Parts for Mariner 5 HP (2-Stroke) Accessories
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 815596A 2 | FUEL TANK ADAPTOR KIT (1 required per assembly) (4 HP) |
  |
|
815596A 2 - Remote Fuel Tank Adapter Kit [ More info ] Unavailable |
| # | 22-13563Q 3 | CONNECTOR, Fuel, Engine End (1 required per assembly) For 6.6 Gallon/25L |
  |
|
22-13563Q 3 - Fuel Fitting - Priced Individually [ More info ]
|
  |
|
22-13563T 3 - Fuel Connector Fitting, Engine End, Priced Individually [ More info ]
|
| # | 82776 | ATTACHING KIT, Cable And Pulley (1 required per assembly) |
  |
|
82776 - Attaching Assembly [ More info ]
|
| # | 16838A 4 | CHARGING KIT, Battery, Rectifer-6 AMP (1 required per assembly) |
  |
|
16838A 4 - Rectifier Kit [ More info ]
|
| # | 12612Q 2 | FLUSHING ATTACHMENT, Allows running Engine (1 required per assembly) |
  |
|
12612Q 2 - Flushing Kit - Priced Individually [ More info ]
|
  |
|
12612T 2 - Flushing Kit - Priced Individually [ More info ]
|
| # | 22-13563Q 7 | FITTING ASSEMBLY, Fuel Line, Tank End (1 required per assembly) For 6.6 Gallon/25L |
  |
|
22-13563Q 7 - Fuel Fitting - Priced Individually [ More info ]
|
  |
|
18-8091 - Fuel Connector, 22-13563Q7 [ More info ]
|
  |
|
22-13563T 7 - Tank Fitting - Priced Individually [ More info ]
|
| # | 14171Q 2 | MOTOR LOCK (1 required per assembly) |
  |
|
14171Q 2 - Lock Kit - Std - Priced Individually [ More info ] Unavailable |
| #1 | 16837A 2 | ALTERNATOR KIT (1 required per assembly) |
  |
|
16837A 2 - Stator Kit - Light [ More info ]
|
| #2 | 16074T | ALTERNATOR (1 required per assembly) |
  |
|
16074T - Alternator [ More info ]
|
| #3 | 10-16059 | SCREW (2 required per assembly) |
  |
|
10-16059 - Screw [ More info ]
|
| #4 | 54-16060 | CLAMP (1 required per assembly) |
  |
|
54-16060 - Clamp [ More info ]
|
| #5 | 10-16821 | SCREW (1 required per assembly) |
  |
|
10-16821 - Screw [ More info ]
|
| #6 | 16076A 1 | RECTIFIER KIT (1 required per assembly) |
  |
|
16076A 1 - Rectifier Kit [ More info ]
|
| #7 | 89-16077 | FUSE (1 required per assembly) |
  |
|
89-16077 - Fuse [ More info ] Unavailable |
| #8 | 10-16123 | SCREW, (25 mm) (1 required per assembly) |
  |
|
10-16123 - Screw [ More info ]
|
| #9 | 13-16079 | LOCKWASHER (1 required per assembly) |
  |
|
13-16079 - LockWasher [ More info ]
|
| #10 | 12-16080 | WASHER, Stainless Steel (1 required per assembly) |
  |
12-16080 - Washer, Stainless Steel [ More info ] Unavailable |
|
  |
|
128M0108373 - Washer [ More info ]
|
| #11 | 54-813275 | CLAMP (1 required per assembly) |
  |
|
54-813275 - Clamp [ More info ]
|
| #12 | 11-16081 | NUT, Stainless Steel (1 required per assembly) |
  |
|
11-16081 - Nut, Stainless Steel [ More info ]
|
| #13 | 84-16082 | CABLE, Battery (1 required per assembly) |
  |
|
84-16082 - Harness - Battery [ More info ]
|
| #14 | 16839A 4 | GUIDE KIT, Vertical Rope (1 required per assembly) |
  |
|
16839A 4 - Guide Kit -rope [ More info ]
|
| #15 | 16113 | PLATE, Seal (1 required per assembly) |
  |
|
|
| #16 | 10-17173 | SCREW (4 required per assembly) |
  |
|
10-17173 - Screw [ More info ]
|
| #17 | 16841A 2 | FLUSHING ATTACHMENT (1 required per assembly) |
  |
|
16841A 2 - Flushing Kit [ More info ]
|
  |
|
16841Q02 - Flushing Kit - Priced Individually [ More info ]
|
| #18 | 84-17175 | HARNESS ASSEMBLY (1 required per assembly) |
  |
|
84-17175 - Harness - Light [ More info ]
|
| #19 | 853828 | HANDLE, (0.8 Meters) (1 required per assembly) |
  |
|
853828 - Handle A [ More info ] Unavailable |
| #19 | 853828 1 | HANDLE, (1.0 Meters) (1 required per assembly) |
  |
|
853828 1 - Handle A [ More info ]
|
| #20 | 803799A 1 | IGNITION CHECKER (1 required per assembly) |
  |
|
803799A 1 - Ignition Checker [ More info ]
|
