Parts for Mariner 28 HP Flywheel Magneto

Revise Search: All Models > 28 HP > 664-25801 & Up (E) > Flywheel Magneto

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#0-1	253-7169M	FLYWHEEL MAG ASS'Y (MANUAL START MODEL) (1 required per assembly) SERIAL EL570101-0Z999999
		253-7169M - Flywheel [ More info ] Unavailable
		253-6981M - Flywheel, NLA [ More info ] Unavailable
#0-1	253-6799M	FLYWHEEL MAG ASS'Y (MANUAL START MODEL) (1 required per assembly) SERIAL 00000000-00150100
		253-6799M - Flywheel, NLA [ More info ] Unavailable
#0-1	253-6981M	FLYWHEEL MAG ASS'Y (ELECTRIC START MODEL) (1 required per assembly) SERIAL EL570101-0Z999999
#0-1	80683M	FLYWHEEL MAG ASS'Y (ELECTRIC START MODEL) (1 required per assembly) SERIAL 00000000-00150100
		80683M - MAGNETO,NLA [ More info ] Unavailable
#1	253-7171M	FLYWHEEL ASS'Y (MANUAL START MODEL) (1 required per assembly) SERIAL EL570101-0Z999999
		253-7171M - Flywheel [ More info ] Unavailable
		83312M - ROTOR,NLA [ More info ] Unavailable
#1	253-7170M	FLYWHEEL ASS'Y (MANUAL START MODEL) (1 required per assembly) SERIAL 00000000-00150100
		253-7170M - Flywheel, NLA [ More info ] Unavailable
#1	83312M	FLYWHEEL ASS'Y (ELECTRIC START MODEL) (1 required per assembly) SERIAL EL570101-0Z999999
#1	80687M	FLYWHEEL ASS'Y (ELECTRIC START MODEL) (1 required per assembly) SERIAL 00000000-00150100
		80687M - ROTOR,NLA [ More info ] Unavailable
#2	43-80711M	RING GEAR(ELECTRIC START MODEL) (1 required per assembly)
		43-80711M - Ring Gear, NLA [ More info ] Unavailable
#3	10-82404M	BOLT (ELECTRIC START MODEL) (6 required per assembly)
		10-82404M - SCREW,NLA [ More info ] Unavailable
#4	13-82197M	WASHER, LOCK (ELECTRIC START MODEL) (6 required per assembly)
		13-82197M - LockWasher - Priced Individually [ More info ] Unavailable
		13-82212M - LockWasher - Priced Individually [ More info ] $1.10 10+ In Stock.
#5	12-82198M	WASHER (ELECTRIC START MODEL) (6 required per assembly)
		12-82198M - WASHER Note: Priced Individually [ More info ] Unavailable
		12-82213M - Washer - Priced Individually [ More info ] $1.50 $1.28 10+ In Stock.
#6	80684M	BASE, MAGNETO (1 required per assembly)
		80684M - Base, NLA [ More info ] Unavailable
#7	83313M	PRIMARY IGNITION COIL, #1 CYL (1 required per assembly) SERIAL EL570101-0Z999999
		83313M - Coil, NLA [ More info ] $44.99 $38.10 4 In Stock.
#7	80551M	PRIMARY IGNITION COIL, #1 CYL (1 required per assembly) SERIAL 00000000-00150100
		80551M - Ignition Coil, NLA [ More info ] $65.00 1 In Stock.
#8	83314M	PRIMARY IGNITION COIL, #2 CYL (1 required per assembly) SERIAL EL570101-0Z999999
		83314M - Coil, NLA [ More info ] $65.00 1 In Stock.
#8	80552M	PRIMARY IGNITION COIL, #2 CYL (1 required per assembly) SERIAL 00000000-00150100
		80552M - Ignition Coil, NLA [ More info ] Unavailable
#9	23-80555M	SPACER, COILE (2 required per assembly)
		23-80555M - Spacer - Coil - NLA [ More info ] Unavailable
#10	10-80556M	SCREW W/WASHER (2 required per assembly)
		10-80556M - SCREW,NLA [ More info ] Unavailable
#11	80930M	BREAKER ASS'Y (2 required per assembly)
		80930M - Breaker Point Assembly, Priced Individually [ More info ] $75.09 4 In Stock.
