Parts for Mariner 55 HP Carburetor
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #0-1 | 1383-9819M | CARBURETOR ASSEMBLY (UPPER) (1 required per assembly) SERIAL (E-004424 EL-318399) AND ABOVE |
  |
|
1383-9819M - Carburetor [ More info ] Unavailable |
| #0-1 | 1383-9820M | CARBURETOR (LOWER) (1 required per assembly) SERIAL (E-004424 EL-318399) AND ABOVE |
  |
|
1383-9820M - Carburetor, NLA [ More info ] Unavailable |
| #0-1 | 1383-9279M | CARBURETOR (UPPER) (1 required per assembly) SERIAL (E-004423 EL-318398) AND ABOVE |
  |
1383-9279M - Carburetor [ More info ] Unavailable |
|
| #0-1 | 1383-9280M | CARBURETOR (LOWER) (1 required per assembly) SERIAL (E-004423EL-318398) AND BELOW |
  |
1383-9280M - Carburetor [ More info ] Unavailable |
|
| #1 | 10-81292M | PLUG SCREW (2 required per assembly) |
  |
|
10-81292M - SCREW,NLA [ More info ] Unavailable |
| #2 | 12-92636M | WASHER (2 required per assembly) |
  |
|
12-92636M - Washer, NLA [ More info ]
|
| #3 | 10-81279M | PLUG SCREW (2 required per assembly) |
  |
|
10-81279M - SCREW,NLA [ More info ] Unavailable |
| #4 | 84441M | JET, PILOT (#80) (2 required per assembly) SERIAL (E-004424 EL-318399) AND ABOVE |
  |
|
84441M - Jet, NLA [ More info ]
|
| #4 | 97081M | JET, PILOT (#82) (2 required per assembly) SERIAL (E-004423 EL-318398) AND BELOW |
  |
|
97081M - JET,NLA [ More info ] Unavailable |
| #5 | 10-81277M | SCREW, THROTTLE (LOWER) (1 required per assembly) |
  |
|
10-81277M - Screw, NLA [ More info ]
|
| #6 | 24-82080M | SPRING (LOWER) (1 required per assembly) |
  |
|
24-82080M - Spring [ More info ] Unavailable |
| #7 | 10-81281M | SCREW, IDLE SPEED (2 required per assembly) |
  |
|
10-81281M - Screw, NLA [ More info ] Unavailable |
| #8 | 24-82073M | SPRING (2 required per assembly) |
  |
|
24-82073M - Spring, Compression - Idle Speed Screw,NLA [ More info ]
|
| #9 | 81287M | MAIN NOZZLE (2 required per assembly) |
  |
|
81287M - Main Nozzle, NLA [ More info ] Unavailable |
| #10 | 92638M | MAIN JET (#160) (2 required per assembly) |
  |
|
92638M - MAIN JET ,NLA [ More info ] Unavailable |
| #11 | 97848M | FLOAT (E-004424 EL-318399 AND ABOVE) (2 required per assembly) |
  |
|
|
| #11 | 81291M | FLOAT (E-004423 EL-318398 AND BELOW) (2 required per assembly) |
  |
81291M - Float [ More info ] Unavailable |
|
| #12 | 17-81278M | FLOAT PIN (2 required per assembly) |
  |
|
17-81278M - Pin, NLA [ More info ] Unavailable |
| #13 | 25-82288M | "O" RING (2 required per assembly) |
  |
|
25-82288M - O-Ring [ More info ]
|
| #14 | 81290M | FLOAT BOWL (2 required per assembly) |
  |
|
81290M - Float Bowl, NLA [ More info ] Unavailable |
| #15 | 10-81758M | SCREW (8 required per assembly) |
  |
|
10-81758M - Screw - Priced Individually [ More info ]
|
| #16 | 10-81293M | SCREW (2 required per assembly) |
  |
|
10-81293M - Screw [ More info ]
|
| #17 | 25-94498M | "O" RING (2 required per assembly) |
  |
|
25-94498M - O-Ring [ More info ]
|
| #18 | 81288M | PILOT, AIR JET (#100) (2 required per assembly) |
  |
|
81288M - Jet, NLA [ More info ]
|
| #19 | 95626M | JET (#125) (2 required per assembly) |
  |
|
95626M - Jet, NLA [ More info ] Unavailable |
| #20 | 41841M | VALVE SEAT (2 required per assembly) SERIAL (E-004424 EL-318399) AND ABOVE |
  |
|
41841M - Valve Seat, NLA [ More info ]
|
| #20 | 82780M | VALVE SEAT (2 required per assembly) SERIAL (E-004423 EL-318398) AND BELOW |
  |
|
82780M - Inlet Needle [ More info ]
|
| #21 | 54-82781M | CLIP (2 required per assembly) . |
  |
54-82781M - Clip - Priced Individually [ More info ] Unavailable |
|
  |
|
54-8M0120624 - CLIP @2 NLA [ More info ] Unavailable |
| #22 | 25-82261M | "O" RING (2 required per assembly) |
  |
|
25-82261M - O-Ring - Priced Individually [ More info ] Unavailable |
| #23 | 17-92639M | VALVE PIN (2 required per assembly) |
  |
|
17-92639M - Pin, Float [ More info ]
|
| #24 | 80026M | PLATE (2 required per assembly) |
  |
|
80026M - Retainer, NLA [ More info ] Unavailable |
| #25 | 10-82512M | SCREW (2 required per assembly) |
  |
|
10-82512M - Screw, NLA [ More info ]
|
| #26 | 10-97082M | SCREW (UPPER) (1 required per assembly) |
  |
|
10-97082M - Screw, NLA [ More info ] Unavailable |
| #27 | 12-83372M | WASHER (UPPER) (1 required per assembly) |
  |
|
12-83372M - Washer, NLA [ More info ]
|
| #27 | 19141M | CARB REPAIR KIT (1 required per assembly) SERIAL (E-004424 EL-318399) AND ABOVE. |
  |
|
19141M - Carburetor Repair Kit, NLA [ More info ] Unavailable |
| #27 | 84419M | CARB REPAIR KIT (1 required per assembly) SERIAL (E-004423 EL-318398) AND BELOW. |
  |
|
84419M - Carburetor Repair Kit [ More info ]
|
