Parts for Mariner 55 HP Mounting System

Revise Search: All Models > 55 HP > 663-315379 & Up (EL) > Mounting System

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	19144M	ARM & SHAFT (E) (1 required per assembly)
		19144M - Steering Arm, NLA [ More info ] Unavailable
#1	19145M	ARM & SHAFT (EL) (1 required per assembly)
		19145M - Steering Arm [ More info ] $138.16 1 In Stock.
		19145T - Steering Arm,NLA [ More info ] Unavailable
#2	81482M	PLATE, STEERING (RIDE GUIDE) (1 required per assembly)
		81482M - Bracket, NLA [ More info ] Unavailable
#3	16-81742M	STUD, STEERING PLATE (2 required per assembly)
		16-81742M - Stud, NLA [ More info ] Unavailable
#4	11-81785M	NUT (2 required per assembly)
		11-81785M - Nut, Nylon,NLA [ More info ] $6.51 10+ In Stock.
#5	12-19146M	WASHER (1 required per assembly)
		12-19146M - Washer, NLA [ More info ] $2.78 $2.36 10+ In Stock.
#6	23-81955M	BUSHING (2 required per assembly)
		23-81955M - Bushing [ More info ] Unavailable
#7	26-98950M	OIL SEAL, STEERING SHAFT (1 required per assembly)
		26-98950M - SEAL,NLA [ More info ] Unavailable
#8	12-81839M	WASHER (1 required per assembly)
		12-81839M - Washer, Steering Shaft-lower, NLA [ More info ] $2.50 $2.13 10+ In Stock.
#9	81432M	HOUSING, LOWER MOUNT (1 required per assembly)
		81432M - Yoke, NLA [ More info ] Unavailable
#10	53-42446M	SNAP RING (1 required per assembly)
		53-42446M - Snap Ring, NLA [ More info ] $2.50 $2.13 10+ In Stock.
#11	84430M	LOWER MOUNT (2 required per assembly)
		84430M - Mount, NLA [ More info ] Unavailable
#12	12-84431M	WASHER (2 required per assembly)
		12-84431M - Washer, NLA [ More info ] Unavailable
#13	12-84432M	WASHER (2 required per assembly)
		12-84432M - Washer, NLA [ More info ] $2.00 $1.69 1 In Stock.
#14	10-81717M	BOLT (2 required per assembly)
		10-81717M - Bolt, NLA [ More info ] $7.78 $6.59 6 In Stock.
#15	81436M	BUMPER (2 required per assembly)
		81436M - Cap, NLA [ More info ] $2.78 $2.36 8 In Stock.
#16	12-84429M	WASHER (4 required per assembly)
		12-84429M - WASHER,NLA [ More info ] Unavailable
#17	11-82397M	NUT (2 required per assembly)
		11-82397M - Nut, NLA [ More info ] $5.56 $4.71 5 In Stock.
#18	84433M	RETAINER, LOWER MOUNT (2 required per assembly)
		84433M - Retainer, NLA [ More info ] Unavailable
#19	24-82087M	SPRING, COMPRESSION (4 required per assembly)
		24-82087M - SPRING [ More info ] Unavailable
#20	10-43106M	BOLT (4 required per assembly)
		10-43106M - Bolt [ More info ] Unavailable
#21	13-82215M	LOCKWASHER (7 required per assembly)
		13-82215M - LockWasher - Priced Individually [ More info ] $0.40 10 In Stock.
#22	81434M	COVER, LOWER MOUNT (2 required per assembly)
		81434M - Cover [ More info ] Unavailable
#23	10-82172M	SCREW (2 required per assembly)
		10-82172M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-83870M - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#24	11-81779M	NUT (2 required per assembly)
		11-81779M - Nut, Lower Mount Cover Screw,NLA [ More info ] $3.75 $3.17 10 In Stock.
#25	81676M	UPPER MOUNT (2 required per assembly)
		81676M - MOUNT [ More info ] Unavailable
		81676T - Mount [ More info ] $99.99 Available to Order: Shipping delay up to 10 days.
#26	81431M	BUMPER (2 required per assembly)
		81431M - Cap, NLA [ More info ] $4.44 $3.76 5 In Stock.
#27	10-81714M	BOLT (2 required per assembly)
		10-81714M - Screw, NLA [ More info ] $6.67 $5.65 10+ In Stock.
#28	12-81825M	WASHER (2 required per assembly)
		12-81825M - Washer, Upper Mount Bolt, NLA [ More info ] $1.67 $1.42 10+ In Stock.
#29	12-83702M	WASHER (2 required per assembly)
		12-83702M - Washer, Upper Mount Bolt, NLA [ More info ] $7.78 $6.59 10 In Stock.
#30	12-81803M	WASHER (2 required per assembly)
		12-81803M - Washer, Upper Mount Bolt, NLA [ More info ] Unavailable
#31	11-81783M	NUT (2 required per assembly)
		11-81783M - Nut, Upper Mount Bolt,NLA [ More info ] $2.78 $2.36 6 In Stock.
#32	81429M	RETAINER, UPPER MOUNT (1 required per assembly)
		81429M - Retainer, NLA [ More info ] $10.00 $8.47 6 In Stock.
#33	10-814575M	BOLT (3 required per assembly)
		10-814575M - BOLT [ More info ] Unavailable
		10-82442M - Bolt, NLA [ More info ] $4.50 10+ In Stock.
#34	41844M	GROUND WIRE (E) (1 required per assembly)
		41844M - WIRE [ More info ] Unavailable
		41845M - Wire, NLA [ More info ] $7.00 $5.93 10+ In Stock.
#34	41845M	GROUND WIRE (EL) (1 required per assembly)
