Parts for Mariner 3.5 HP Recoil Starter
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #0-1 | 2169-6911M | STARTER ASSEMBLY (1 required per assembly) |
  |
|
2169-6911M - Starter Housing,NLA [ More info ] Unavailable |
| #1 | 2169-7159M | STARTER HOUSING (1 required per assembly) |
  |
|
2169-7159M - Housing, NLA [ More info ] Unavailable |
| #2 | 80039M | SPACER (1 required per assembly) |
  |
|
80039M - PLATE,NLA [ More info ] Unavailable |
| #3 | 24-80056M | SPRING (1 required per assembly) |
  |
|
24-80056M - Spring [ More info ]
|
| #4 | 50-80057M | STARTER SHEAVE (1 required per assembly) |
  |
|
50-80057M - Starter Sheave,NLA [ More info ] Unavailable |
| #5 | 12-82782M | WASHER (1 required per assembly) |
  |
|
12-82782M - Washer, NLA [ More info ]
|
| #6 | 24-80058M | SPRING (1 required per assembly) |
  |
|
24-80058M - Spring, NLA [ More info ] Unavailable |
| #7 | 24-80060M | SPRING (1 required per assembly) |
  |
|
24-80060M - Spring, NLA [ More info ] Unavailable |
| #8 | 80061M | PAWL (3 required per assembly) |
  |
|
80061M - Pawl, NLA [ More info ]
|
| #9 | 80036M | DRIVE PLATE (1 required per assembly) |
  |
|
80036M - Plate [ More info ] Unavailable |
| #11 | 54-80062M | SNAP RING (1 required per assembly) |
  |
|
54-80062M - Snap Ring, NLA [ More info ]
|
| #12 | 50-12066A 9 | STARTER ROPE (1 required per assembly) |
  |
50-12066A 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
50-12066Q 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
|
50-12066Q10 - Starter Rope - Priced Individually [ More info ]
|
  |
|
18-4915 - Pull Rope, 50-12066Q9 [ More info ]
|
  |
|
50-12066K10 - Starter Rope - Priced Individually [ More info ]
|
| #13 | 80063M | HANDLE (1 required per assembly) |
  |
80063M - Starter Handle [ More info ] Unavailable |
|
  |
|
814491A 1 - Handle Kit, NLA [ More info ]
|
| #14 | 80125M | GUIDE (1 required per assembly) |
  |
|
80125M - Guide, NLA [ More info ] Unavailable |
| #15 | 80973M | PULLEY (1 required per assembly) SERIAL 00023741-09999999 |
  |
|
80973M - PULLEY,NLA [ More info ] Unavailable |
| #15 | NLA | PULLEY (1 required per assembly) SERIAL 00000000-00023740 |
  |
|
NLA - No Longer Availab [ More info ] Unavailable |
| #16 | 53-82336M | SNAP RING (1 required per assembly) |
  |
|
53-82336M - E-Ring, NLA [ More info ]
|
| #17 | 10-84315M | BOLT (1 required per assembly) |
  |
10-84315M - BOLT [ More info ] Unavailable |
|
  |
|
10-84088M - Bolt [ More info ]
|
| #18 | 13-82212M | LOCKWASHER (4 required per assembly) |
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #19 | 80276M | COVER (1 required per assembly) |
  |
|
80276M - Cover, NLA [ More info ] Unavailable |
| #20 | 10-83539M | BOLT (2 required per assembly) |
  |
|
10-83539M - 10-83539M - BOLT (M6 x 20) [ More info ] Unavailable Replaced by 10-84058M |
  |
|
10-84058M - Bolt [ More info ]
|
| #22 | 12-82213M | WASHER (4 required per assembly) |
  |
|
12-82213M - Washer - Priced Individually [ More info ]
|
| #23 | 23-81976M | PORT COLLAR (2 required per assembly) |
  |
|
23-81976M - Spacer, NLA [ More info ] Unavailable |
| #24 | 23-81975M | STARBOARD COLLAR (2 required per assembly) |
  |
|
23-81975M - SPACER,NLA [ More info ] Unavailable |
| #25 | 80032M | PLATE (1 required per assembly) |
  |
|
80032M - PLATE,NLA [ More info ] Unavailable |
| #26 | 10-84303M | BOLT (3 required per assembly) |
  |
|
10-84303M - Screw , Priced Individually [ More info ]
|
  |
10-813477M - BOLT [ More info ] Unavailable |
|
  |
|
10-91772M - Bolt [ More info ]
|
| #27 | 10-82451M | BOLT (2 required per assembly) |
  |
10-82451M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-82423M - Bolt, NLA [ More info ]
|
| #28 | 23-82214M | WASHER (4 required per assembly) |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
