Parts for Mariner 55 HP Gear Shift Linkage
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 98919M | SHIFT BRACKET (1 required per assembly) |
  |
|
98919M - Bracket, NLA [ More info ] Unavailable |
| #2 | 17-82137M | CLEVIS PIN (1 required per assembly) |
  |
|
17-82137M - Pin, Clevis-shift Bracket,NLA [ More info ] Unavailable |
| #3 | 12-82214M | WASHER (3 required per assembly) |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #4 | 13-81866M | WAVE WASHER (1 required per assembly) |
  |
|
13-81866M - Wave Washer, NLA [ More info ] Unavailable |
| #5 | 10-82423M | BOLT (1 required per assembly) |
  |
|
10-82423M - Bolt, NLA [ More info ]
|
| #6 | 53-82330M | SNAP RING (1 required per assembly) |
  |
|
53-82330M - E-Ring, NLA [ More info ]
|
| #7 | 84209M | SHIFT ROD LEVER (1 required per assembly) |
  |
|
|
| #8 | 18-82126M | COTTER PIN (1 required per assembly) |
  |
18-82126M - COTTER PIN Note: Priced Individually [ More info ] Unavailable |
|
  |
|
18-43089M - PIN-COTTER,NLA [ More info ] Unavailable |
| #9 | 81480M | CLEVIS (1 required per assembly) |
  |
|
|
| #10 | 98920M | BRACKET (1 required per assembly) |
  |
|
98920M - Bracket, NLA [ More info ]
|
| #11 | 10-82441M | BOLT (2 required per assembly) |
  |
|
10-82441M - Bolt, NLA [ More info ]
|
| #12 | 13-82215M | LOCKWASHER (2 required per assembly) |
  |
|
13-82215M - LockWasher - Priced Individually [ More info ]
|
| #13 | 92659M | BALL (1 required per assembly) |
  |
|
92659M - Ball, NLA [ More info ]
|
| #14 | 24-82081M | SPRING (1 required per assembly) |
  |
|
24-82081M - Spring [ More info ] Unavailable |
| #15 | 23-80635M | RETAINER (1 required per assembly) |
  |
|
23-80635M - Bushing, NLA [ More info ] Unavailable |
| #16 | 19142M | SHIFT ROD (E) (1 required per assembly) SERIAL (E-004424 EL-318399) AND ABOVE |
  |
|
19142M - Shift Rod, NLA [ More info ]
|
| #16 | 19143M | SHIFT ROD (EL) (1 required per assembly) SERIAL (E-004424 EL-318399) AND ABOVE |
  |
|
19143M - Shift Rod, NLA [ More info ] Unavailable |
| #16 | 98921M | SHIFT ROD (E) (1 required per assembly) SERIAL (E-004423 EL-318398) AND BELOW |
  |
98921M - Shift Rod [ More info ] Unavailable |
|
| #16 | 98922M | SHIFT ROD (EL) (1 required per assembly) SERIAL (E-004423 EL-318398) AND BELOW |
  |
98922M - Shift Rod [ More info ] Unavailable |
|
| #17 | 23-98923M | BUSHING (1 required per assembly) |
  |
|
23-98923M - Bushing, NLA [ More info ]
|
| #18 | 12-82216M | WASHER (1 required per assembly) |
  |
|
12-82216M - Washer, Lock, NLA [ More info ]
|
| #19 | 18-82053M | COTTER PIN (2 required per assembly) |
  |
|
18-82053M - Cotter Pin - Priced Individually [ More info ]
|
| #20 | 98924M | BOOT (1 required per assembly) |
  |
|
98924M - BOOT,NLA [ More info ] Unavailable |
| #21 | 54-92664M | CLAMP (1 required per assembly) |
  |
|
54-92664M - CLAMP,NLA [ More info ] Unavailable |
