212M	LOCKWASHER (3 required per assembly)
		13-82212M - LockWasher - Priced Individually [ More info ] $1.10 10+ In Stock.
#24	12-83769M	WASHER (4 required per assembly) SERIAL (M-271271 ML-581823) AND BELOW
		12-83769M - Washer, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#25	10-84303M	BOLT (1 required per assembly)
		10-84303M - Screw , Priced Individually [ More info ] $0.72 1 In Stock.
		10-813477M - BOLT [ More info ] Unavailable
		10-91772M - Bolt [ More info ] $5.42 $4.59 10+ In Stock.
#26	41305M	C.D.I.ASSEMBLY (1 required per assembly)
		41305M - Switch Box, NLA [ More info ] $99.00 $83.85 1 In Stock.
		18-99317 - Ignition Pack, Yamaha 2 Cylinder , 117-696-12 [ More info ] $246.51 $199.31 1 In Stock.
#27	41306M	CONTROL ASSEMBLY (1 required per assembly)
		41306M - Control Unit, NLA [ More info ] Unavailable
#28	95188M	IGNITION COIL ASSEMBLY (1 required per assembly)
		95188M - Ignition Coil [ More info ] Unavailable
		95188T - Igition Coil [ More info ] Unavailable
#29	80935M	CAP (NOISE SUPPRESSOR) (OPT required per assembly)
		80935M - Protector [ More info ] Unavailable
		814991M - Plug Cap [ More info ] Unavailable
		85-815119M - Protector [ More info ] Unavailable
#29	82788M	CAP (2 required per assembly)
		82788M - Protector - Priced Individually [ More info ] $5.21 4 In Stock.
		85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ] $8.19 8 In Stock.
#30	41833M	CLAMP (1 required per assembly)
		41833M - CLAMP,NLA [ More info ] Unavailable
#31	41834M	CLAMP (1 required per assembly)
		41834M - CLAMP,NLA [ More info ] Unavailable
#32	41835M	COVER (1 required per assembly)
		41835M - Cover [ More info ] $7.00 $5.93 2 In Stock.
#33	10-83285M	BOLT (2 required per assembly)
		10-83285M - Screw - Priced Individually [ More info ] $5.19 10+ In Stock.
#34	54-95636M	CLAMP (1 required per assembly)
		54-95636M - Clamp [ More info ] $1.25 $1.06 5 In Stock.
#35	87-97834M	THERMO-SWITCH ASSEMBLY (1 required per assembly)
		87-97834M - Switch [ More info ] $22.22 $18.82 10+ In Stock.
#36	97835M	PLATE (1 required per assembly)
		97835M - Plate [ More info ] $5.56 $4.71 3 In Stock.
#37	10-84315M	BOLT (1 required per assembly)
		10-84315M - BOLT [ More info ] Unavailable
		10-84088M - Bolt [ More info ] $3.40 5 In Stock.
#38	54-83577M	CLAMP (1 required per assembly)
		54-83577M - Clamp [ More info ] $1.50 $1.28 4 In Stock.
#39	84-41310M	GROUND WIRE (1 required per assembly)
		84-41310M - Lead Wire, NLA [ More info ] Unavailable
#40	84-81250M	GROUND WIRE (1 required per assembly)
		84-81250M - Ground Cable, NLA [ More info ] $2.50 $2.13 3 In Stock.
#42	84-97078M	GROUND WIRE (1 required per assembly)
		84-97078M - Wire, NLA [ More info ] Unavailable
