Parts for Mariner 48 HP Steering Handle

Revise Search: All Models > 48 HP > 670-02640 & Below (M) > Steering Handle

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#0-1	83703M	STEERING HANDLE ASS'Y (1 required per assembly)
		83703M - HANDLE [ More info ] Unavailable
		92680M - STEERING HANDLE,NLA [ More info ] Unavailable
#1	82553M	ARM, STEERING (1 required per assembly)
		82553M - STEERING HANDLE,NLA [ More info ] Unavailable
#2	81585M	HANDLE, THROTTLE (1 required per assembly)
		81585M - Handle A [ More info ] Unavailable
#3	80509M	GRIP, THROTTLE HANDLE (1 required per assembly)
		80509M - Grip, NLA [ More info ] $9.99 $8.45 6 In Stock.
#4	81356M	INDICATOR, THROTTLE (1 required per assembly)
		81356M - INDICATOR [ More info ] Unavailable
		98947M - Indicator, NLA [ More info ] Unavailable
#5	17-81907M	RIVET, INDICATOR (1 required per assembly)
		17-81907M - Rivet, NLA [ More info ] $7.53 6 In Stock.
#6	10-82483M	SCREW, HANDLE ATTACHING (1 required per assembly)
		10-82483M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-84300M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-811916M - Screw, NLA [ More info ] $3.61 $3.06 10+ In Stock.
#7	12-82204M	WASHER, THROTTLE SHAFT (1 required per assembly)
		12-82204M - Washer, Plate [ More info ] Unavailable
		12-82220M - Washer - Priced Individually [ More info ] Unavailable
#8	24-82095M	SPRING, THROTTLE SHAFT (1 required per assembly)
		24-82095M - Spring, Throttle Shaft,NLA [ More info ] $9.69 10 In Stock.
#9	23-81945M	BUSHING, STEERING ARM (1 required per assembly)
		23-81945M - Bushing, NLA [ More info ] $9.36 10+ In Stock.
#10	81351M	SHAFT, THROTTLE (1 required per assembly)
		81351M - SHAFT,NLA [ More info ] Unavailable
#11	81357M	CAM, THROTTLE (1 required per assembly)
		81357M - Cam [ More info ] Unavailable
		81357T - Cam, NLA [ More info ] $25.00 $21.18 10+ In Stock.
#12	17-82152M	PIN, THROTTLE CAM (1 required per assembly)
		17-82152M - Pin, Throttle Cam Roll, NLA [ More info ] Unavailable
#13	81355M	HOUSING, THROTTLE CAM (1 required per assembly)
		81355M - Housing, NLA [ More info ] Unavailable
#14	27-81353M	GASKET, THROTTLE CAM COVER (1 required per assembly)
		27-81353M - Throttle Cam Cover Gasket [ More info ] Unavailable
#15	81354M	COVER, THROTTLE CAM (1 required per assembly)
		81354M - Cover [ More info ] Unavailable
#16	10-82495M	SCREW, CAM COVER ATTACHING (4 required per assembly)
		10-82495M - SCREW,NLA [ More info ] Unavailable
#17	81329M	THROTTLE CABLE (1 required per assembly)
		81329M - Throttle Cable, NLA [ More info ] $50.00 $42.35 8 In Stock.
#18	83148M	BRACKET, STEERING (1 required per assembly)
		83148M - Bracket, NLA [ More info ] Unavailable
#19	10-81710M	BOLT, ARM ATTACHING (1 required per assembly)
		10-81710M - Bolt, NLA [ More info ] $5.00 $4.24 10+ In Stock.
#20	12-82221M	WASHER, ARM BOLT (1 required per assembly)
		12-82221M - Washer [ More info ] Unavailable
#21	23-81950M	BUSHING, ARM BOLT (1 required per assembly)
		23-81950M - Bushing, NLA [ More info ] $9.76 7 In Stock.
#22	12-81853M	WASHER, ARM BOLT (2 required per assembly)
		12-81853M - Washer, Arm Bolt, NLA [ More info ] $6.28 10+ In Stock.
