Parts for Mariner 80 HP Fuel Tank Assembly (6 Gallon)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 1225-1529A16 | FUEL TANK ASSEMBLY, COMPLETE (6 GALLON) (1 required per assembly) |
  |
1225-1529A16 - Fuel Tank [ More info ] Unavailable |
|
  |
1225-1529A21 - Fuel Tank [ More info ] Unavailable |
|
  |
1225-1529A22 - Fuel Tank [ More info ] Unavailable |
|
  |
1225-1529A26 - Fuel Tank [ More info ] Unavailable |
|
  |
1259-9728 - Fuel Tank [ More info ] Unavailable |
|
  |
|
1259-812410A 1 - Fuel Tank-6.6 GA,NLA [ More info ] Unavailable |
| # | 64841A 1 | COVER ASSEMBLY, COMPLETE- FUEL TANK (1 required per assembly) |
  |
|
64841A 1 - Cover Assembly, NLA [ More info ]
|
| # | 28897A 2 | FUEL GAUGE ASSEMBLY, COMPLETE (1 required per assembly) |
  |
|
28897A 2 - Fuel Indicator, NLA [ More info ]
|
| # | 37-75881 | DECAL, FUEL TANK (1 required per assembly) |
  |
37-75881 - 3799734A1 [ More info ] Unavailable |
|
  |
37-90454 - DECAL [ More info ] Unavailable |
|
  |
37-99734A 1 - Decal Set [ More info ] Unavailable |
|
  |
|
37-13921 - Decal, NLA [ More info ] Unavailable |
| #1 | 1225-1529 | FUEL TANK (6 GALLON) (1 required per assembly) |
  |
1225-1529 - Fuel Tank [ More info ] Unavailable |
|
| #3 | 36-25392A 2 | FILLER CAP ASSEMBLY (1 required per assembly) |
  |
36-25392A 2 - Filler Cap Assembly [ More info ] Unavailable |
|
  |
36-25392A 4 - CAP ASSY [ More info ] Unavailable |
|
  |
|
36-41098A 1 - Cap Assembly [ More info ]
|
  |
|
|
  |
|
|
| #4 | 10-25575 | SCREW, VENT-FILLER CAP (1 required per assembly) |
  |
|
10-25575 - Screw, NLA [ More info ] Unavailable |
| #5 | 12-49221 | WASHER, VENT SCREW (1 required per assembly) |
  |
12-49221 - Washer, (.187 X .500 X .062) Neoprene [ More info ] Unavailable |
|
  |
|
12-8M0204663 - Washer, Sold Individually [ More info ]
|
| #6 | 24-22227 | SPRING, TENSION - VENT SCREW (1 required per assembly) |
  |
|
24-22227 - Spring, Tenion - Vent Screw,NLA [ More info ]
|
| #7 | 11-28587 | NUT, SPEED- SPRING RETAINER (1 required per assembly) |
  |
|
11-28587 - Nut, Speed (spring Retainer) [ More info ]
|
| #8 | 27-25568 | GASKET, FILLER CAP TO FUEL TANK (1 required per assembly) |
  |
27-25568 - Filler Cap Gasket [ More info ] Unavailable |
|
  |
|
27-74856 - Filler Cap To Fuel Tank Gasket [ More info ]
|
  |
|
27-41065 - Filler Cap To Fuel Tank Gasket [ More info ]
|
| #9 | 64841A 3 | COVER ASS'Y, FUEL TANK (1/4-18 TAPPED HOLE) (1 required per assembly) |
  |
64841A 3 - Cover Assembly [ More info ] Unavailable |
|
  |
|
17792A 1 - Pickup Assembly, NLA [ More info ] Unavailable |
| #10 | 32-33909A 3 | TUBE ASS'Y (1/4-18 CONNECTOR AND 1/2" TUBE) (1 required per assembly) |
  |
32-33909A 3 - Tube [ More info ] Unavailable |
|
  |
|
32-75239 - Tubing, NLA [ More info ]
|
| #11 | 54920A 1 | LENS ASSEMBLY, FUEL GAUGE (1 required per assembly) |
  |
54920A 1 - LENS Assembly [ More info ] Unavailable |
|
  |
|
98542A 1 - Window Assembly, NLA [ More info ] Unavailable |
| #12 | 27-54921 | GASKET, FUEL GAUGE LENS (1 required per assembly) |
  |
|
27-54921 - Fuel Gauge Lens Gasket [ More info ]
|
| #13 | 20430 | RETAINER, FUEL GAUGE (1 required per assembly) |
  |
|
20430 - Fuel Gauge Retainer, NLA [ More info ]
|
| #14 | 28897A 1 | INDICATOR AND FLOAT ASSEMBLY (1 required per assembly) |
  |
|
28897A 1 - Float Assembly, NLA [ More info ]
|
| #15 | 20427 | FLOAT, FUEL GAUGE (1 required per assembly) |
  |
20427 - Float [ More info ] Unavailable |
|
  |
|
99274 - Fuel Tank Float, NLA [ More info ]
|
| #16 | 17-20426 | RIVET, INDICATOR TO RETAINER (1 required per assembly) |
  |
|
17-20426 - Rivet, NLA [ More info ]
|
| #17 | 10-62568 | SCREW, RETAINER TO FUEL TANK COVER (5/16") (2 required per assembly) |
  |
|
10-62568 - Screw - Priced Individually [ More info ]
|
| #19 | 27-28862 | GASKET, COVER ASSEMBLY TO FRAME (1 required per assembly) |
  |
|
27-28862 - Cover Asembly To Frame Gasket [ More info ]
|
| #20 | 28860 | FRAME, RETAINING-FUEL TANK COVER (1 required per assembly) |
  |
|
28860 - Frame, NLA [ More info ]
|
| #21 | 53-28903 | FASTENER, RETAINING FRAME TO FUEL TANK (2 required per assembly) |
  |
|
11-28903 - Nut - Priced Individually [ More info ]
|
| #22 | 10-20411 | SCREW, FUEL TANK COVER TO FUEL TANK (4 required per assembly) |
  |
|
10-20411 - Screw, NLA [ More info ]
|
| #23 | 12-74711 | WASHER, FUEL TANK COVER FASTENING SCREW (4 required per assembly) |
  |
12-74711 - Washer, NLA [ More info ] Unavailable |
|
  |
|
12-29070 - Washer, NLA [ More info ]
|
