Parts for Mariner 60 HP (2 Cylinder) Ignition System

Revise Search: All Models > 60 HP (2 Cylinder) > 6F0-300311 & Up (EL) > Ignition System

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	253-8602M	I. MAGNETO ASS'Y (1 required per assembly)
		253-8602M - Flywheel, NLA [ More info ] Unavailable
#2	253-8603M	FLYWHEEL ASS'Y (1 required per assembly)
		253-8603M - Flywheel, NLA M [ More info ] Unavailable
#3	97798M	BASE ASS'Y (1 required per assembly)
		97798M - Base, NLA [ More info ] Unavailable
#4	97799M	COIL, CHARGE (1 required per assembly)
		97799M - COIL ,NLA [ More info ] Unavailable
#5	97800M	COIL, PULSAR (1 required per assembly)
		97800M - Coil, NLA [ More info ] Unavailable
#6	97801M	COIL, PULSER (1 required per assembly)
		97801M - Coil, NLA [ More info ] Unavailable
#7	97802M	COIL, LIGHTING (1 required per assembly)
		97802M - Coil, NLA [ More info ] Unavailable
#8	10-97803M	SCREW (2 required per assembly)
		10-97803M - Screw, NLA [ More info ] Unavailable
#9	10-91691M	SCREW (2 required per assembly)
		10-91691M - Screw, NLA Z [ More info ] $1.25 $1.06 8 In Stock.
#10	10-97804M	SCREW (4 required per assembly)
		10-97804M - Screw [ More info ] Unavailable
		10-17661M - Screw - Priced Individually [ More info ] $1.25 $1.06 2 In Stock.
#11	13-82186M	WASHER (4 required per assembly)
		13-82186M - LockWasher, NLA [ More info ] $1.36 $1.16 10+ In Stock.
#12	84305M	JOINT, BALL (1 required per assembly)
		84305M - Ball Joint [ More info ] $13.99 Available to Order: Shipping delay up to 10 days.
#13	97805M	RETAINER, MAGNETO BASE (1 required per assembly)
		97805M - Retainer, NLA [ More info ] $20.00 $16.94 3 In Stock.
#14	97806M	RETAINER, MAGNETO BASE (2 required per assembly)
		97806M - Retainer, NLA [ More info ] Unavailable
#15	10-83568M	SCREW (4 required per assembly)
		10-83568M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-11832M - Screw, NLA [ More info ] Unavailable
#16	13-82212M	WASHER (4 required per assembly)
		13-82212M - LockWasher - Priced Individually [ More info ] $1.10 10+ In Stock.
#17	97807M	PLATE, BASE (1 required per assembly)
		97807M - Plate [ More info ] Unavailable
#18	10-97808M	BOLT (4 required per assembly)
		10-97808M - Screw [ More info ] Unavailable
		10-98998M - Bolt, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#19	97809M	COVER, FLYWHEEL (1 required per assembly)
		97809M - Cover, NLA [ More info ] Unavailable
#20	23-97810M	COLLAR (3 required per assembly)
		23-97810M - COLLAR,NLA [ More info ] Unavailable
#21	25-97811M	GROMMET (3 required per assembly)
		25-97811M - Grommet, NLA [ More info ] Unavailable
#22	12-82202M	WASHER (3 required per assembly)
		12-82202M - WASHER Note: Priced Individually [ More info ] Unavailable
		12-82217M - Washer, NLA [ More info ] $1.67 $1.42 10 In Stock.
#23	13-82200M	WASHER (3 required per assembly)
		13-82200M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable
		13-82215M - LockWasher - Priced Individually [ More info ] $0.40 10 In Stock.
#24	10-82441M	BOLT (2 required per assembly)
		10-82441M - Bolt, NLA [ More info ] $5.63 $4.77 10+ In Stock.
#25	97812M	PLATE, TIMING (1 required per assembly)
		97812M - PLATE,NLA [ More info ] Unavailable
#26	10-84303M	BOLT (1 required per assembly)
		10-84303M - Screw , Priced Individually [ More info ] $0.72 1 In Stock.
		10-813477M - BOLT [ More info ] Unavailable
		10-91772M - Bolt [ More info ] $5.42 $4.59 10+ In Stock.
#27	13-82199M	WASHER (1 required per assembly)
		13-82199M - LockWasher - Priced Individually [ More info ] Unavailable
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#28	11-81773M	NUT (1 required per assembly)
		11-81773M - Nut, Flywheel [ More info ] $7.99 5 In Stock.
