Parts for Mariner 45 HP (4 Cylinder) Auto Blend
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 13019 30 | AUTO-BLEND (1 required per assembly) |
  |
13019 30 - Auto Blend [ More info ] Unavailable |
|
  |
|
13019 31 - Auto Blend , NLA [ More info ] Unavailable |
| #1 | 13982 | OIL TANK KIT (1 required per assembly) |
  |
13982 - OIL TANK [ More info ] Unavailable |
|
  |
|
16612 - Oil Tank Kit, NLA [ More info ] Unavailable |
| #2 | 13996 | HANDLE KIT (1 required per assembly) |
  |
|
13996 - Handle Kit, NLA [ More info ]
|
| #3 | 36-13986 | CAP, OIL TANK (1 required per assembly) |
  |
|
36-13986 - Auto Blend Cap, NLA [ More info ]
|
| #4 | 13994 | HARDWARE KIT (1 required per assembly) |
  |
13994 - HARDWARE KIT [ More info ] Unavailable |
|
  |
|
16614 - HARDWARE KIT,NLA [ More info ] Unavailable |
| #5 | 19-13979 | DRAIN PLUG KIT (1 required per assembly) |
  |
|
19-13979 - PLUG KIT-DRAIN,NLA [ More info ] Unavailable |
| #6 | 16611 | DIAPHRAGM KIT (1 required per assembly) |
  |
|
16611 - Diaphragm Kit, NLA [ More info ]
|
| #7 | 13990 | BRACKET (1 required per assembly) |
  |
|
13990 - Bracket, NLA [ More info ] Unavailable |
| #8 | 13993 | BAND (1 required per assembly) |
  |
|
13993 - BAND,NLA [ More info ] Unavailable |
| #9 | 13983 | BRACKET (LEFT) (1 required per assembly) |
  |
|
13983 - Bracket-LEFT,NLA [ More info ] Unavailable |
| #10 | 13984 | BRACKET (RIGHT) (1 required per assembly) |
  |
|
13984 - Bracket - Right, NLA [ More info ]
|
| #11 | 13991 | COVER (1 required per assembly) |
  |
13991 - Cover [ More info ] Unavailable |
|
  |
|
16613 - Cover, NLA [ More info ] Unavailable |
| #12 | 35-13985 | OIL FILTER AND LEVEL SENSOR KIT (1 required per assembly) |
  |
|
35-13985 - Filter Kit, NLA [ More info ] Unavailable |
| #13 | 13987 | HORN KIT (1 required per assembly) |
  |
|
13987 - Horn Kit, NLA [ More info ] Unavailable |
| #14 | 84-13988 | WIRING HARNESS (1 required per assembly) |
  |
|
84-13988 - Harness Assembly, NLA [ More info ]
|
| #15 | 88-13989 | FUSE (.5 AMP) (1 required per assembly) |
  |
|
88-13989 - FUSE,NLA [ More info ] Unavailable |
| #16 | 35-13981 | FUEL FILTER KIT (1 required per assembly) |
  |
35-13981 - Fuel Filter Kit [ More info ] Unavailable |
|
  |
|
35-18089 - Filter, NLA [ More info ]
|
| #17 | 32-13992 | VINYL TUBE (1 required per assembly) |
  |
|
32-13992 - Tubing, NLA [ More info ] Unavailable |
| #18 | 32-13995 | FUEL TUBE KIT (1 required per assembly) |
  |
|
32-13995 - Fuel Line, NLA [ More info ]
|
| #19 | 15387A 1 | OIL STRAINER (1 required per assembly) |
  |
|
15387A 1 - A/B Strainer Kit, NLA [ More info ]
|
| #20 | 21-16615 | CHECK VALVE KIT (1 required per assembly) |
  |
|
21-16615 - Check Valve Kit, NLA [ More info ]
|
| #21 | 27-16616 | GASKET KIT (1 required per assembly) |
  |
|
27-16616 - Oil Tank Gasket Kit [ More info ]
|