#23	12-81815M	WASHER, ARM BOLT (2 required per assembly)
		12-81815M - Washer, NLA [ More info ] Unavailable
#24	13-81870M	WASHER, ARM BOLT (1 required per assembly)
		13-81870M - Wave Washer, NLA [ More info ] Unavailable
#25	11-81786M	NUT, ARM BOLT (1 required per assembly)
		11-81786M - Nut, Nylon,NLA [ More info ] $2.25 10+ In Stock.
#26	81402M	BRACKET, IINDICATOR (1 required per assembly)
		81402M - Bracket, NLA [ More info ] Unavailable
#27	81414M	INDICATOR, F-N-R (1 required per assembly)
		81414M - Indicator, NLA [ More info ] $2.22 $1.88 10+ In Stock.
#28	10-82172M	SCREW, INDICATOR BRACKET ATTACHING (2 required per assembly)
		10-82172M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-83870M - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#29	81411M	HANDLE, GEAR SHIFT (1 required per assembly)
		81411M - LEVER,NLA [ More info ] Unavailable
#30	81413M	KNOB, SHIFT CONTROL. (1 required per assembly)
		81413M - HANDLE,NLA [ More info ] Unavailable
#31	23-81946M	BUSHING (2 required per assembly)
		23-81946M - Bushing, NLA [ More info ] $7.00 $5.93 10+ In Stock.
#32	12-81804M	WASHER (1 required per assembly)
		12-81804M - Washer, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#33	11-81785M	NUT, NYLON (1 required per assembly)
		11-81785M - Nut, Nylon,NLA [ More info ] $6.51 10+ In Stock.
#34	81358M	ROD, MANUAL SHIFT (1 required per assembly)
		81358M - Link Rod, NLA [ More info ] $10.00 $8.47 10+ In Stock.
#35	12-82214M	WASHER (1 required per assembly)
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#36	18-82129M	PIN, COTTER (1 required per assembly)
		18-82129M - Pin, Cotter [ More info ] Unavailable
		18-84301M - Cotter Pin, NLA [ More info ] $1.39 $1.17 2 In Stock.
#37	23-81943M	BUSHING (1 required per assembly)
		23-81943M - Bushing, NLA [ More info ] $2.78 $2.36 10+ In Stock.
#38	11-82920M	NUT, CABLE END (1 required per assembly)
		11-82920M - Nut, Cable End,NLA [ More info ] $1.67 $1.42 10 In Stock.
#39	87-81535M	KILL SWITCH ASS'Y (1 required per assembly)
		87-81535M - STOP Switch [ More info ] Unavailable
		87-98955M - Switch,NLA [ More info ] Unavailable
#40	81531M	STOPPER (1 required per assembly)
		81531M - Retainer - Priced Individually [ More info ] Unavailable
		97756M - Lanyard Stopper [ More info ] $34.73 1 In Stock.
#41	83704M	ROD, STEERING LINK (1 required per assembly) CO-PILOT (OPTIONAL)
		83704M - LINK ROD [ More info ] Unavailable
		41848M -Steering Link Rod [ More info ] $10.00 $8.47 6 In Stock.
#42	11-83502M	NUT (2 required per assembly) CO-PILOT (OPTIONAL)
		11-83502M - Nut, Nylon [ More info ] Unavailable
		11-84295M - Nut, Nylon,NLA [ More info ] $7.88 $6.67 10 In Stock.
#43	12-82217M	WASHER (2 required per assembly) CO-PILOT (OPTIONAL)
		12-82217M - Washer, NLA [ More info ] $1.67 $1.42 10 In Stock.
#44	83705M	SHAFT, FRICTION (1 required per assembly) CO-PILOT (OPTIONAL)
		83705M - SHAFT,NLA [ More info ] Unavailable
#45	83706M	PIECE, FRICTION (1 required per assembly) CO-PILOT (OPTIONAL)
		83706M - Coupler,NLA [ More info ] Unavailable
#46	10-82456M	BOLT (1 required per assembly) CO-PILOT (OPTIONAL)
		10-82456M - BOLT Note: Priced Individually [ More info ] Unavailable
		10-96293M - BOLT [ More info ] Unavailable
		10-83285M - Screw - Priced Individually [ More info ] $5.19 10+ In Stock.
#47	11-82703M	NUT, WING (1 required per assembly) CO-PILOT (OPTIONAL)
		11-82703M - Nut, Wing,NLA [ More info ] Unavailable
