Parts for Mariner 40A (Above Prop. Exhaust) Steering Handle
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #0-1 | 93050M | STEERING HANDLE ASS'Y (1 required per assembly) |
  |
|
93050M - Steering Handle, NLA [ More info ] Unavailable |
| #1 | 84971M | HANDLE, STEERING (1 required per assembly) |
  |
|
84971M - Steering Handle, NLA [ More info ]
|
| #2 | 81585M | GRIP, STEERING HANDLE (1 required per assembly) |
  |
|
81585M - Handle A [ More info ] Unavailable |
| #3 | 84854M | RUBBER, HANDLE (1 required per assembly) |
  |
84854M - HANDLE [ More info ] Unavailable |
|
  |
95497M - HANDLE [ More info ] Unavailable |
|
  |
95497 1 - Grip [ More info ] Unavailable |
|
  |
|
8M0080456 - Grip [ More info ]
|
| #4 | 83515M | INDICATOR, THROTTLE (1 required per assembly) |
  |
83515M - INDICATOR [ More info ] Unavailable |
|
  |
|
97763M - Indicator, NLA [ More info ] Unavailable |
| #5 | 17-81907M | RIVET (1 required per assembly) |
  |
|
17-81907M - Rivet, NLA [ More info ]
|
| #6 | 10-82483M | SCREW (1 required per assembly) |
  |
10-82483M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
10-84300M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-811916M - Screw, NLA [ More info ]
|
| #7 | 12-82204M | WASHER (1 required per assembly) |
  |
12-82204M - Washer, Plate [ More info ] Unavailable |
|
  |
|
12-82220M - Washer - Priced Individually [ More info ] Unavailable |
| #8 | 24-82095M | SPRING (1 required per assembly) |
  |
|
24-82095M - Spring, Throttle Shaft,NLA [ More info ]
|
| #9 | 23-81945M | BUSHING (1 required per assembly) |
  |
|
23-81945M - Bushing, NLA [ More info ]
|
| #10 | 83516M | SHAFT, STEERING HANDLE (1 required per assembly) |
  |
|
83516M - Shaft, NLA [ More info ]
|
| #11 | 83517M | BRACKET (1 required per assembly) |
  |
|
83517M - Bracket, NLA [ More info ] Unavailable |
| #12 | 10-82452M | BOLT (2 required per assembly) |
  |
|
10-82452M - Bolt - Priced Individually [ More info ]
|
  |
|
10-84058M - Bolt [ More info ]
|
| #13 | 12-82214M | WASHER (2 required per assembly) |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #14 | 43-80778M | GEAR (1 required per assembly) |
  |
|
43-80778M - Gear, Pinion, NLA [ More info ]
|
| #15 | 17-82151M | PIN, ROLL (1 required per assembly) |
  |
|
17-82151M - Pin -roll [ More info ]
|
| #16 | 43-94512M | PINION (1 required per assembly) |
  |
|
43-94512M - Pinion, NLA [ More info ]
|
| #17 | M-94513M | BUSHING (1 required per assembly) |
  |
|
23-94513M - BUSHING NLA [ More info ] Unavailable |
| #18 | 11-82389M | NUT (1 required per assembly) |
  |
|
11-82389M - Nut, NLA [ More info ] Unavailable |
| #19 | 13-82212M | WASHER, LOCK (1 required per assembly) |
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #20 | 83520M | THROTTLE WIRE COMPLETE (2 required per assembly) |
  |
|
83520M - Throttle Wire, NLA [ More info ] Unavailable |
| #21 | 83521M | HOLDER, WIRE (1 required per assembly) |
  |
|
83521M - Holder, NLA [ More info ] Unavailable |
| #22 | 83522M | HOLDER, WIRE (1 required per assembly) |
  |
|
83522M - Wire Holder, NLA [ More info ]
|
| #23 | 10-83523M | SCREW (2 required per assembly) |
  |
|
10-83523M - Screw, NLA [ More info ]
|
| #24 | 23-81950M | BUSHING (1 required per assembly) |
  |
|
23-81950M - Bushing, NLA [ More info ]
|
| #25 | 10-94514M | BOLT (1 required per assembly) |
  |
|
10-94514M - Bolt, NLA [ More info ]
|
| #26 | 12-83524M | WASHER (1 required per assembly) |
  |
|
12-83524M - Washer, NLA [ More info ]
|
| #27 | 12-81853M | WASHER (2 required per assembly) |
  |
|
12-81853M - Washer, Arm Bolt, NLA [ More info ]
|
| #28 | 12-81815M | WASHER (2 required per assembly) |
  |
|
12-81815M - Washer, NLA [ More info ] Unavailable |
| #29 | 13-81870M | WASHER, WAVE (1 required per assembly) |
  |
|
13-81870M - Wave Washer, NLA [ More info ] Unavailable |
| #30 | 11-81786M | NUT, NYLON (1 required per assembly) |
  |
|
11-81786M - Nut, Nylon,NLA [ More info ]
|
| #31 | 82895M | PIECE, FRICTION (1 required per assembly) OPTIONAL PARTS |
  |
|
82895M - Guide, NLA [ More info ]
|
| #32 | 10-84058M | BOLT (1 required per assembly) OPTIONAL PARTS |
| #33 | 11-83056M | NUT (1 required per assembly) OPTIONAL PARTS |
  |
|
11-83056M - Nut, Nylon, NLA [ More info ]
|
