Parts for Mariner 5A HP Cowling
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | NLA | TOP COWL (1 required per assembly) |
  |
|
NLA - No Longer Availab [ More info ] Unavailable |
| #2 | 37-82906M | FRONT DECAL (1 required per assembly) |
  |
|
37-82906M - DECAL,NLA [ More info ] Unavailable |
| #3 | 37-82907M | REAR DECAL (1 required per assembly) |
  |
|
37-82907M - DECAL,NLA [ More info ] Unavailable |
| #4 | 37-83060M | SIDE SET DECALS (1 required per assembly) |
  |
|
37-83060M - Decal Set,NLA [ More info ] Unavailable |
| #5 | 37-81202M | DECAL (F-N-R) (1 required per assembly) |
  |
|
37-81202M - DECAL,NLA [ More info ] Unavailable |
| #6 | 81196M | SEAL (1 required per assembly) |
  |
|
81196M - Seal, NLA [ More info ] Unavailable |
| #8 | 17-81906M | RIVET (8 required per assembly) |
  |
|
17-81906M - RIVET,NLA [ More info ] Unavailable |
| #10 | 94782M | HOLDER (1 required per assembly) |
  |
|
94782M - Holder, NLA [ More info ] Unavailable |
| #11 | 17-81905M | RIVET (4 required per assembly) |
  |
|
17-81905M - RIVET,NLA [ More info ] Unavailable |
| #14 | 82966M | AIR SHROUD (1 required per assembly) |
  |
|
82966M - AIR SHROUD,NLA [ More info ] Unavailable |
| #15 | 2168-6809M | FRONT BOTTOM COWL (1 required per assembly) SERIAL 00018546-09999999 |
  |
|
2168-6809M - Cowl, NLA [ More info ] Unavailable |
| #16 | 10-82423M | BOLT (4 required per assembly) |
  |
|
10-82423M - Bolt, NLA [ More info ]
|
| #17 | 13-82212M | LOCKWASHER (4 required per assembly) |
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #18 | 82068M | GROMMET (1 required per assembly) |
  |
|
82068M - PLUG,NLA [ More info ] Unavailable |
| #19 | 25-82062M | GROMMET (1 required per assembly) |
  |
|
25-82062M - Grommet, NLA [ More info ] Unavailable |
| #20 | 80033M | HOLDER (1 required per assembly) |
  |
|
80033M - Holder, NLA [ More info ]
|
| #21 | 2168-6810M | REAR BOTTOM COWL (1 required per assembly) |
  |
|
2168-6810M - Bottom Cowl, NLA [ More info ] Unavailable |
| #22 | 10-82441M | BOLT (2 required per assembly) |
  |
|
10-82441M - Bolt, NLA [ More info ]
|
| #23 | 13-82215M | LOCKWASHER (2 required per assembly) |
  |
|
13-82215M - LockWasher - Priced Individually [ More info ]
|
| #24 | 82550M | LEVER (1 required per assembly) |
  |
|
82550M - Lever, NLA [ More info ] Unavailable |
| #25 | 12-81817M | WASHER (1 required per assembly) |
  |
|
12-81817M - Washer, Cowl Clamp Lever, NLA [ More info ]
|
| #26 | 13-81871M | WAVE WASHER (1 required per assembly) |
  |
|
13-81871M - Wave Washer, NLA [ More info ] Unavailable |
| #27 | 81201M | CLAMP (1 required per assembly) |
  |
|
81201M - Lever, NLA [ More info ] Unavailable |
| #28 | 12-81794M | WASHER (1 required per assembly) |
  |
|
12-81794M - Washer, Cowl Clamp Lever [ More info ]
|
| #29 | 10-84303M | BOLT (1 required per assembly) SERIAL 00030091-09999999 |
  |
|
10-84303M - Screw , Priced Individually [ More info ]
|
  |
10-813477M - BOLT [ More info ] Unavailable |
|
  |
|
10-91772M - Bolt [ More info ]
|
| #30 | 87-81205M | STOP SWITCH (1 required per assembly) |
  |
|
87-81205M - Switch,NLA [ More info ] Unavailable |
| #31 | 91-81669M | TOOL KIT (1 required per assembly) |
  |
91-81669M - Tool Kit [ More info ] Unavailable |
|
  |
|
91-803581 - Tool Kit [ More info ] Unavailable |
| #32 | 17-82364M | DOWEL PIN (2 required per assembly) SERIAL 00000000-00018545 |
  |
|
17-82364M - Pin -Dowel - Priced Individually [ More info ]
|
| #33 | 82056M | GROMMET (1 required per assembly) SERIAL 00000000-00030090 |
  |
|
82056M - Pin, NLA [ More info ] Unavailable |
| #34 | 23-81951M | BUSHING (1 required per assembly) SERIAL 00000000-00030090 |
  |
|
23-81951M - Bushing, NLA [ More info ] Unavailable |
| #35 | 11-82381M | NUT (1 required per assembly) SERIAL 00000000-00030090 |
  |
11-82381M - Nut - Priced Individually [ More info ] Unavailable |
|
  |
|
11-82390M - Nut, (M6) [ More info ]
|
