Parts for Mariner 48 HP Recoil Starter

Revise Search: All Models > 48 HP > 670-34580 & Below (ML) > Recoil Starter

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#0-1	83162M	STARTER ASS'Y (1 required per assembly)
		83162M - Housing [ More info ] Unavailable
		84448M - Starter,NLA [ More info ] Unavailable
#1	82552M	HOUSING, STARTER (1 required per assembly)
		82552M - Starter Housing [ More info ] Unavailable
		84449M - Starter Housing, NLA [ More info ] Unavailable
#2	24-81295M	SPRING, STARTER (1 required per assembly)
		24-81295M - Spring, Starter,NLA [ More info ] $15.56 $13.18 4 In Stock.
#3	50-81296M	STARTER PULLEY (1 required per assembly)
		50-81296M - Starter Sheave,NLA [ More info ] Unavailable
#4	23-81309M	COLLAR, ENGAGEMENT CAM (1 required per assembly)
		23-81309M - COLLAR,NLA [ More info ] Unavailable
#5	12-81301M	WASHER, ENGAGEMENT CAM (1 required per assembly)
		12-81301M - Washer, Engagement Cam, NLA [ More info ] $2.00 $1.69 10+ In Stock.
#6	53-81305M	CIRCLIP, ENGAGEMENT CAM (1 required per assembly)
		53-81305M - Snap Ring, NLA [ More info ] $4.00 $3.39 10+ In Stock.
#7	24-81302M	SPRING, ENGAGEMENT CAM (1 required per assembly)
		24-81302M - Spring, Return [ More info ] Unavailable
		24-41294M - Spring, Return,NLA [ More info ] $2.78 $2.36 7 In Stock.
#8	81304M	PAWL, STARTER (1 required per assembly)
		81304M - Pawl [ More info ] Unavailable
		19136M - Pawl, NLA [ More info ] $5.00 $4.24 10+ In Stock.
#9	24-81297M	SPRING, ENGAGEMENT CAM (1 required per assembly)
		24-81297M - SPRING,NLA [ More info ] Unavailable
#10	81298M	CAM, PAWL ENGAGEMENT (1 required per assembly)
		81298M - PLATE [ More info ] Unavailable
		41295M - Plate [ More info ] $7.99 $6.76 4 In Stock.
#11	12-81299M	WASHER, ENGAGEMENT CAM BOLT (1 required per assembly)
		12-81299M - WASHER,NLA [ More info ] Unavailable
#12	10-82403M	BOLT (1 required per assembly)
		10-82403M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-84446M - SCREW [ More info ] Unavailable
		10-84247M - BOLT Note: Priced Individually [ More info ] Unavailable
		10-91725M - BOLT [ More info ] Unavailable
		10-826957M - Bolt, NLA [ More info ] $5.19 10+ In Stock.
#13	13-82197M	LOCKWASHER (2 required per assembly)
		13-82197M - LockWasher - Priced Individually [ More info ] Unavailable
		13-82212M - LockWasher - Priced Individually [ More info ] $1.10 10+ In Stock.
#14	19-80604M	PLUG, STARTER HOUSING (6 required per assembly)
		19-80604M - Plug, NLA [ More info ] Unavailable
#15	81307M	ROLLER, STARTER ROPE (1 required per assembly)
		81307M - Roller, NLA [ More info ] $2.78 $2.36 10+ In Stock.
#16	23-81308M	BUSHING, ROLLER (1 required per assembly)
		23-81308M - Bushing [ More info ] Unavailable
		23-11705M - Bushing, NLA [ More info ] $1.67 $1.42 6 In Stock.
#17	12-83149M	WASHER (1 required per assembly)
		12-83149M - WASHER [ More info ] Unavailable
		13-11706M - LockWasher [ More info ] $1.67 $1.42 1 In Stock.
#18	10-83141M	BOLT (1 required per assembly)
		10-83141M - Screw, NLA [ More info ] $1.39 $1.17 10+ In Stock.
#19	80063M	HANDLE, STARTER (1 required per assembly)
		80063M - Starter Handle [ More info ] Unavailable
		814491A 1 - Handle Kit, NLA [ More info ] $7.78 $6.59 10+ In Stock.
