Parts for Mariner 30A C.d.i Magneto
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 253-811178M | FLYWHEEL (ELECTRIC) (1 required per assembly) |
  |
253-811178M - Flywheel [ More info ] Unavailable |
|
  |
|
253-8482M - Flywheel, NLA [ More info ] Unavailable |
| #1 | 253-8927M | FLYWHEEL (MANUAL)1 (1 required per assembly) |
  |
253-8927M - Flywheel [ More info ] Unavailable |
|
| #2 | 811176M | BASE ASSEMBLY (1 required per assembly) |
  |
|
811176M - Base, NLA [ More info ] Unavailable |
| #3 | 84879M | IGNITION COIL (1 required per assembly) |
  |
|
|
  |
|
|
| #4 | 10-82521M | SCREW (2 required per assembly) |
  |
|
10-82521M - Screw [ More info ]
|
  |
|
10-83108M - Screw, NLA [ More info ]
|
| #5 | 13-82186M | WASHER (2 required per assembly) |
  |
|
13-82186M - LockWasher, NLA [ More info ]
|
| #6 | 84881M | LIGHTING COIL (1 required per assembly) |
  |
|
84881M - Lighting Coil, NLA [ More info ] Unavailable |
| #9 | 84877M | PULSER (1 required per assembly) |
  |
|
84877M - Pulser, NLA [ More info ] Unavailable |
| #10 | 10-811177M | SCREW (2 required per assembly) |
  |
|
10-811177M - Screw, NLA [ More info ]
|
| #11 | 10-82499M | SCREW (1 required per assembly) |
  |
|
10-82499M - Screw, NLA [ More info ]
|
| #12 | 84-84883M | GROUND WIRE (1 required per assembly) |
  |
|
84-84883M - Lead Wire, NLA [ More info ] Unavailable |
| #13 | 12-82214M | WASHER (2 required per assembly) |
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #14 | 96649M | COVER (1 required per assembly) |
  |
|
96649M - Cover [ More info ] Unavailable |
| #15 | 10-82436M | SCREW (3 required per assembly) |
  |
|
10-82436M - Bolt, NLA [ More info ]
|
| #16 | 11-96650M | NUT (1 required per assembly) |
  |
|
11-96650M - Nut [ More info ] Unavailable |
| #17 | 12-96651M | WASHER (1 required per assembly) |
  |
|
12-96651M - Washer, NLA [ More info ]
|
| #18 | 84885M | STOP (1 required per assembly) |
  |
|
84885M - Stop,NLA [ More info ] Unavailable |
| #19 | 84886M | CAP (1 required per assembly) |
  |
|
84886M - Cap, NLA [ More info ] Unavailable |
| #20 | 10-84315M | BOLT (2 required per assembly) |
  |
10-84315M - BOLT [ More info ] Unavailable |
|
  |
|
10-84088M - Bolt [ More info ]
|
| #21 | 84887M | CAM (1 required per assembly) |
  |
|
84887M - Cam, NLA [ More info ] Unavailable |
| #22 | 10-84313M | BOLT (2 required per assembly) |
  |
|
10-84313M - Bolt, NLA [ More info ]
|
| #23 | 12-82211M | WASHER (2 required per assembly) |
  |
|
12-82211M - Washer - Priced Individually [ More info ]
|
| #24 | 28-81915M | KEY (1 required per assembly) |
  |
|
28-81915M - Key, NLA [ More info ]
|
