Parts for Mariner 60 HP (2 Cylinder) Switch Panel
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #0-1 | 82993M | SWITCH PANEL ASS'Y (1 required per assembly) |
  |
|
82993M - Switch Pane, NLA [ More info ] Unavailable |
| #1 | 87-82994M | MAIN SWITCH (1 required per assembly) |
  |
|
87-82994M - Switch,NLA [ More info ] Unavailable |
| #2 | 87-81534M | SWITCH, CHOKE (1 required per assembly) |
  |
|
87-81534M - Switch,NLA [ More info ] Unavailable |
| #3 | 87-82689M | STOP SWITCH ASS'Y (1 required per assembly) |
  |
87-82689M - Stop Switch [ More info ] Unavailable |
|
  |
87-97777M - Switch [ More info ] Unavailable |
|
  |
87-97755M - Switch Assembly [ More info ] Unavailable |
|
  |
|
87-97765M - Switch [ More info ]
|
| #4 | 81531M | STOPPER (1 required per assembly) |
  |
81531M - Retainer - Priced Individually [ More info ] Unavailable |
|
  |
|
97756M - Lanyard Stopper [ More info ]
|
| #5 | 81537M | BRACKET, CORD CLAMP (1 required per assembly) |
  |
|
81537M - Bracket, NLA [ More info ]
|
| #6 | 10-82487M | SCREW (1 required per assembly) |
  |
10-82487M - SCREW [ More info ] Unavailable |
|
  |
|
10-82500M - Screw, NLA [ More info ]
|
| #7 | 13-82184M | LOCK WASHER (1 required per assembly) |
  |
13-82184M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-82206M - LockWasher - Priced Individually [ More info ]
|
| #8 | 82995M | SWITCH PANEL (1 required per assembly) |
  |
82995M - PANEL [ More info ] Unavailable |
|
  |
|
92661M - Switch PANEL,NLA [ More info ] Unavailable |
| #9 | 10-80164M | SCREW (4 required per assembly) |
  |
|
10-80164M - SCREW,NLA [ More info ] Unavailable |
| #10 | 11-82377M | NUT (4 required per assembly) |
  |
|
11-82377M - Nut, Panel Nut,NLA [ More info ] Unavailable |
| #12 | 12-82799M | WASHER (4 required per assembly) |
  |
12-82799M - WASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
12-82847M - Washer, NLA [ More info ]
|
| #13 | 84-84434M | WIRE HARNESS (EXTERNAL) (1 required per assembly) SN# S-675-000781/L-675-302051 & Up |
  |
84-84434M - Wiring Harness [ More info ] Unavailable |
|
  |
|
84-81539M - Harness, NLA [ More info ] Unavailable |
| #13 | 84-81539M | WIRE HARNESS (EXTERNAL) (1 required per assembly) SN# S-675-000780/L-675-302050 & Below |
| #14 | 84-81527M | WIRE (INTERNAL) (1 required per assembly) |
  |
|
84-81527M - Harness, NLA [ More info ] Unavailable |
| #15 | 84-81538M | EXTENSION, WIRE HARNESS (OPT) (1 required per assembly) |
  |
|
84-81538M - Harness,NLA [ More info ] Unavailable |
