Parts for Mariner 48 HP Bottom Cowling
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 2168-6838M | COWLING, BOTTOM (1 required per assembly) SERIAL 00002540-09999999 |
  |
|
2168-6838M - BOTTOM COWL,NLA [ More info ] Unavailable |
| #2 | 27-81368M | SEAL, BOTTOM COWL TO APRON (1 required per assembly) SERIAL 00002540-09999999 |
  |
27-81368M - Bottom Cowl To Apron Gasket [ More info ] Unavailable |
|
  |
|
27-83044M - Gasket [ More info ] Unavailable |
| #3 | 81375M | HOOK, COWL CLAMP - FRONT (1 required per assembly) SERIAL 00002540-09999999 |
  |
|
81375M - Bracket, NLA [ More info ] Unavailable |
| #4 | 2168-6951M | COWLING, BOTTOM (1 required per assembly) SERIAL 00002541-09999999 |
  |
2168-6951M - BOTTOM COWL [ More info ] Unavailable |
|
  |
|
2168-7980M - BOTTOM COWL,NLA [ More info ] Unavailable |
| #5 | 27-83044M | SEAL, BOTTOM COWL TO APRON (1 required per assembly) SERIAL 00002541-09999999 |
| #6 | 83045M | STAY (1 required per assembly) SERIAL 00002541-09999999 |
  |
|
83045M - Bracket, NLA [ More info ] Unavailable |
| #7 | 25-83142M | GROMMET (2 required per assembly) SERIAL 00002541-09999999 |
  |
|
25-83142M - Grommet, NLA [ More info ] Unavailable |
| #8 | 25-81369M | GROMMET (1 required per assembly) |
  |
|
25-81369M - Grommet, NLA [ More info ] Unavailable |
| #9 | 22-81326M | FITTING (1 required per assembly) |
  |
|
22-81326M - Fitting, NLA [ More info ] Unavailable |
| #10 | 25-82061M | GROMMET (1 required per assembly) |
  |
|
25-82061M - Grommet, NLA [ More info ] Unavailable |
| #11 | 25-82065M | GROMMET, APRON BOLT (4 required per assembly) |
  |
|
25-82065M - Grommer, Apron Bolt,NLA [ More info ] Unavailable |
| #12 | 23-81968M | COLLAR, APRON BOLT (4 required per assembly) |
  |
|
23-81968M - COLLAR,NLA [ More info ] Unavailable |
| #13 | 12-81796M | WASHER, APRON BOLT (8 required per assembly) |
  |
|
12-81796M - Washer, Apron Bolt, NLA [ More info ]
|
| #14 | 10-82426M | BOLT, COWLING TO DRIVESHAFT HOUSING (4 required per assembly) |
  |
10-82426M - BOLT [ More info ] Unavailable |
|
  |
10-84237M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-83285M - Screw - Priced Individually [ More info ]
|
| #15 | 13-82197M | LOCKWASHER, APRON BOLT (12 required per assembly) |
  |
13-82197M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #16 | 81377M | HOOK, COWL-REAR (1 required per assembly) SERIAL 00002540-09999999 |
  |
|
81377M - Bracket, NLA [ More info ] Unavailable |
| #17 | 10-82422M | BOLT (4 required per assembly) |
  |
10-82422M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
10-84247M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
10-91725M - BOLT [ More info ] Unavailable |
|
  |
|
10-826957M - Bolt, NLA [ More info ]
|
| #18 | 81371M | BUMPER. COWL (1 required per assembly) |
  |
|
81371M - Bumper, NLA [ More info ]
|
| #19 | 81372M | RETAINER, COWL BUMPER (1 required per assembly) SERIAL 00002540-09999999 |
  |
|
81372M - Retainer,NLA [ More info ] Unavailable |
| #19 | 83153M | RETAINER, COWL BUMPER (1 required per assembly) SERIAL 00002541-09999999 |
  |
|
83153M - Retainer, NLA [ More info ]
|
| #20 | 81374M | APRON, COWL - FRONT (1 required per assembly) |
  |
81374M - Cover [ More info ] Unavailable |
|
  |
|
95664M - Cover, NLA [ More info ] Unavailable |
| #21 | 81378M | APRON, COWL - REAR (1 required per assembly) |
  |
81378M - Cover [ More info ] Unavailable |
|
  |
|
95665M - Cover, NLA [ More info ] Unavailable |
| #22 | 10-82451M | BOLT, APRON ATTACHING (2 required per assembly) |
  |
10-82451M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-82423M - Bolt, NLA [ More info ]
|
| #23 | 10-82453M | BOLT, APRON ATTACHING (2 required per assembly) |
  |
10-82453M - Bolt - Priced Individually [ More info ] Unavailable |
|
  |
|
10-82405M - Screw, NLA [ More info ]
|
| #24 | 54-82983M | CLAMP (1 required per assembly) |
  |
|
54-82983M - CLAMP,NLA [ More info ] Unavailable |
| #25 | 23-81376M | FASTENER (1 required per assembly) |
  |
|
23-81376M - Bushing,NLA [ More info ] Unavailable |
| #26 | 32-81324M | ROD (1 required per assembly) |
  |
|
32-81324M - Hose, NLA [ More info ] Unavailable |
| #27 | 91-80942M | TOOL KIT (1 required per assembly) |
  |
91-80942M - TOOL KIT [ More info ] Unavailable |
|
  |
91-80277M - TOOL KIT [ More info ] Unavailable |
|
  |
91-81669M - Tool Kit [ More info ] Unavailable |
|
  |
|
91-803581 - Tool Kit [ More info ] Unavailable |
| #28 | 47341A 1 | STARTER ROPE (1 required per assembly) |
  |
47341A 1 - Rope And Handle [ More info ] Unavailable |
|
  |
|
47341A11 - Manual Start Rope And Handle [ More info ]
|
| #29 | 37-83053M | DECAL, SIDE (2 required per assembly) SERIAL 00002541-09999999 |
  |
|
37-83053M - Decal, NLA [ More info ]
|
| #30 | 83047M | COVER, BOTTOM (1 required per assembly) SERIAL 00002541-09999999 |
  |
|
83047M - Cover, NLA [ More info ] Unavailable |