		11893789 - Nut [ More info ] $9.79 Available to Order: Shipping delay up to 10 days.
#29	12-84436M	WASHER (1 required per assembly)
		12-84436M - Washer, Flywheel [ More info ] Unavailable
		12-893762 - Washer - Priced Individually [ More info ] $4.09 1 In Stock.
#30	10-84342M	BOLT (1 required per assembly)
		10-84342M - Bolt, NLA [ More info ] $4.13 $3.50 10 In Stock.
#31	97813M	BRACKET (1 required per assembly)
		97813M - Bracket, NLA [ More info ] Unavailable
#32	25-93114M	GROMMET (3 required per assembly)
		25-93114M - O RING [ More info ] Unavailable
		25-881304 - Damper [ More info ] $5.99 Available to Order: Shipping delay up to 10 days.
#33	23-82851M	COLLAR (3 required per assembly)
		23-82851M - Bushing [ More info ] Unavailable
		23-804344003 - Collar [ More info ] $2.29 1 In Stock.
#34	12-82979M	WASHER (3 required per assembly)
		12-82979M - Washer, Bracket [ More info ] Unavailable
		12-83769M - Washer, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#35	10-84237M	BOLT (3 required per assembly)
		10-84237M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-83285M - Screw - Priced Individually [ More info ] $5.19 10+ In Stock.
#36	13-82197M	WASHER (3 required per assembly)
		13-82197M - LockWasher - Priced Individually [ More info ] Unavailable
#37	97814M	COVER, TERMINAL (1 required per assembly)
		97814M - Cover [ More info ] Unavailable
#38	10-82980M	SCREW (4 required per assembly)
		10-82980M - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#40	97815M	I. ASS'Y (1 required per assembly)
		97815M - CDI Assembly [ More info ] Unavailable
#41	10-82405M	BOLT (2 required per assembly)
		10-82405M - Screw, NLA [ More info ] $10.86 $9.19 10+ In Stock.
#43	97817M	COIL ASS'Y, IGNITION (2 required per assembly)
		97817M - Coil, NLA [ More info ] Unavailable
#44	25-82069M	GROMMET (2 required per assembly)
		25-82069M - Grommet, Plug Wire,NLA [ More info ] $3.00 6 In Stock.
#45	54-97079M	CLAMP (1 required per assembly)
		54-97079M - Clamp [ More info ] $1.50 $1.28 2 In Stock.
#46	80935M	PLUG CAP ASS'Y (NOISE SUPPRESSOR) (2 required per assembly)
		80935M - Protector [ More info ] Unavailable
		814991M - Plug Cap [ More info ] Unavailable
		85-815119M - Protector [ More info ] Unavailable
#46	82788M	PLUG CAP ASS'Y (2 required per assembly)
		82788M - Protector - Priced Individually [ More info ] $5.21 4 In Stock.
		85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ] $8.19 8 In Stock.
#49	81652M	RECTIFIER ASS'Y (1 required per assembly)
		81652M - Rectifier [ More info ] Unavailable
		810937M - Rectifier [ More info ] Unavailable
		810937T - Rectifier [ More info ] Unavailable
		8M0091976 - Rectifier [ More info ] $198.49 Available to Order: Shipping delay up to 10 days.
		18-99437 - Rectifier Yamaha & Mariner 1, 2 & 3 Cylinder , 157-664-61 [ More info ] $142.45 $115.18 1 In Stock.
#50	10-82492M	SCREW (1 required per assembly)
		10-82492M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-82521M - Screw [ More info ] $1.99 7 In Stock.
		10-83108M - Screw, NLA [ More info ] $2.17 $1.83 10+ In Stock.
#51	12-82196M	WASHER (1 required per assembly)
		12-82196M - WASHER Note: Priced Individually [ More info ] Unavailable
		12-82211M - Washer - Priced Individually [ More info ] $1.70 $0.96 10+ In Stock.
#52	84-97078M	WIRE, GROUND (1 required per assembly)
		84-97078M - Wire, NLA [ More info ] Unavailable
#53	84-81250M	WIRE, GROUND (1 required per assembly)
		84-81250M - Ground Cable, NLA [ More info ] $2.50 $2.13 3 In Stock.
#56	97818M	RETAINER (4 required per assembly)
		97818M - Retainer,NLA [ More info ] Unavailable
#57	10-91772M	BOLT (1 required per assembly)
#58	12-82214M	WASHER (1 required per assembly)
