Parts for Mariner 9.9C HP Electric Start

Revise Search: All Models > 9.9C HP > 682-250946 & Up (E) > Electric Start

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#0-1	50-98982M	STARTER MOTOR (1 required per assembly)
		50-98982M - Starter,NLA [ More info ] Unavailable
#1	84330M	ARMATURE (1 required per assembly)
		84330M - Armature, NLA [ More info ] Unavailable
#2	12-84331M	WASHER KIT (1 required per assembly)
		12-84331M - WASHER,NLA [ More info ] Unavailable
#3	84332M	PINION STOPPER SET (1 required per assembly)
		84332M - Pinion Stopper, NLA [ More info ] Unavailable
#4	98983M	FIELD (682-81800-11/OR -12 ONLY) (1 required per assembly)
		98983M - FIELD ASSY,NLA [ More info ] Unavailable
#4	NLA	FIELD (ALL OTHERS) (1 required per assembly)
		NLA - No Longer Availab [ More info ] Unavailable
#5	84334M	COVER ASSEMBLY (1 required per assembly)
		84334M - Cover Assembly [ More info ] Unavailable
#6	84335M	BRUSH HOLDER (1 required per assembly)
		84335M - BRUSH HOLDER,NLA [ More info ] Unavailable
#7	24-84336M	SPRING (2 required per assembly)
		24-84336M - Spring, NLA [ More info ] $2.50 $2.13 3 In Stock.
#8	84337M	BRUSH (+) (1 required per assembly)
		84337M - Brush, NLA [ More info ] Unavailable
#9	84338M	BRUSH (-) (1 required per assembly)
		84338M - Brush, NLA [ More info ] $5.00 $4.24 9 In Stock.
#10	43-84339M	PINION GEAR (1 required per assembly)
		43-84339M - Pinion Gear [ More info ] Unavailable
#11	84340M	COVER (1 required per assembly)
		84340M - Cover, NLA [ More info ] Unavailable
#12	10-84341M	THRU BOLT (2 required per assembly)
		10-84341M - BOLT-THRU,NLA [ More info ] Unavailable
#13	25-14258M	O-RING NEW DESIGN (2 required per assembly)
		25-14258M - O RING,NLA [ More info ] Unavailable
#14	53-14752M	SNAP RING NEW DESIGN (1 required per assembly)
		53-14752M - Snap Ring, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#15	14215M	BRACKET (SEE NOTE #3) (1 required per assembly)
		14215M - Bracket, NLA [ More info ] $16.77 4 In Stock.
#15	84095M	BRACKET (SEE NOTE #4) (1 required per assembly)
		84095M - Bracket, NLA [ More info ] Unavailable
#16	10-83539M	BOLT (2 required per assembly)
		10-83539M - 10-83539M - BOLT (M6 x 20) [ More info ] Unavailable Replaced by 10-84058M
		10-84058M - Bolt [ More info ] $7.79 1 In Stock.
#17	10-83285M	BOLT (1 required per assembly)
		10-83285M - Screw - Priced Individually [ More info ] $5.19 10+ In Stock.
#18	10-82405M	BOLT (SEE NOTE #3) (1 required per assembly)
		10-82405M - Screw, NLA [ More info ] $10.86 $9.19 10+ In Stock.
#19	12-82214M	WASHER (4 required per assembly)
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#20	87-84096M	STARTER SWITCH (1 required per assembly)
		87-84096M - Switch [ More info ] Unavailable
#21	84-98985M	LEAD WIRE (1 required per assembly)
		84-98985M - Wire Lead, NLA [ More info ] $5.00 $4.24 2 In Stock.
#22	84-98986M	HARNESS (SEE NOTE #1) (1 required per assembly)
		84-98986M - WIRE HARNESS [ More info ] Unavailable
		84-18932M - Harness, NLA [ More info ] Unavailable
#22	84-94550M	HARNESS (SEE NOTE #2) (1 required per assembly)
		84-94550M - HARNESS [ More info ] Unavailable
#23	98987M	RETAINER (1 required per assembly)
		98987M - Retainer, NLA [ More info ] Unavailable
#24	99062M	RETAINER (1 required per assembly)
		99062M - Clamp [ More info ] $1.62 3 In Stock.
#25	84708M	PLATE (1 required per assembly)
		84708M - Plate [ More info ] Unavailable
#26	10-84709M	SCREW (1 required per assembly)
		10-84709M - Screw, NLA [ More info ] $1.80 $1.52 10+ In Stock.
#27	54-41876M	CLAMP (1 required per assembly)
		54-41876M - Clamp [ More info ] $2.50 $2.13 10 In Stock.
#28	10-84247M	BOLT (2 required per assembly)
		10-84247M - BOLT Note: Priced Individually [ More info ] Unavailable
		10-91725M - BOLT [ More info ] Unavailable
		10-826957M - Bolt, NLA [ More info ] $5.19 10+ In Stock.
#30	810937M	RECTIFIER (1 required per assembly)
		810937M - Rectifier [ More info ] Unavailable
		810937T - Rectifier [ More info ] Unavailable
		8M0091976 - Rectifier [ More info ] $198.49 Available to Order: Shipping delay up to 10 days.
		18-99437 - Rectifier Yamaha & Mariner 1, 2 & 3 Cylinder , 157-664-61 [ More info ] $142.45 $115.18 1 In Stock.
#31	10-82521M	SCREW (1 required per assembly)
		10-82521M - Screw [ More info ] $1.99 7 In Stock.
		10-83108M - Screw, NLA [ More info ] $2.17 $1.83 10+ In Stock.
#32	98988M	FUSE HOLDER (1 required per assembly)
		98988M - Fuse Holder, NLA [ More info ] Unavailable
#33	88-81522M	FUSE (12V-20A) (1 required per assembly)
		88-81522M - Fuse, NLA [ More info ] $3.23 10+ In Stock.
#34	98989M	BRACKET (SEE NOTE #1) (1 required per assembly)
		98989M - Bracket [ More info ] Unavailable
		811998M - Bracket, NLA [ More info ] $6.47 3 In Stock.
#34	84091M	BRACKET (SEE NOTE #2) (1 required per assembly)
		84091M - Bracket, NLA [ More info ] Unavailable
#35	94798M	BRACKET (1 required per assembly)
		94798M - Bracket, NLA [ More info ] Unavailable
#36	10-14232M	SCREW (2 required per assembly)
		10-14232M - Screw, NLA [ More info ] $4.05 10+ In Stock.
#37	25-82060M	STA-STRAP (1 required per assembly)
		25-82060M - Grommet, NLA [ More info ] Unavailable
#38	12-82211M	WASHER (1 required per assembly)
		12-82211M - Washer - Priced Individually [ More info ] $1.70 $0.96 10+ In Stock.
#39	25-84092M	GROMMET (1 required per assembly)
		25-84092M - Grommet, NLA [ More info ] Unavailable
#40	10-84342M	BOLT (2 required per assembly)
		10-84342M - Bolt, NLA [ More info ] $4.13 $3.50 10 In Stock.
#41	12-82217M	WASHER (2 required per assembly)
		12-82217M - Washer, NLA [ More info ] $1.67 $1.42 10 In Stock.
