Parts for Mariner 6C HP Remote Control Attaching Kit - Optional
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 11661A 1 | ATTACHING KIT (BALL POST TYPE) (1 required per assembly) |
  |
|
11661A 1 - Attaching Assembly, NLA [ More info ] Unavailable |
| #2 | 11662M | BRACKET, REMOTE CONTROL (1 required per assembly) |
  |
|
11662M - Bracket, NLA [ More info ]
|
| #3 | 54-84113M | CLAMP, CABLE (2 required per assembly) |
  |
|
54-84113M - Clamp, NLA [ More info ]
|
| #4 | 17-82146M | PIN, SPRING (2 required per assembly) |
  |
|
17-82146M - Pin -roll, NLA [ More info ] Unavailable |
| #5 | 10-95456M | BOLT (2 required per assembly) |
  |
|
10-95456M - Bolt, NLA [ More info ]
|
| #6 | 11663M | LEVER, MAGNETO CONTROL (1 required per assembly) |
  |
|
11663M - LEVER,NLA [ More info ] Unavailable |
| #7 | 11664M | SHAFT (1 required per assembly) |
  |
|
11664M - Shaft, NLA [ More info ]
|
| #8 | 17-82155M | PIN (1 required per assembly) |
  |
|
17-82155M - Pin -roll, NLA [ More info ]
|
| #9 | 23-81946M | BUSHING (1 required per assembly) |
  |
|
23-81946M - Bushing, NLA [ More info ]
|
| #10 | 11665M | LEVER, MAGNETO CONTROL (1 required per assembly) |
  |
|
11665M - Lever, NLA [ More info ] Unavailable |
| #11 | 12-81846M | WASHER (2 required per assembly) |
  |
|
12-81846M - Washer, NLA [ More info ]
|
| #12 | 13-11666M | WASHER, WAVE (1 required per assembly) |
  |
|
13-11666M - Washer, Wave, NLA [ More info ] Unavailable |
| #13 | 10-82879M | BOLT (1 required per assembly) |
  |
|
10-82879M - Bolt, NLA [ More info ]
|
| #14 | 12-82211M | WASHER (1 required per assembly) |
  |
|
12-82211M - Washer - Priced Individually [ More info ]
|
| #15 | 11667M | LAVER, MAGNETO CONTROL (1 required per assembly) |
  |
|
11667M - LEVER,NLA [ More info ] Unavailable |
| #16 | 11668M | ROD (1 required per assembly) |
  |
|
11668M - Link, NLA [ More info ]
|
| #17 | 81225M | ROD END (1 required per assembly) |
  |
81225M - Coupler [ More info ] Unavailable |
|
  |
|
|
| #18 | 12-83768M | WASHER (1 required per assembly) |
  |
|
12-83768M - Washer, NLA [ More info ] Unavailable |
| #19 | 18-82129M | PIN, COTTER (1 required per assembly) |
  |
18-82129M - Pin, Cotter [ More info ] Unavailable |
|
  |
|
18-84301M - Cotter Pin, NLA [ More info ]
|
| #20 | 10-11669M | SCREW (1 required per assembly) |
  |
|
10-11669M - SCREW,NLA [ More info ] Unavailable |
| #21 | 84109M | CABLE END ASS'Y (THROTTLE) (1 required per assembly) |
  |
|
84109M - Cable End, NLA [ More info ] Unavailable |
| #22 | 84110M | CABLE END (1 required per assembly) |
  |
|
84110M - Cable END,NLA [ More info ] Unavailable |
| #23 | 17-83726M | HOOK,CABLE (1 required per assembly) |
  |
17-83726M - Pin [ More info ] Unavailable |
|
  |
|
17-814499M - PIN-ANCHOR,NLA [ More info ] Unavailable |
| #24 | 24-83725M | SPRING (1 required per assembly) |
  |
|
24-83725M - Spring, NLA [ More info ] Unavailable |
| #25 | 12-82217M | WASHER (1 required per assembly) |
  |
|
12-82217M - Washer, NLA [ More info ]
|
| #27 | 84106M | CABLE END ASS'Y (SHIFT) (1 required per assembly) |
  |
|
84106M - Cable End, NLA [ More info ]
|
| #28 | 84107M | CABLE END (1 required per assembly) |
  |
|
84107M - Cable End, NLA [ More info ] Unavailable |
| #29 | 17-83722M | HOOK, CABLE (1 required per assembly) |
  |
17-83722M - Pin [ More info ] Unavailable |
|
  |
|
17-814500M - Anchor Pin, NLA [ More info ]
|
| #30 | 24-83721M | SPRING (1 required per assembly) |
  |
|
24-83721M - Spring, NLA [ More info ] Unavailable |
| #33 | 11670M | BRACKET, STEERING (BALL POST TYPE) (1 required per assembly) |
  |
11670M - Steering Bracket Ball Post Type [ More info ] Unavailable |
|
  |
|
11670T - Bracket [ More info ] Unavailable |
| #34 | 10-91636M | BOLT (1 required per assembly) |
  |
|
10-91636M - Screw, NLA [ More info ]
|
| #35 | 12-82220M | WASHER (1 required per assembly) |
  |
|
12-82220M - Washer - Priced Individually [ More info ] Unavailable |
| #36 | 11-81785M | NUT, SELF LOCKING (1 required per assembly) |
  |
|
11-81785M - Nut, Nylon,NLA [ More info ]
|
| #37 | 83727M | BRACKET, STEERING (ROPE TYPE) (OPT) (1 required per assembly) |
  |
|
83727M - Bracket, NLA [ More info ] Unavailable |
