Parts for Mariner 45 HP (4 Cylinder) Clamp Bracket Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 1440-8394A 2 | CLAMP BRACKET ASSEMBLY (MANUAL) (2 required per assembly) |
  |
|
1440-8394A 2 - Clamp Bracket, NLA [ More info ] Unavailable |
| #1 | 1440-8394A 1 | CLAMP BRACKET ASSEMBLY ( ELECTRIC) MERCURY (2 required per assembly) |
  |
|
1440-8394A 1 - Clamp Bracket Assembly [ More info ] Unavailable |
| #1 | 1440-8394A 3 | CLAMP BRACKET ASSEMBLY (ELECTRIC ) MARINER (2 required per assembly) |
  |
|
1440-8394A 3 - Clamp Bracket, NLA [ More info ] Unavailable |
| #2 | 10-90470A 3 | THUMB SCREW ASSEMBLY (MANUAL) (2 required per assembly) |
  |
|
10-90470A 3 - Thumb Screw Assembly, NLA [ More info ]
|
| #2 | 10-78492A 1 | THUMB SCREW ASSEMBLY (ELECTRIC) (2 required per assembly) |
  |
|
10-78492A 1 - Screw Assembly, NLA [ More info ] Unavailable |
| #3 | 12-78493 | WASHER, THUMB SCREW (2 required per assembly) |
  |
|
12-78493 - Wahser, Thumb Screw, NLA [ More info ]
|
| #4 | 10-78495 1 | SCREW, WASHER TO THUMB SCREW (2 required per assembly) |
  |
10-78495 1 - SCREW [ More info ] Unavailable |
|
  |
|
10-78495 - Screw - Priced Individually [ More info ]
|
| #5 | 75043 | CAP, THUMB SCREW (ELECTRIC) (2 required per assembly) |
  |
|
|
| #6 | 74528 | TILT TUBE (1 required per assembly) |
  |
74528 - Tilt Tube [ More info ] Unavailable |
|
  |
883067 - Tilt Tube [ More info ] Unavailable |
|
  |
8M0035074 - Tilt Tube [ More info ] Unavailable |
|
  |
|
8M0041936 - Tilt Tube [ More info ]
|
| #7 | 12-52864 | WASHER, TILT TUBE (2 required per assembly) |
  |
|
12-52864 - Washer, Tilt Tube, NLA [ More info ]
|
| #8 | 11-56041 | NUT, TILT TUBE (2 required per assembly) |
  |
11-56041 - Nut (7/8-14) [ More info ] Unavailable |
|
  |
11-30499 - Nut (7/8-14) [ More info ] Unavailable |
|
  |
|
11-858869 - Nut, (.875-14) [ More info ]
|
| #9 | 53078 | CAP, PLASTIC - TILT TUBE (2 required per assembly) |
  |
|
53078 - Plastic Cap, NLA [ More info ]
|
| #10 | 55-28416 | PIN, UPPER SHOCK - WITH SHOCK ABSORBER (1 required per assembly) |
  |
|
55-28416 - Upper Shock Pin, NLA [ More info ]
|
| #11 | 23-73203 | BUSHING, CLAMP BRACKET (2 required per assembly) |
  |
|
23-73203 - Bushing, NLA [ More info ]
|
| #12 | 23-59623 | SPACER, CLAMP BRACKET STUD (1 required per assembly) |
  |
|
23-59623 - Spacer, NLA [ More info ] Unavailable |
| #13 | 16-59625 | STUD, CLAMP BRACKET (1 required per assembly) |
  |
|
16-59625 - Stud, NLA [ More info ]
|
| #14 | 13-26993 | LOCKWASHER, CLAMP BRACKET STUD (2 required per assembly) |
  |
|
13-26993 - LockWasher - Priced Individually [ More info ]
|
  |
|
138M0204647 - LOCKWASHER, Priced Individually [ More info ]
|
| #15 | 11-28770 | NUT, CLAMP BRACKET STUD (2 required per assembly) |
  |
|
11-28770 - Nut (5/16-24) [ More info ]
|
| #16 | 17-49930A 1 | TILT LOCK PIN ASSEMBLY (1 required per assembly) |
  |
17-49930A 1 - Tilt Pin Assembly [ More info ] Unavailable |
|
  |
|
17-8M0026068 - Pin Assembly - Tilt [ More info ]
|
| #17 | 32-28052 | SLEEVE, RUBBER - TILT LOCK PIN (1 required per assembly) |
  |
|
32-28052 - Tubing, NLA [ More info ] Unavailable |
