Parts for Mariner 40 HP EFI (4 Cylinder) (4-Stroke) Driveshaft Housing
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 1503-852421T 5 | HOUSING, Driveshaft (1 required per assembly) |
  |
1503-852421T 5 - D SHAFT HSG-BLK [ More info ] Unavailable |
|
  |
|
1503-852421T07 - Drive Shaft Housin [ More info ] Unavailable |
| #2 | 825220T06 | PIPE, Exhaust (1 required per assembly) |
  |
|
825220T06 - Retainer Assembly Kit [ More info ]
|
| #3 | 10-824459110 | SCREW, (M8 x 110) Stainless Steel (8 required per assembly) |
  |
|
10-824459110 - Screw [ More info ]
|
| #4 | 10-889608 45 | SCREW, (M8 x 45) (5 required per assembly) |
  |
|
10-889608 45 - Screw [ More info ]
|
| #5 | 828818 1 | PLUG, Drain (1 required per assembly) |
  |
|
828818 1 - Drain Plug [ More info ]
|
| #6 | 27-828816 | GASKET (1 required per assembly) |
  |
27-828816 - Driveshaft Housing Plug Gasket [ More info ] Unavailable |
|
  |
|
27-8M0204692 - Gasket Note: Priced Individually [ More info ]
|
| #7 | 826276 | BUMPER (2 required per assembly) |
  |
|
|
| #8 | 25-828817 | GROMMET (1 required per assembly) SN# USA-0T979999/BEL-0P325499 & Below |
  |
|
25-828817 - Grommet [ More info ]
|
  |
25-828817001 - Grommet [ More info ] Unavailable |
|
  |
258M4504002 - Grommet [ More info ] Unavailable |
|
  |
|
258M0151042 - Grommet [ More info ]
|
| #8 | 25-828817001 | GROMMET (1 required per assembly) SN# USA-0T980000/BEL-0P325500 & Up |
| #9 | 16-823984 | STUD, (M10 x 50) (1 required per assembly) (Non-Bigfoot) |
  |
|
16-823984 - Stud [ More info ]
|
| #9 | 16-90350 1 | STUD, (M10 x 100) (1 required per assembly) (Bigfoot-Long) |
  |
|
16-90350 1 - Stud [ More info ]
|
| #10 | 12-856774 | WASHER, (.406 x .750 x .105) Stainless Steel (1 required per assembly) |
  |
12-856774 - Washer, (.406 X .750 X .105) Stainless Steel [ More info ] Unavailable |
|
  |
|
128M0214963 - WASHER Note: Priced Individually [ More info ]
|
| #11 | 11-40140 | NUT, (M10) (1 required per assembly) |
  |
|
11-40140 - Nut, (M10) [ More info ]
|
| #12 | 32-888591 | TUBE, Water (1 required per assembly) (Long) |
  |
32-888591 - TUBE-WATER [ More info ] Unavailable |
|
  |
32-888591001 - Water Tube [ More info ] Unavailable |
|
  |
|
32-897971A01 - Water Tube - Long [ More info ]
|
| #12 | 32-828937 1 | TUBE, Water (1 required per assembly) (X-Long) |
  |
32-828937 1 - Water Tube [ More info ] Unavailable |
|
  |
|
32-8M4501430 - Water Tube 4 Inch XL Extension only [ More info ]
|
| #13 | 54-828529 | GUIDE (1 required per assembly) |
  |
|
54-828529 - Guide [ More info ]
|
| #14 | 828706 | BUMPER (1 required per assembly) |
  |
828706 - Bumper [ More info ] Unavailable |
|
  |
|
8M0043364 - Bumper [ More info ]
|
| #15 | 42941 | SEAL, Water Tube (1 required per assembly) SN# USA-0T979999/BEL-0P325499 & Below |
  |
42941 - SEAL [ More info ] Unavailable |
|
  |
|
42941001 - Water Tube Seal [ More info ]
|
| #15 | 42941001 | SEAL, Water Tube (1 required per assembly) SN# USA-0T980000/BEL-0P325500 & Up |
| #16 | 854471 | PLATE (1 required per assembly) |
  |
854471 - Plate -dsh [ More info ] Unavailable |
|
  |
|
893770 - Plate -dsh [ More info ] Unavailable |
  |
|
8M4503628 - Plate-DSH [ More info ]
|
| #17 | 10-19933 25 | SCREW, (M10 x 25) (1 required per assembly) |
  |
|
10-19933 25 - Screw [ More info ]
|
| #18 | 19-892286 | CAP (1 required per assembly) (Design II) |
  |
|
|
| #19 | 54-816311T | TIE STRAP, (8.00 Inches) (1 required per assembly) |
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #20 | 22-13035 | FITTING (1 required per assembly) SN# USA-0T979999/BEL-0P325499 & Below |
  |
22-13035 - Fitting [ More info ] Unavailable |
|
  |
22-13035002 - Fitting [ More info ] Unavailable |
|
  |
|
22-8M0181450 - FITTING [ More info ] Unavailable |
| #20 | 22-13035002 | FITTING (1 required per assembly) SN# USA-0T980000/BEL-0P325500 & Up |
| #21 | 23-813745 | SPACER (1 required per assembly) |
  |
|
23-813745 - Spacer [ More info ]
|
| #22 | 43585 | COUPLING (1 required per assembly) |
  |
|
43585 - Shift Shaft Coupling [ More info ]
|
  |
|
18-1730 - Coupling, 43585 [ More info ]
|
  |
|
93-02639 - Shift Coupling 43585 [ More info ]
|
| #23 | 23-855623 | BUSHING (1 required per assembly) |
  |
|
23-855623 - Bushing [ More info ] Unavailable |
| #24 | 12-45176 | WASHER, (.453 x .812 x .105) Stainless Steel (2 required per assembly) |
  |
|
12-45176 - Washer, (.453 X .812 X .105) [ More info ]
|
| #26 | 22-85822A 7 | SPEEDOMETER PICK UP (1 required per assembly) (Design I) |
  |
|
22-85822A 7 - Connector Assembly [ More info ] Unavailable |
| #27 | 22-85822 | CONNECTOR, Straight (1 required per assembly) (Design I) |
  |
|
22-85822 - Connector [ More info ]
|
  |
|
22-85822T - Speedometer Tube Connector [ More info ]
|
| #28 | 12092A 3 | SPACER KIT (1 required per assembly) (X-Long) |
  |
|
12092A 3 - Spacer - Drive Shaft Housing - XL - Black [ More info ]
|
| #29 | 17-43043 | PIN, Dowel - With Hole (.375 x .625) , Front (W/Hole) (1 required per assembly) (X-Long) |
  |
|
17-43043 - Pin, Dowel [ More info ]
|
  |
|
178M0084244 - Pin - Dowel [ More info ]
|
| #30 | 17-43044 | PIN, Dowel - Without Hole (.375 x .625), Rear (1 required per assembly) (X-Long) |
  |
|
17-43044 - Pin -Dowel-solid [ More info ]
|
| #31 | 16-90350 3 | STUD, (M10 x 190) (4 required per assembly) (X-Long) |
  |
|
16-90350 3 - Stud [ More info ]
|
| #32 | 16-90350 2 | STUD, (M10 x 227) (1 required per assembly) (X-Long) |
  |
|
16-90350 2 - Stud [ More info ]
|