#20	79629A 1	STARTER ROPE (1 required per assembly)
		79629A 1 - Starter Rope Note: Priced Individually [ More info ] Unavailable
		50-28985A 2 - Starter Rope Assembly [ More info ] Unavailable
		50-12066A 9 - Starter Rope , Priced Individually [ More info ] Unavailable
		50-12066Q 9 - Starter Rope , Priced Individually [ More info ] Unavailable
		50-12066Q10 - Starter Rope - Priced Individually [ More info ] $13.59 5 In Stock.
		18-4915 - Pull Rope, 50-12066Q9 [ More info ] $4.79 $4.53 4 In Stock.
		50-12066K10 - Starter Rope - Priced Individually [ More info ] $14.99 2 In Stock.
#21	12-83151M	WASHER (2 required per assembly)
		12-83151M - Washer, NLA [ More info ] $1.88 $1.59 10+ In Stock.
#22	23-83150M	BUSHING (1 required per assembly)
		23-83150M - Collar [ More info ] Unavailable
#23	81300M	DRIVE CUP, PAWL (1 required per assembly)
		81300M - DRIVE CUP,NLA [ More info ] Unavailable
#24	81310M	GUIDE, STARTER ROPE (1 required per assembly)
		81310M - GUIDE,NLA [ More info ] Unavailable
#25	12-82198M	WASHER (8 required per assembly) SERIAL 00002540-09999999
		12-82198M - WASHER Note: Priced Individually [ More info ] Unavailable
		12-82213M - Washer - Priced Individually [ More info ] $1.50 $1.28 10+ In Stock.
#26	23-81967M	COLLAR, GUIDE MOUNT (4 required per assembly) SERIAL 00002540-09999999
		23-81967M - COLLAR,NLA [ More info ] Unavailable
#28	23-82851M	BUSHING (4 required per assembly) SERIAL 00002541-09999999
		23-82851M - Bushing [ More info ] Unavailable
		23-804344003 - Collar [ More info ] $2.29 1 In Stock.
#29	81523M	MOUNT, GUIDE (4 required per assembly)
		81523M - Mount, NLA [ More info ] Unavailable
#30	10-82426M	BOLT, ROPE GUIDE ATTACHING (4 required per assembly)
		10-82426M - BOLT [ More info ] Unavailable
		10-84237M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-83285M - Screw - Priced Individually [ More info ] $5.19 10+ In Stock.
#32	13-81799M	WASHER, LIFT BRACKET BOLT (6 required per assembly)
		13-81799M - LockWasher, NLA [ More info ] Unavailable
#33	25-81937M	GROMMET, LIFT BRACKET (6 required per assembly)
		25-81937M - Grommet, Lift Bracket,NLA [ More info ] Unavailable
#34	23-81978M	COLLAR, LIFT BRACKET (3 required per assembly)
		23-81978M - Bushing,NLA [ More info ] Unavailable
#35	10-82442M	BOLT, STARTER HOUSING ATTACHING (2 required per assembly)
		10-82442M - Bolt, NLA [ More info ] $4.50 10+ In Stock.
#36	10-82443M	BOLT, LIFT BRACKET ATTACHING (1 required per assembly)
		10-82443M - BOLT Note: Priced Individually [ More info ] Unavailable
		10-84236M - Bolt, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#37	13-82200M	LOCKWASHER (8 required per assembly)
		13-82200M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable
		13-82215M - LockWasher - Priced Individually [ More info ] $0.40 10 In Stock.
#38	81313M	BRACKET, STARTER HOUSING (1 required per assembly)
		81313M - Bracket, NLA [ More info ] Unavailable
#39	10-82441M	BOLT, BRACKET ATTACHING (2 required per assembly)
		10-82441M - Bolt, NLA [ More info ] $5.63 $4.77 10+ In Stock.
#40	10-82439M	BOLT, DRIVE CUP ATTACHING (3 required per assembly)
		10-82439M - Screw, NLA [ More info ] $1.50 $1.28 5 In Stock.
#41	81251M	HANGER, ENGINE (1 required per assembly)
		81251M - Bracket [ More info ] Unavailable
		41827M - Hanger, NLA [ More info ] $6.00 $5.08 10+ In Stock.