| #18 | 10-68298 | BOLT, CLAMP BRACKET TO TRANSOM (3-1/4") (2 required per assembly) |
  |
|
10-68298 - Screw, NLA [ More info ]
|
| #19 | 12-68410 | WASHER, CLAMP BRACKET BOLT (2 required per assembly) |
  |
|
12-68410 - Washer, NLA [ More info ]
|
| #18 | 10-89673 | BOLT, CLAMP BRACKET TO TRANSOM (5") (2 required per assembly) |
  |
|
10-89673 - Screw, NLA [ More info ]
|
| #19 | 12-28420 | WASHER, CLAMP BRACKET BOLT (2 required per assembly) |
  |
|
12-28420 - Washer [ More info ] Unavailable |
| #19 | 12-68300 | WASHER, CLAMP BRACKET BOLT (2 required per assembly) |
  |
|
12-68300 - Washer, (..88 X .39 X .06) [ More info ]
|
| #20 | 11-99405 | NUT, CLAMP BRACKET BOLT (4 required per assembly) |
  |
|
11-99405 - Nut (3/8-16) (brass) [ More info ]
|
  |
|
11-826711 12 - Nut, (.375-16) [ More info ]
|
| #21 | 55-58780A 3 | SHOCK ABSORBER MERCURY (2 required per assembly) W/SHOCK ABSORBER |
  |
55-58780A 3 - Shock Absorber [ More info ] Unavailable |
|
  |
|
55-58780A 7 - Shock Abs Assembly -bl, NLA [ More info ] Unavailable |
| #21 | 55-58780A 4 | SHOCK ABSORBER MARINER (2 required per assembly) W/SHOCK ABSORBER |
  |
|
55-58780A 4 - Shock Abs Assembly -gr, NLA [ More info ] Unavailable |
| #22 | 55-69653 | PIN, LOWER SHOCK (2 required per assembly) W/SHOCK ABSORBER |
  |
55-69653 - Pin, Lower Shock [ More info ] Unavailable |
|
  |
|
55-69653 1 - Pin, NLA [ More info ]
|
| #23 | 12-34937 | WASHER, UPPER BUSHING RETAINER (INNER) (2 required per assembly) W/SHOCK ABSORBER |
  |
|
12-34937 - Washer, (.766 X 1.312 X .125) [ More info ]
|
| #24 | 12-59378 | WASHER, LOWER BRUSHING RETAINER (INNER) (2 required per assembly) W/SHOCK ABSORBER |
  |
|
12-59378 - Washer, NLA [ More info ]
|
| #25 | 23-32171 | BUSHING, RUBBER - SHOCK ABSORBER (UPPER) (4 required per assembly) W/SHOCK ABSORBER |
  |
|
23-32171 - Bushing, NLA [ More info ]
|
| #26 | 23-28198 | BUSHING, RUBBER - SHOCK ABSORBER (LOWER) (4 required per assembly) W/SHOCK ABSORBER |
  |
|
23-28198 - Bushing, NLA [ More info ] Unavailable |
| #27 | 12-69374 | WASHER, UPPER AND LOWER BUSHING (OUTER) (4 required per assembly) W/SHOCK ABSORBER |
  |
|
12-69374 - Washer [ More info ]
|
| #28 | 10-69375A 1 | SCREW, UPPER AND LOWER SHOCK PIN (5/8") (4 required per assembly) |
  |
|
10-69375A 1 - Screw & Washer, NLA [ More info ] Unavailable |
| #29 | 98876 | STRAP, TILT STOP (1 required per assembly) W/O SHOCK ABSORBER |
  |
|
98876 - Tilt Stop Strap, NLA [ More info ] Unavailable |
| #30 | 98878 | PIN, LOWER SHOCK MOUNT (1 required per assembly) W/O SHOCK ABSORBER |
  |
|
98878 - Pin, NLA [ More info ]
|
| #31 | 24-98875 | SPRING (1 required per assembly) W/O SHOCK ABSORBER |
  |
|
24-98875 - Spring, NLA [ More info ]
|
| #32 | 18-32857 | COTTER PIN (1 required per assembly) W/O SHOCK ABSORBER |
  |
|
18-32857 - Cotter Pin , Priced Individually [ More info ]
|
  |
|
18-32857 1 - Cotter Pin [ More info ]
|
  |
|
18-8M0214922 - PIN-COTTER [ More info ] Unavailable |
| #33 | 98877 | UPPER SHOCK MOUNT (1 required per assembly) W/O SHOCK ABSORBER |
  |
|
98877 - Upper Shock Mount, NLA [ More info ]
|
