Parts for Mariner 8A Gear Shift Linkage

Revise Search: All Models > 8A > 682-550141 - 551055 (EL) > Gear Shift Linkage

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	81066M	HANDLE, GEAR SHIFT... (1 required per assembly)
		81066M - Handle, NLA [ More info ] Unavailable
#2	17-82155M	PIN, SHIFT HANDLE... (1 required per assembly)
		17-82155M - Pin -roll, NLA [ More info ] $5.63 $4.77 10+ In Stock.
#3	12-81847M	WASHER, SHIFT HANDLE SHAFT... (1 required per assembly) SERIAL 00000000-00020160
		12-81847M - WASHER,NLA [ More info ] Unavailable
#3	12-81854M	WASHER... .(S-20161 L-54716)- (1 required per assembly)
		12-81854M - WASHER,NLA [ More info ] Unavailable
#4	23-82666M	COLLAR, SHIFT HANDLE SHAFT... (1 required per assembly) SERIAL 00000000-00020160
		23-82666M - Bushing,NLA [ More info ] Unavailable
#4	23-81070M	COLLAR, SHIFT HANDLE SHAFT... (1 required per assembly) SERIAL 16-55465-09999999
		23-81070M - Bushing,NLA [ More info ] Unavailable
#4	23-83094M	COLLAR, SHIFT HANDLE SHAFT... (1 required per assembly) SERIAL 00020661-09999999
		23-83094M - Bushing, NLA [ More info ] $5.00 $4.24 5 In Stock.
#5	25-82259M	O-RING, SHIFT HANDLE SHAFT... . (2 required per assembly) SERIAL 00000000-00020160
		25-82259M - O-ring,NLA [ More info ] $1.50 $1.28 4 In Stock.
#5	25-82263M	O-RING, SHIFT HANDLE SHAFT... (2 required per assembly) SERIAL 00020161-09999999
		25-82263M - O-ring, Shift Handle Shaft. [ More info ] Unavailable
		25-814496M - O-Ring, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#6	82665M	SHAFT, SHIFT HANDLE... (1 required per assembly) SERIAL 00000000-00020160
		82665M - SHAFT,NLA [ More info ] Unavailable
#6	81068M	SHAFT, SHIFT HANDLE... . (1 required per assembly) SERIAL 00020161-09999999
		81068M - Shaft, NLA [ More info ] Unavailable
#7	81067M	SWIVEL, SHIFT HANDLE SHAFT... (1 required per assembly)
		81067M - PLATE,NLA [ More info ] Unavailable
#8	10-82447M	BOLT, SHIFT HANDLE SHAFT ATTACHING.. (1 required per assembly)
		10-82447M - Bolt, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#9	13-82208M	LOCKWASHER, SHIFT HANDLE SHAFT... (1 required per assembly)
		13-82208M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable
		13-82186M - LockWasher, NLA [ More info ] $1.36 $1.16 10+ In Stock.
#10	17-81879M	SHAFT, SHIFT SHAFT CAM... (1 required per assembly)
		17-81879M - PIN,NLA [ More info ] Unavailable
#11	13-81865M	WAVE WASHER, CAM SHAFT... (1 required per assembly)
		13-81865M - Wave Washer - Priced Individually [ More info ] $1.50 $1.28 10 In Stock.
#12	12-82209M	WASHER, CAM SHAFT... (1 required per assembly)
		12-82209M - Washer, NLA [ More info ] $2.17 $1.83 10+ In Stock.
#13	18-82125M	PIN, SHAFT CAM... (1 required per assembly)
		18-82125M - Cotter Pin, NLA [ More info ] $3.76 $3.19 10+ In Stock.
#14	80528M	SHAFT, SHIFT-UPPER... (1 required per assembly) SERIAL 00000000-00026575
		80528M - ROD,NLA [ More info ] Unavailable
#14	83095M	SHAFT, SHIFT-UPPER... (1 required per assembly) SERIAL 00026576-09999999
		83095M - ARM,NLA [ More info ] Unavailable
#15	18-82049M	PIN, CONNECTOR RETAINING... . (1 required per assembly) SERIAL 00000000-00026575
		18-82049M - Cotter Pin, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#16	80049M	CONNECTOR, SHIFT SHAFT (STARBOARD)... (1 required per assembly)
		80049M - Connector, NLA [ More info ] Unavailable
#17	80050M	CONNECTOR, SHIFT SHAFT (PORT)... (1 required per assembly)
		80050M - Connector, NLA [ More info ] $5.39 3 In Stock.
#18	10-82452M	BOLT, SHIFT SHAFT CONNECTOR... (1 required per assembly)
		10-82452M - Bolt - Priced Individually [ More info ] $1.29 10+ In Stock.
		10-84058M - Bolt [ More info ] $7.79 1 In Stock.
#19	12-82214M	WASHER, SHIFT SHAFT... (1 required per assembly) SERIAL 00000000-00026575
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#20	81069M	LEVER, SHIFT ROD... (1 required per assembly)
		81069M - LEVER,NLA [ More info ] Unavailable
#21	81061M	CAP, SHIFT LEVER CAM BALL... (1 required per assembly)
		81061M - Retainer, NLA [ More info ] $2.50 $2.13 2 In Stock.
#22	24-82084M	SPRING, SHIFT LEVER CAM... (1 required per assembly)
		24-82084M - Spring, Compression,NLA [ More info ] $2.04 $1.72 10 In Stock.
#23	82348M	BALL, SHIFT LEVER CAM... (1 required per assembly)
		82348M - Ball, NLA [ More info ] $1.36 $1.16 10+ In Stock.
