Parts for Mariner 60 HP (2 Cylinder) Throttle Control
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 81345M | LEVER, C.D.I. CONTROL (1 required per assembly) |
  |
|
81345M - LEVER,NLA [ More info ] Unavailable |
| #2 | 81341M | CAP, CLEVIS LOCK (1 required per assembly) |
  |
|
|
| #3 | 17-82976M | PIN (1 required per assembly) |
  |
|
17-82976M - Pin, Lock Lever Pivot, NLA [ More info ] Unavailable |
| #4 | 17-82367M | PIN, DOWEL (1 required per assembly) |
  |
|
17-82367M - Pin -Dowel, NLA [ More info ] Unavailable |
| #5 | 17-82149M | PIN, ROLL (4 required per assembly) |
  |
|
17-82149M - Pin, (18.5 Mm) [ More info ] Unavailable |
| #6 | 81480M | CLEVIS, THROTLE CABLE (1 required per assembly) |
  |
|
|
| #7 | 81350M | BRACKET, SHAFT (1 required per assembly) |
  |
|
81350M - Bracket, NLA [ More info ] Unavailable |
| #8 | 23-81946M | BUSHING (4 required per assembly) |
  |
|
23-81946M - Bushing, NLA [ More info ]
|
| #9 | 10-82423M | BOLT (3 required per assembly) |
  |
|
10-82423M - Bolt, NLA [ More info ]
|
| #10 | 13-82199M | WASHER, LOCK (4 required per assembly) |
  |
13-82199M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #11 | 23-81942M | BUSHING (1 required per assembly) |
  |
23-81942M - Bushing [ More info ] Unavailable |
|
  |
|
23-41311M - Bushing, NLA [ More info ] Unavailable |
| #12 | 81403M | STOP, SHAFT BRAKET (1 required per assembly) |
  |
|
81403M - Throttle Stop, NLA [ More info ] Unavailable |
| #13 | 24-82074M | SPRING, COMPRESSION (1 required per assembly) |
  |
|
24-82074M - Spring,compression - Shaft Bracket Stop,NLA [ More info ] Unavailable |
| #14 | 53-82330M | SNAPPING (2 required per assembly) |
  |
|
53-82330M - E-Ring, NLA [ More info ]
|
| #15 | M-81346M | LEVER, C.D.I. CONTROL (1 required per assembly) |
  |
|
81346M - Lever [ More info ] Unavailable |
| #16 | 81347M | SHAFT, LINK CONNECTING (1 required per assembly) |
  |
|
81347M - Shaft, NLA [ More info ] Unavailable |
| #17 | 24-82113M | SPRING, TORSION (1 required per assembly) |
  |
|
24-82113M - Spring, Torsion - Link Shaft,NLA [ More info ] Unavailable |
| #18 | 81344M | LEVER, C.D.I. CONTROL (1 required per assembly) |
  |
|
81344M - Lever [ More info ] Unavailable |
| #19 | 81349M | BRACKER, SHAFT - UPPER (1 required per assembly) |
  |
|
81349M - Bracket, NLA [ More info ] Unavailable |
| #20 | 17-82154M | PIN, ROLL (1 required per assembly) |
  |
|
17-82154M - Pin -roll, NLA [ More info ] Unavailable |
| #21 | 10-82977M | SCREW (1 required per assembly) |
  |
|
10-82977M - Screw, NLA [ More info ]
|
| #22 | 10-83050M | SCREW 1 (2 required per assembly) |
  |
|
10-83050M - SCREW,NLA [ More info ] Unavailable |
| #23 | 11-82381M | NUT (2 required per assembly) |
  |
11-82381M - Nut - Priced Individually [ More info ] Unavailable |
|
  |
|
11-82390M - Nut, (M6) [ More info ]
|
| #24 | 97087M | CAP (1 required per assembly) SERIAL 00001171-09999999 |
  |
|
97087M - Cap, NLA [ More info ] Unavailable |
| #24 | 81415M | CAP (1 required per assembly) SERIAL 00000000-00001170 |
  |
|
81415M - Cap, NLA [ More info ] Unavailable |
| #26 | 81348M | ROD, CONTROL (1 required per assembly) |
  |
|
81348M - Control Rod [ More info ] Unavailable |
| #27 | 81225M | CLEVIS (4 required per assembly) |
  |
81225M - Coupler [ More info ] Unavailable |
|
  |
|
|
| #28 | 92655M | ROD, LINK (1 required per assembly) |
  |
|
92655M - LINK ROD,NLA [ More info ]
|
| #29 | 11-82378M | NUT (1 required per assembly) |
  |
11-82378M - NUT [ More info ] Unavailable |
|
  |
|
11-82388M - Nut, (M5) [ More info ]
|
| #30 | 81334M | CAM (1 required per assembly) |
  |
|
81334M - Cam, NLA [ More info ] Unavailable |
| #31 | 13-81868M | WASHER, WAVE (1 required per assembly) |
  |
|
13-81868M - Wave Washer - Priced Individually [ More info ]
|
| #32 | 10-81713M | BOLT (1 required per assembly) |
  |
|
10-81713M - Screw, NLA [ More info ]
|
| #33 | 81483M | BRACLET, REMOTE CONTROL (1 required per assembly) |
  |
|
81483M - Bracket, NLA [ More info ] Unavailable |
| #34 | M-81484M | CLAMP, CABLE (1 required per assembly) |
  |
|
81484M - Bracket, NLA [ More info ] Unavailable |
| #35 | 17-82146M | PIN, ROLL (1 required per assembly) |
  |
|
17-82146M - Pin -roll, NLA [ More info ] Unavailable |
| #36 | 10-82437M | BOLT (1 required per assembly) |
  |
|
10-82437M - Bolt, NLA [ More info ]
|
| #37 | 13-82200M | WASHER (1 required per assembly) |
  |
13-82200M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
13-82215M - LockWasher - Priced Individually [ More info ]
|
