Parts for Mariner 9.9C HP C.d.i. Magneto

Revise Search: All Models > 9.9C HP > 682-250946 & Up (E) > C.d.i. Magneto

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	253-8920M	FLYWHEEL ASSEMBLY (W/RING GEAR) (1 required per assembly)
		253-8920M - Flywheel, NLA [ More info ] Unavailable
#1	253-8921M	FLYWHEEL ASSEMBLY (W/O RING GEAR) (1 required per assembly)
		253-8921M - Flywheel, NLA [ More info ] Unavailable
#2	16708M	BASE (1 required per assembly) SERIAL 00070796-09999999
		16708M - Base, NLA [ More info ] Unavailable
#3	41863M	MAGNETO BASE (1 required per assembly)
		41863M - Base, NLA [ More info ] Unavailable
#4	41829M	CHARGE COIL (1 required per assembly)
		41829M - COIL [ More info ] Unavailable
		41829T - Coil, NLA [ More info ] $132.00 $111.80 10+ In Stock.
#5	41830M	PULSAR COIL (1 required per assembly)
		41830M - Coil, NLA [ More info ] $88.99 $75.37 10+ In Stock.
#6	10-96346M	SCREW (2 required per assembly)
		10-96346M - SCREW,NLA [ More info ] Unavailable
#7	10-91691M	SCREW (1 required per assembly)
		10-91691M - Screw, NLA Z [ More info ] $1.25 $1.06 8 In Stock.
#8	NLA	LIGHTING COIL ASSEMBLY (1 required per assembly)
		NLA - No Longer Availab [ More info ] Unavailable
#10	84305M	RETAINER (2 required per assembly)
		84305M - Ball Joint [ More info ] $13.99 Available to Order: Shipping delay up to 10 days.
#11	54-41867M	CLAMP (1 required per assembly)
		54-41867M - CLAMP,NLA [ More info ] Unavailable
#12	10-82499M	SCREW (1 required per assembly)
		10-82499M - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#13	10-84303M	BOLT (3 required per assembly)
		10-84303M - Screw , Priced Individually [ More info ] $0.72 1 In Stock.
		10-813477M - BOLT [ More info ] Unavailable
		10-91772M - Bolt [ More info ] $5.42 $4.59 10+ In Stock.
#14	12-82214M	WASHER (3 required per assembly)
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#15	11-81770M	NUT (1 required per assembly)
		11-81770M - Nut, Flywheel,NLA [ More info ] $2.17 $1.83 10 In Stock.
#16	12-81814M	WASHER (1 required per assembly)
		12-81814M - Washer, Flywheel Nut [ More info ] $1.36 $1.16 10+ In Stock.
#17	41869M	PLATE (1 required per assembly)
		41869M - PLATE,NLA [ More info ] Unavailable
#18	10-17661M	SCREW (4 required per assembly)
		10-17661M - Screw - Priced Individually [ More info ] $1.25 $1.06 2 In Stock.
#19	41268M	THROTTLE CAM (1 required per assembly)
		41268M - Cam, NLA [ More info ] $22.62 3 In Stock.
#20	10-84313M	BOLT (2 required per assembly)
		10-84313M - Bolt, NLA [ More info ] $1.63 $1.39 10+ In Stock.
#21	12-82211M	WASHER (2 required per assembly)
		12-82211M - Washer - Priced Individually [ More info ] $1.70 $0.96 10+ In Stock.
#22	16-41883M	STUD (1 required per assembly)
		16-41883M - Stud, NLA [ More info ] Unavailable
#23	11-83763M	NUT (1 required per assembly)
		11-83763M - Nut [ More info ] $5.50 $4.67 1 In Stock.
#24	84316M	STOP (1 required per assembly)
		84316M - Stopper , NLA [ More info ] Unavailable
#25	10-82444M	BOLT (1 required per assembly)
		10-82444M - BOLT Note: Priced Individually [ More info ] Unavailable
#26	41259M	BRACKET (1 required per assembly)
		41259M - Bracket, NLA [ More info ] $7.53 1 In Stock.
#27	41260M	DAMPER (2 required per assembly)
		41260M - Damper, NLA [ More info ] $2.70 10+ In Stock.
#28	10-84247M	BOLT (2 required per assembly)
		10-84247M - BOLT Note: Priced Individually [ More info ] Unavailable
		10-91725M - BOLT [ More info ] Unavailable
		10-826957M - Bolt, NLA [ More info ] $5.19 10+ In Stock.
#30	41262M	COVER (1 required per assembly)
		41262M - Cover [ More info ] $7.00 $5.93 4 In Stock.
#31	43077M	I. UNIT ASSEMBLY (1 required per assembly)
		43077M - Switch Box [ More info ] Unavailable
		43077T - Switch Box [ More info ] Unavailable
		18-5131 - CDI Ignition Switch Box Yamaha Mercury Mariner [ More info ] $252.84 $245.88 Available to Order: Shipping delay up to 10 days.
#32	10-83285M	BOLT (2 required per assembly)
		10-83285M - Screw - Priced Individually [ More info ] $5.19 10+ In Stock.
#33	12-82213M	WASHER (2 required per assembly)
		12-82213M - Washer - Priced Individually [ More info ] $1.50 $1.28 10+ In Stock.
#34	95188M	IGNITION COIL ASSEMBLY (1 required per assembly)
		95188M - Ignition Coil [ More info ] Unavailable
		95188T - Igition Coil [ More info ] Unavailable
#37	814991M	PLUG CAP (NOISE SUPPRESSOR) (OPT required per assembly)
		814991M - Plug Cap [ More info ] Unavailable
		85-815119M - Protector [ More info ] Unavailable
#37	85-63709A 1	PLUG CAP (2 required per assembly)
		85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ] $8.19 8 In Stock.
#38	94547M	TIMING PLATE (1 required per assembly)
		94547M - Timing Pointer, NLA [ More info ] $6.00 $5.08 4 In Stock.
#39	10-84211M	BOLT (2 required per assembly)
		10-84211M - Bolt, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#40	25-82069M	GROMMET (2 required per assembly)
		25-82069M - Grommet, Plug Wire,NLA [ More info ] $3.00 6 In Stock.
#41	98981M	RETAINER (1 required per assembly)
		98981M - Retainer,NLA [ More info ] Unavailable
#42	10-96671M	SCREW (3 required per assembly)
		10-96671M - Screw, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#43	83962M	RETAINER (1 required per assembly)
		83962M - Retainer,NLA [ More info ] Unavailable
#44	41316M	PULLEY (1 required per assembly)
		41316M - Pulley, NLA [ More info ] $10.78 10 In Stock.
