Parts for Mariner 30A Carburetor
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #0-1 | 1383-7841M | CARBURETOR ASSEMBLY (1 required per assembly) |
  |
|
1383-7841M - Carburetor [ More info ] Unavailable |
| #1 | 84764M | FLOAT BOWL (1 required per assembly) |
  |
|
84764M - Float Bowl,NLA [ More info ] Unavailable |
| #2 | 27-80590M | GASKET, FLOAT BOWL (1 required per assembly) |
  |
|
27-80590M - Float Bowl Gasket [ More info ]
|
| #3 | 80591M | FLOAT (1 required per assembly) |
  |
|
|
| #4 | 17-84765M | PIN (1 required per assembly) |
  |
17-84765M - Pin, Float [ More info ] Unavailable |
|
  |
|
17-11794M - Pin, Float [ More info ]
|
| #5 | 10-82515M | SCREW (4 required per assembly) |
  |
|
10-82515M - Screw - Priced Individually [ More info ]
|
| #6 | 13-82206M | WASHER, LOCK (4 required per assembly) |
  |
|
13-82206M - LockWasher - Priced Individually [ More info ]
|
| #7 | 84766M | NOZZLE MAIN (1 required per assembly) |
  |
|
84766M - Main Nozzle, NLA [ More info ] Unavailable |
| #8 | 84767M | JET, MAIN (#135) (1 required per assembly) |
  |
|
84767M - Main Jet, NLA [ More info ] Unavailable |
| #9 | 80593M | INLET NEEDLE VALVE ASSEMBLY (1 required per assembly) |
  |
|
80593M - Inlet Valve And Seat [ More info ]
|
| #10 | 95550M | JET, PILOT (#54) (1 required per assembly) SERIAL 00018821-09999999 |
  |
|
95550M - Jet, NLA [ More info ] Unavailable |
| #10 | 80577M | JET, PILOT (#54) (1 required per assembly) SERIAL 00010646-00018820 |
  |
80577M - JET [ More info ] Unavailable |
|
| #10 | 80578M | JET, PILOT (#60) (1 required per assembly) SERIAL 00000000-00010645 |
  |
|
80578M - Jet, NLA [ More info ]
|
| #11 | 10-82623M | SCREW, IDLE SPEED (1 required per assembly) |
  |
10-82623M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
10-814463M - Screw-IDLE [ More info ] Unavailable |
|
  |
|
10-83509M - Screw, NLA [ More info ]
|
| #12 | 10-80573M | SCREW, IDLE MIXTURE (1 required per assembly) |
  |
|
10-80573M - Screw, NLA [ More info ] Unavailable |
| #13 | 24-80329M | SPRING (2 required per assembly) |
  |
24-80329M - Spring, Pilot Adjusting [ More info ] Unavailable |
|
  |
|
24-814460M - Spring, NLA [ More info ]
|
| #14 | 84768M | LEVER, THROTTLE ROD (1 required per assembly) |
  |
|
84768M - Lever [ More info ] Unavailable |
| #15 | 10-80091M | SCREW (1 required per assembly) |
  |
|
10-80091M - SCREW,NLA [ More info ] Unavailable |
| #16 | 84770M | RETAINER, THROTTLE ROD (1 required per assembly) |
  |
|
84770M - Retainer, NLA [ More info ] Unavailable |
| #17 | 84771M | ROD, THROTTLE (1 required per assembly) |
  |
|
84771M - Throttle Rod, NLA [ More info ]
|
| #18 | 84772M | THROTTLE ARM (1 required per assembly) |
  |
84772M - THROTTLE ARM [ More info ] Unavailable |
|
  |
|
811037M - Throttle Arm, NLA [ More info ] Unavailable |
| #19 | 23-81941M | BUSHING (2 required per assembly) |
  |
|
23-81941M - Bushing, NLA [ More info ]
|
| #20 | 11-82379M | NUT (1 required per assembly) |
  |
|
11-82379M - NUT Note: Priced Individually [ More info ]
|
  |
|
|
| #21 | 13-82208M | WASHER (1 required per assembly) |
  |
13-82208M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
13-82186M - LockWasher, NLA [ More info ]
|
| #22 | 23-84454M | COLLAR, THROTTLE ARM (1 required per assembly) |
  |
|
23-84454M - Bushing, NLA [ More info ]
|
| #23 | 12-82209M | WASHER (1 required per assembly) |
  |
|
12-82209M - Washer, NLA [ More info ]
|
| #24 | 53-82328M | SNAP RING (1 required per assembly) |
  |
|
53-82328M - Snap Ring, NLA [ More info ]
|
| #24 | 84773M | REPAIR KIT, CARBURETOR (1 required per assembly) REPLACEMENT PARTS |
  |
84773M - Carburetor Repair Kit [ More info ] Unavailable |
|
  |
|
811038M - Carburetor Repair Kit [ More info ]
|
