Parts for Mariner 6D HP Cowling
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 2168-9372M | TOP COWLING ASS'Y (8M) (1 required per assembly) |
  |
|
2168-9372M - Top Cowl,NLA [ More info ] Unavailable |
| #1 | 2168-9373M | TOP COWLING ASS'Y (6M) (1 required per assembly) |
  |
|
2168-9373M - TOP COWL ASSEMBLY NLA [ More info ] Unavailable |
| #2 | 37-11938M | DECAL, SIDE SET (8M) (1 required per assembly) |
  |
|
37-11938M - Decal Set,NLA [ More info ] Unavailable |
| #2 | 37-11939M | DECAL, SIDE SET (6M) (1 required per assembly) |
  |
|
37-11939M - DECAL NLA [ More info ] Unavailable |
| #3 | 26-11403M | SEAL (1 required per assembly) |
  |
|
26-11403M - Seal, NLA [ More info ]
|
| #4 | 37-11940M | DECAL, FRONT (1 required per assembly) |
  |
|
37-11940M - DECAL,NLA [ More info ] Unavailable |
| #5 | 11937M | MOLDING, AIR DUCT (1 required per assembly) |
  |
|
11937M - MOLDING,NLA [ More info ] Unavailable |
| #6 | 95587M | SEAL (1 required per assembly) |
  |
|
95587M - Seal, NLA [ More info ] Unavailable |
| #7 | 11406M | HOLDER, CLAMP BAND (1 required per assembly) |
  |
|
11406M - Holder, NLA [ More info ]
|
| #8 | 11407M | HOOK (1 required per assembly) |
  |
|
11407M - HOOK,NLA [ More info ] Unavailable |
| #9 | 17-83140M | RIVET (4 required per assembly) |
  |
|
17-83140M - Rivet, NLA [ More info ] Unavailable |
| #10 | 37-81202M | INDICATOR, SHIFT (1 required per assembly) |
  |
|
37-81202M - DECAL,NLA [ More info ] Unavailable |
| #11 | 10-84303M | BOLT (4 required per assembly) |
  |
|
10-84303M - Screw , Priced Individually [ More info ]
|
  |
10-813477M - BOLT [ More info ] Unavailable |
|
  |
|
10-91772M - Bolt [ More info ]
|
| #12 | 12-82214M | LOCKWASHER (4 required per assembly) |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #13 | 2168-9509M | COWLING, BOTTOM (1 required per assembly) |
  |
|
2168-9509M - BOTTOM COWL,NLA [ More info ] Unavailable |
| #14 | 11408M | LEVER, CLAMP (1 required per assembly) |
  |
|
|
| #15 | 91660M | HOOK, CLAMP (1 required per assembly) |
  |
|
|
| #16 | 10-91661M | BOLT (1 required per assembly) |
  |
10-91661M - SCREW [ More info ] Unavailable |
|
  |
10-82179M - Screw - Priced Individually [ More info ] Unavailable |
|
  |
|
10-852787 6 - Screw, NLA [ More info ]
|
| #17 | 23-F11409 | BUSHING (2 required per assembly) |
  |
F11409 - SPRING [ More info ] Unavailable |
|
  |
|
F12146 - Spring, Coil Wedge,NLA [ More info ]
|
| #18 | 13-81869M | WASHER, WAVE (1 required per assembly) |
  |
|
13-81869M - Wave Washer, NLA [ More info ]
|
| #19 | 19-11410M | PLUG (1 required per assembly) |
  |
|
19-11410M - Plug, NLA [ More info ] Unavailable |
| #20 | 19-11411M | PLUG (1 required per assembly) |
  |
|
19-11411M - PLUG,NLA [ More info ] Unavailable |
| #21 | 11-82381M | NUT (1 required per assembly) |
  |
11-82381M - Nut - Priced Individually [ More info ] Unavailable |
|
  |
|
11-82390M - Nut, (M6) [ More info ]
|
| #22 | 87-14222M | LANYARD IGNITION SWITCH ASS'Y (8M) (1 required per assembly) |
  |
|
87-14222M - Switch [ More info ] Unavailable |
| #22 | 87-93102M | STOP SWITCH (6M) (1 required per assembly) |
  |
|
87-93102M - Switch [ More info ]
|
| #23 | 97756M | STOPPER (1 required per assembly) |
  |
|
97756M - Lanyard Stopper [ More info ]
|
| #24 | 19-11412M | PLUG (1 required per assembly) |
  |
|
19-11412M - Plug, NLA [ More info ] Unavailable |
| #25 | 25-11413M | GROMMET (1 required per assembly) |
  |
|
25-11413M - Grommet, NLA [ More info ] Unavailable |
| #26 | 25-11414M | GROMMET (1 required per assembly) |
  |
|
25-11414M - Grommet, NLA [ More info ]
|
| #27 | 19-11415M | PLUG (1 required per assembly) |
  |
|
19-11415M - Plug, NLA [ More info ] Unavailable |
| #28 | 25-11416M | GROMMET (4 required per assembly) |
  |
25-11416M - Grommet [ More info ] Unavailable |
|
  |
|
25-11416T - Grommet [ More info ]
|
| #29 | 11417M | PANEL (1 required per assembly) |
  |
|
11417M - PANEL,NLA [ More info ] Unavailable |
| #30 | 11418M | BRACKET (1 required per assembly) |
  |
|
11418M - Bracket, NLA [ More info ] Unavailable |
| #31 | 10-11419M | SCREW (3 required per assembly) |
  |
|
10-11419M - Screw, NLA [ More info ] Unavailable |
| #32 | 11-82378M | NUT (1 required per assembly) |
  |
11-82378M - NUT [ More info ] Unavailable |
|
  |
|
11-82388M - Nut, (M5) [ More info ]
|
| #33 | 23-11420M | COLLAR (4 required per assembly) |
  |
|
23-11420M - Collar, NLA [ More info ] Unavailable |
| #34 | 10-91674M | BOLT (4 required per assembly) |
  |
|
10-91674M - Bolt, NLA [ More info ]
|
| #35 | 26-11421M | SEAL (1 required per assembly) |
  |
|
26-11421M - Seal, NLA [ More info ] Unavailable |
