Parts for Mariner 30A Fuel Pump, Fuel Lines & Filter

Revise Search: All Models > 30A > 689-530101 & Up (ML) > Fuel Pump, Fuel Lines & Filter

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	43113M	FUEL PUMP ASSEMBLY (1 required per assembly)
		43113M - Fuel Pump [ More info ] Unavailable
		43113T - Fuel Pump [ More info ] $149.49 Available to Order: Shipping delay up to 10 days.
#2	80606M	DIAPHRAGM (1 required per assembly)
		80606M - Fuel Pump Diaphragm [ More info ] $38.49 Available to Order: Shipping delay up to 10 days.
		18-7839 - Fuel Pump Diaphragm, 80606M, & Yamaha [ More info ] $20.14 In Stock
#3	80611M	PLATE (1 required per assembly)
		80611M - Plate [ More info ] $1.62 10+ In Stock.
#4	24-80610M	SPRING (1 required per assembly)
		24-80610M - Spring, Fuel Pump Diahragm,NLA [ More info ] $6.51 $5.51 10 In Stock.
#5	27-80613M	GASKET (1 required per assembly)
		27-80613M - Body To Base Gasket [ More info ] $7.77 10+ In Stock.
		27-80613 - Body To Base Gasket [ More info ] $7.09 $5.68 6 In Stock.
#6	21-41888M	CHECK VALVE (2 required per assembly)
		21-41888M - Check Valve [ More info ] $21.51 2 In Stock.
#7	27-80614M	GASKET (1 required per assembly)
		27-80614M - Cover To Body Gasket [ More info ] $11.10 10+ In Stock.
		27-80614 - Body To Cover Gasket [ More info ] $18.77 5 In Stock.
#8	84141M	DIAPHRAGM (1 required per assembly)
		84141M - Fuel Pump Diaphragm [ More info ] $12.79 Available to Order: Shipping delay up to 10 days.
		18-7840 - Fuel Pump Diaphragm, 84141M [ More info ] $11.49 $8.76 2 In Stock.
#9	80607M	COVER (1 required per assembly)
		80607M - Cover [ More info ] Unavailable
#10	10-82522M	SCREW (3 required per assembly)
		10-82522M - Screw, NLA [ More info ] Unavailable
#11	13-82186M	LOCKWASHER (3 required per assembly)
		13-82186M - LockWasher, NLA [ More info ] $1.36 $1.16 10+ In Stock.
#12	10-41889M	SCREW (2 required per assembly)
		10-41889M - Screw, NLA [ More info ] Unavailable
#13	11-82537M	NUT (2 required per assembly)
		11-82537M - Nut, NLA [ More info ] $1.63 $1.39 10+ In Stock.
#14	27-80757M	GASKET (1 required per assembly)
		27-80757M - Fuel Pump To Crankcase Gasket [ More info ] $4.27 10+ In Stock.
		27-80757 - Fuel Pump Mounting Gasket [ More info ] $3.59 $2.02 10+ In Stock.
#15	10-82428M	BOLT (2 required per assembly)
		10-82428M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-827043M - Bolt, NLA [ More info ] $6.45 3 In Stock.
#16	12-82214M	WASHER (2 required per assembly)
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#17	14187M	FUEL CONNECTOR (1 required per assembly)
		14187M - Fuel Line Connector, Straight, Old Style [ More info ] $53.49 Available to Order: Shipping delay up to 10 days.
#18	10-83539M	BOLT (1 required per assembly)
		10-83539M - 10-83539M - BOLT (M6 x 20) [ More info ] Unavailable Replaced by 10-84058M
		10-84058M - Bolt [ More info ] $7.79 1 In Stock.
#20	32-82012M	HOSE (1 required per assembly)
		32-82012M - Fuel Line, NLA [ More info ] $16.91 10+ In Stock.
#21	54-82047M	CLAMP (QTY. OF 8 ON ELECTRIC) (6 required per assembly)
		54-82047M - Clip - Priced Individually [ More info ] Unavailable
#22	35-11931M	FUEL FILTER ASSEMBLY (SEE NOTE#1) (1 required per assembly)
		35-11931M - Filter [ More info ] Unavailable
		35-826964M - Filter [ More info ] Unavailable
		35-826964T - Filter Assembly [ More info ] $93.49 Available to Order: Shipping delay up to 10 days.
#23	35-11934M	FILTER (SEE NOTE#1) (1 required per assembly)
		35-11934M - Filter [ More info ] Unavailable
		35-826965M - Filter [ More info ] Unavailable
		35-826965T - Fuel Filter [ More info ] $19.99 Available to Order: Shipping delay up to 10 days.
#24	25-84957M	O-RING (SEE NOTE#1) (1 required per assembly)
		25-84957M - O-Ring - Priced Individually [ More info ] $6.79 10+ In Stock.
#25	11935M	CUP (SEE NOTE#1) (1 required per assembly)
		11935M - Bowl, NLA [ More info ] Unavailable
#26	80620M	BRACKET (1 required per assembly)
		80620M - Bracket, NLA [ More info ] Unavailable
#27	10-813477M	BOLT (1 required per assembly)
		10-813477M - BOLT [ More info ] Unavailable
		10-91772M - Bolt [ More info ] $5.42 $4.59 10+ In Stock.
#28	11-82382M	NUT (1 required per assembly)
		11-82382M - Nut - Priced Individually [ More info ] $3.90 $3.12 10+ In Stock.
#29	32-81324M	HOSE (MANUAL) (1 required per assembly)
		32-81324M - Hose, NLA [ More info ] Unavailable
#31	22-811156M	CONNECTOR - ELECTRIC (1 required per assembly)
		22-811156M - Connector, NLA [ More info ] Unavailable
#22	35-826964M	FILTER ASSEMBLY (SEE NOTE #2) (1 required per assembly)
#23	35-826965M	FILTER (SEE NOTE #2) (1 required per assembly)
#24	25-826966M	O-RING (SEE NOTE #2) (1 required per assembly)
		25-826966M - O-Ring [ More info ] Unavailable
		25-826966T - O-Ring [ More info ] Unavailable
