Parts for Mariner K 40 HP Steering Handle
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 11872M | STEERING HANDLE ASSEMBLY (1 required per assembly) |
  |
|
11872M - STEERING HANDLE K40,NLA [ More info ] Unavailable |
| #1 | 84971M | HANDLE (1 required per assembly) |
  |
|
84971M - Steering Handle, NLA [ More info ]
|
| #2 | 81585M | GRIP (1 required per assembly) |
  |
|
81585M - Handle A [ More info ] Unavailable |
| #3 | 10-811916M | SCREW (1 required per assembly) |
  |
|
10-811916M - Screw, NLA [ More info ]
|
| #4 | 95497 1 | HANDLE RUBBER (1 required per assembly) |
  |
95497 1 - Grip [ More info ] Unavailable |
|
  |
|
8M0080456 - Grip [ More info ]
|
| #5 | 10-11873M | SCREW (1 required per assembly) |
  |
|
11873M - Indicator, NLA [ More info ]
|
| #6 | 17-81907M | RIVET (1 required per assembly) |
  |
|
17-81907M - Rivet, NLA [ More info ]
|
| #7 | 12-82220M | WASHER (1 required per assembly) |
  |
|
12-82220M - Washer - Priced Individually [ More info ] Unavailable |
| #8 | 24-82095M | SPRING (1 required per assembly) |
  |
|
24-82095M - Spring, Throttle Shaft,NLA [ More info ]
|
| #9 | 23-81945M | BUSHING (1 required per assembly) |
  |
|
23-81945M - Bushing, NLA [ More info ]
|
| #10 | 83516M | SHAFT (1 required per assembly) |
  |
|
83516M - Shaft, NLA [ More info ]
|
| #11 | 43-80778M | GEAR (1 required per assembly) |
  |
|
43-80778M - Gear, Pinion, NLA [ More info ]
|
| #12 | 17-82151M | PIN (1 required per assembly) |
  |
|
17-82151M - Pin -roll [ More info ]
|
| #13 | 83517M | BRACKET (1 required per assembly) |
  |
|
83517M - Bracket, NLA [ More info ] Unavailable |
| #14 | 10-84058M | BOLT, (M6 x 20) (2 required per assembly) |
  |
|
10-84058M - Bolt [ More info ]
|
| #15 | 12-881379 | WASHER (2 required per assembly) |
  |
|
12-881379 - 12-881379 - WASHER [ More info ] Unavailable Replaced by 12-82214M |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #16 | 43-83518M | PINION (1 required per assembly) |
  |
|
43-83518M - Pinion Gear, NLA [ More info ]
|
| #17 | 23-83519M | BUSHING (1 required per assembly) |
  |
|
23-83519M - Bushing, NLA [ More info ]
|
| #18 | 11-82389M | NUT (1 required per assembly) |
  |
|
11-82389M - Nut, NLA [ More info ] Unavailable |
| #19 | 13-82212M | LOCKWASHER (1 required per assembly) |
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #20 | 11871M | THROTTLE WIRE (2 required per assembly) |
  |
|
11871M - Throttle Wire, NLA [ More info ]
|
| #21 | 83521M | HOLDER (1 required per assembly) |
  |
|
83521M - Holder, NLA [ More info ] Unavailable |
| #22 | 12-82211M | WASHER (2 required per assembly) |
  |
|
12-82211M - Washer - Priced Individually [ More info ]
|
| #23 | 83522M | HOLDER (1 required per assembly) |
  |
|
83522M - Wire Holder, NLA [ More info ]
|
| #24 | 10-84313M | BOLT (2 required per assembly) |
  |
|
10-84313M - Bolt, NLA [ More info ]
|
| #25 | 11-81786M | NUT (1 required per assembly) |
  |
|
11-81786M - Nut, Nylon,NLA [ More info ]
|
| #26 | 12-81853M | WASHER (2 required per assembly) |
  |
|
12-81853M - Washer, Arm Bolt, NLA [ More info ]
|
| #27 | 12-81815M | WASHER (2 required per assembly) |
  |
|
12-81815M - Washer, NLA [ More info ] Unavailable |
| #28 | 13-81870M | WASHER (1 required per assembly) |
  |
|
13-81870M - Wave Washer, NLA [ More info ] Unavailable |
| #29 | 23-81950M | BUSHING (1 required per assembly) |
  |
|
23-81950M - Bushing, NLA [ More info ]
|
| #30 | 10-94514M | BOLT (1 required per assembly) |
  |
|
10-94514M - Bolt, NLA [ More info ]
|
| #31 | 12-83524M | WASHER (1 required per assembly) |
  |
|
12-83524M - Washer, NLA [ More info ]
|
| #32 | M-82895M | FRICTION PIECE (1 required per assembly) |
  |
|
82895M - Guide, NLA [ More info ]
|
| #34 | 11-83056M | NUT (1 required per assembly) |
  |
|
11-83056M - Nut, Nylon, NLA [ More info ]
|