#12	80558M	CONDENSER (2 required per assembly)
		80558M - Condenser [ More info ] $35.49 Available to Order: Shipping delay up to 10 days.
#13	80025M	LUBRICATOR (2 required per assembly)
		80025M - Lubricator - Priced Individually, NLA [ More info ] $2.04 $1.72 10+ In Stock.
#14	10-80023M	SCREW W/WASHER (4 required per assembly)
		10-80023M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-82500M - Screw, NLA [ More info ] $1.79 10+ In Stock.
#15	84-80685M	LEAD WIRE (1 required per assembly)
		84-80685M - LEAD WIRE [ More info ] Unavailable
		84-92594M - Lead Wire, NLA [ More info ] Unavailable
#16	83315M	LIGHTING COIL (SEE NOTE) (1 required per assembly) SERIAL EL570101-0Z999999
		83315M - Coil, NLA [ More info ] $81.52 $69.05 5 In Stock.
#16	80553M	LIGHTING COIL (SEE NOTE) (1 required per assembly) SERIAL 00000000-00150100
		80553M - Lighting Coil, NLA [ More info ] $34.99 $29.63 4 In Stock.
#17	10-82503M	SCREW W/WAWSHER (2 required per assembly)
		10-82503M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-82522M - Screw, NLA [ More info ] Unavailable
#18	80689M	COVER, FLYWHEEL (1 required per assembly)
		80689M - Cover [ More info ] Unavailable
		80688M - Cover [ More info ] Unavailable
#19	27-80690M	GASKET, FLYWHEEL COVER (1 required per assembly)
		27-80690M - Flywheel Cover Gasket [ More info ] Unavailable
#20	10-82421M	BOLT, COVER ATTACHING (3 required per assembly)
		10-82421M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-84303M - Screw , Priced Individually [ More info ] $0.72 1 In Stock.
		10-813477M - BOLT [ More info ] Unavailable
		10-91772M - Bolt [ More info ] $5.42 $4.59 10+ In Stock.
#22	11-81770M	NUT, FLYWHEEL ATTACHING (1 required per assembly)
		11-81770M - Nut, Flywheel,NLA [ More info ] $2.17 $1.83 10 In Stock.
#23	12-81814M	WASHER, FLYWHEEL NUT (1 required per assembly)
		12-81814M - Washer, Flywheel Nut [ More info ] $1.36 $1.16 10+ In Stock.
#24	81657M	BRACKET, SECONDARY COIL (2 required per assembly)
		81657M - Bracket, NLA [ More info ] Unavailable
#25	10-82422M	BOLT (4 required per assembly)
		10-82422M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-84247M - BOLT Note: Priced Individually [ More info ] Unavailable
		10-91725M - BOLT [ More info ] Unavailable
		10-826957M - Bolt, NLA [ More info ] $5.19 10+ In Stock.
#27	81656M	SECONDARY IGNITION COIL ASS'Y #1 CYL (1 required per assembly)
		81656M - Ignition Coil, NLA [ More info ] Unavailable
#28	83776M	SECONDARY IGNITION COIL ASS'Y #2 CYL (1 required per assembly)
		83776M - Ignition Coil, NLA [ More info ] Unavailable
#29	84-82831M	CORD, HIGH TENSION (2 required per assembly)
		84-82831M - Wire, NLA [ More info ] $12.08 $10.23 10+ In Stock.
#30	10-82405M	BOLT (4 required per assembly)
		10-82405M - Screw, NLA [ More info ] $10.86 $9.19 10+ In Stock.
#31	13-82199M	WASHER, LOCK (4 required per assembly)
		13-82199M - LockWasher - Priced Individually [ More info ] Unavailable
		12-82214M - Washer - Priced Individually [ More info ] $5.28 10+ In Stock.
#32	82038M	CLAMP, HIGH TENSION LEADS (1 required per assembly)
		82038M - Retainer, NLA [ More info ] Unavailable
#33	82788M	PLUG CAP ASS'Y (2 required per assembly)
		82788M - Protector - Priced Individually [ More info ] $5.21 4 In Stock.
		85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ] $8.19 8 In Stock.
#33	80935M	PLUG CAP ASS'Y (NOISE SUPPRESSOR)(OPT) (2 required per assembly)
		80935M - Protector [ More info ] Unavailable
		814991M - Plug Cap [ More info ] Unavailable
		85-815119M - Protector [ More info ] Unavailable
